10. Mounting backup battery (Accessory)
If not factory-mount:
The backup battery consists of a rechargeable battery
and a printed circuit card, as well as the supplied
cable with which to connect to the main card.
Do as follows:
• Disconnect the power to the cabinet.
• Attach the backup battery in the cabinet's top left
corner. There are pre-drilled holes in which to
secure the backup battery.
• Remove the cable running between the power
supply unit and the main card, one black and
one red cable.
11. Alarm
The activation of alarms under chapter 8.6.6
includes an alarm for door and burglar alarm
(service door and wall).
Door Alarm – Connector J706
Burglar alarm – Connector J707
(See drawing, chapter 14)

12. External card reader

To connect an external card reader unit, se chapter 14.
Contact your retailer for further information.
• Now connect the supplied black cable and red
cable to the power supply unit, red cable to + and
black cable to -. Then connect this to the backup
battery's printed circuit card.
• Then connect the black, red, blue and white cable
from the printed circuit card to the backup battery
and to the main card. NB! The cabinet is now
powered via the batter y.
• Then turn on the power to the main cabinet.
Backup battery must be installed by a specialist.
At burglar alarm our external alarm connector will
be activated. This is connected to connector J1, see
drawing chapter 14
