Serial Number Location
ATTAIN
S E R I A L
1 2 3 4 5 6 7 8
Record your Serial number
and purchase date here:
S/N __________________
DATE:________________
DEALER:______________
______________________
Model No. H803
MA712
ATTAIN FITNESS
H803 FLAT/INCLINE BENCH
OWNER'S MANUAL
Fitness Authority Industrial Co., LTD.
No. 15, Xiangxue Rd., Dali Dist.,
Taichung City 41275, Taiwan.
Advertisement
Related Manuals for ATTAIN FITNESS H803
Summary of Contents for ATTAIN FITNESS H803
- Page 1 H803 FLAT/INCLINE BENCH OWNER’S MANUAL Serial Number Location ATTAIN S E R I A L 1 2 3 4 5 6 7 8 Record your Serial number and purchase date here: S/N __________________ DATE:________________ DEALER:______________ ______________________ Model No. H803 Fitness Authority Industrial Co., LTD.
-
Page 2: Important Safety Notes
7. Make certain all cables are seated within the pulleys before every use. 8. Exercise with care to avoid injury. 9. If you are unsure about the proper use of the ATTAIN FITNESS H803, call your local ATTAIN FITNESS dealer or our customer service department. - Page 3 Gym Placement Planner 28" HEIGHT 50" 39" Important Notes and Tips: Recommended Tools 1. Do not tighten bolts until instructed. for Assembly 2. Two people are required for the safe assembly of this product. 3. Use window cleaner or water to assist with sliding roller pads on to tubes.
- Page 4 H803 PARTS LIST 1 NOTE: If you are missing a listed part, it likely has been pre-installed in our factory for quality control purposes. Please con�nue with assembly. *Parts images are not to scale. (1) REAR FRAME (2) BASE FRAME...
- Page 5 STEP 1. Attach the Rear Frame (1) to Base Frame (2) using two 1/2" X 4" Hex Bolts (18), four 1/2" Washers (22) and two 1/2" Nylon Nuts (24). 2. Stick two Sheet Nonslips (8) on Rear Frame (1).
- Page 6 STEP 1. Cap one 45 X 75mm End Rect. Plug (13) to Back Support Frame (3). Attach the Back Support Frame (3) to the Base Frame (2) using one 1/2" X 4-1/2" Hex Bolt (17), two 1/2" Washers (22), and one 1/2" Nylon Nut (24).
- Page 7 STEP 1. Attach the Back Pad (6) to the Back Adj. Slider (4) using four 3/8" X 1"' Inner Hex Screws (20), and four 3/8” Washers (23). 2. Slide the Back Adj. Slider (4) onto the Back Support Frame (3) and lock it into place at your desired height using the Spring Knob (15).
-
Page 8: Parts List
PARTS LIST NO. DESCRIPTION QTY. REAR FRAME BASE FRAME BACK SUPPORT FRAME BACK ADJ. SLIDER HANDLE BAR BACK PAD SEAT PAD SHEET NONSLIP HAND GRIP SLEEVE WHEEL RECT. PLASTIC BUSHING 45 X 75mm END RECT. PLUG STEEL BUSHING SPRING KNOB LONGER POP PIN 1/2"... - Page 9 OVERVIEW...
- Page 10 Make certain all bolts are tightened securely. Enjoy many years of a Fit Lifestyle. Thank you for purchasing the ATTAIN FITNESS H803 FLAT/INCLINE BENCH! If you have any questions or comments, please contact our customer service department at +1 877-551-7484 and info@attainfitnessusa.com.
