Creone Keybox 9000 Basic Instruction Manual page 22

8. Programming
Programming is based entirely on the Main Menu and
Function Menu.
All programming must start from the programming po-
sition and can only be executed by those who have access
to the service code. To enter the programming position
the operator has to input the relevant service code. On
delivery from the factory this is 301042#.
In programming position; select the required option
in the main menu and then select the required option
in the function menu. After programming, or to change
to another menu, press 0 to return to the previous posi-
tion.
As long as you are working in the same menu, for
example entering codes, you don't need to return to
start position after each programming.
All examples below are based on the operator being
in programming position to then select the required
option in the main menu.
8.1 Codes
8.1.1 – New Code
Press 1 for NEW CODE
• Enter code (1-7 characters) and press #
• Enter compartment no. and press # twice. NB!
If more compartments are required press # once
and then select the next compartment for which
you want the code to apply. On completion, finish
off with #.
9000 S series
• Enter name (1-12 characters) and press #.
• Enter how many times the code is to apply. NB!
This is an option. If you want the code to apply
once, enter 1 then #. If the code is to always apply
don't enter anything and proceed by pressing #.
• Enter start date. NB! This is if you want the code
to be activated on a particular date. To use this func-
tion you must also specify end date, start time and
end time. If this is not required press # to proceed.
• Enter end date and press #. NB! This is if you want
the code to be deactivated on a particular date.
To use this function you must also specify start date,
start time and end time. If this is not required press
# to proceed.
• Enter start time and press #. NB! This is if you want
the code to be activated at a particular time. To use
this function you must also specify start date, end
date and end time. If this is not required press
# to proceed.
• Enter end time and press #. NB! This is if you want
the code to be deactivated at a particular time.
To use this function you must also specify start date,
end date and start time. If this is not required press
# to proceed.
You will now return to the function menu CODES.
If you wish to enter more codes select 1 for NEW
CODE and repeat the previous steps.
22
