H810 Arm Curl Attachment Assembly Manual
NO. DESCRIPTION
1
ADJ. TUBE
2
BAR CATCH
4
ARM CURL PAD
6
SQ. SPACER
8
KNOB
9
3/8" X 1-1/2" HEX HEAD BOLT
10
3/8" WASHER
1. Attach Arm Curl Pad (4) to Adj.Tube (1) using two 3/8" X 1-1/2" Hex Bolts (9)
and two 3/8" Washers (10) as shown.
2. Install 2 Sq. Spacer onto Bar Catch (2). Partially thread Knob (8) into Bar
Catch (2) then slide Bar Catch (2) onto the Adj. Tube (1) as shown.
Assembly is complete! Please make certain all bolts are tightened securely.
10
10
9
9
8
QTY.
1
1
1
2
1
2
2
4
1
6
2
6
1
6
8
NOTE! ADJUSTING THE BAR CATCH
The Knob (8) is a combination pop-pin and
tighten down.
When adjusting the bar catch,
loosen the knob by turning it counter-clockwise
½
turn, then pull the pin to adjust the bar catch
height. Always re-tighten the knob to secure
the bar catch.
2
9
10
79500-2
4
