DE-1000 Series
User Manual
Version: V1.48
Power Efficient Fanless Computers
DE-1000
Power Efficient Fanless Computers
DE-1001
Power Efficient Fanless Computers
DE-1002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE-1001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze DE-1001

Summary of Contents for Cincoze DE-1001

  • Page 1 DE-1000 Series User Manual Power Efficient Fanless Computers DE-1000 Power Efficient Fanless Computers DE-1001 Power Efficient Fanless Computers DE-1002 Version: V1.48...

  • Page 2: Table Of Contents

    Contents Preface Revision……………………………………………..……………….……………...……………...05 Copyright Notice.…………………………………………………………………………………...05 Acknowledgement.………………………………………………………………......05 Disclaimer.………………………………………………………………….………………...05 Declaration of Conformity.………………………………………………….……………………06 Product Warranty Statement …………………………………………………………….....06 Technical Support and Assistance.…………………………………………….…………………07 Conventions Used in this Manual …………………………………………….…………....08 Safety Precaution …...……………………………………………….………….………....08 Package Contents ………………………………………………………….…….………...……..09 Ordering Information …………………………………...…………………….…….……...……...10 Chapter 1 Product Introductions 1.1 Overview …………………………………………………….……..……………....12 1.2 Product Pictures…………………………………………….….……..……….….…..12 1.3 Key Features……...……………………………………….…….…….…….….…....13 1.4 Hardware Specification………….....………………….…………………….…..14...
  • Page 3 3.10 Installing Half Size Mini PCIe Card on Bottom Side……………...….……………………57 3.11 Installing Full Size Mini PCIe Cards on Bottom Side…………….………………..….59 3.12 Installing the PCI/PCIe Cards on Expansion Module (DE-1001 and DE-1002 Only)..62 3.13 Installing the Chassis………………………….………...…………….……………....65 3.14 Installing the Chassis Bottom Cover……...……….………...….………………………..66 3.15 Installing a SIM Card….…….….…….……………...….…………………………...………67...
  • Page 4 4.6.3 Full Screen Logo Show………………………...……………….………………..……88 4.6.4 Fast Boot ……………..………………………………………………………………...88 4.7 Save & Exit …...……….….…………………. …..….…..………………………....89 4.7.1 Save Changes and Reset …………………………………………………………….89 4.7.2 Discard Changes and Reset ….………………………………………………………89 4.7.3 Restore Defaults …………………………………….…………………………………89 4.7.4 Save as User Defaults …………………..…………………………………………….89 4.7.5 Restore User Defaults ..…………………………….…………………………………89 Chapter 5 Product Application 5.1 Digital I/O (DIO) application ………..…………………………………………………………91 5.1.1 Digital I/O Programming Guide ……………………………………………………..91...

  • Page 5: Revision

    1.48 Copyright Notice © 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    Product Warranty Statement Warranty Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and workmanship for 2 years from the date of purchase by the original purchaser. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    Conventions Used in this Manual Safety Precautions Before installing and using this device, please note the following precautions. Read these safety instructions carefully. Keep this User’s Manual for future reference. Disconnected this equipment from any AC outlet before cleaning. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 9 damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified service personnel. If one of the following situations arises, get the equipment checked by service personnel: ⚫...

  • Page 10: Package Contents

    Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty DE-1000 / DE-1001 / DE-1002 Embedded System DIO Terminal Block Connector Power Terminal Block Connector Remote Power Terminal Block Connector...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions DE-1000 Series | User Manual...

  • Page 12: Overview

    EN50155 certification for rail transportation applications; it is designed to ensure stable operation in robust and harsh environments. 1.2 Product pictures DE-1000 DE-1001 DE-1002 Front Rear DE-1000 Series | User Manual...

  • Page 13: Key Features

    ⚫ 2x DDR3L SO-DIMM Max. up to 8GB ⚫ Dual Independent Display from 1x DVI-I and 1x DisplayPort ⚫ 2x Intel® GbE Port, Support Wake-on-LAN and PXE (DE-1000, DE-1001, DE-1002 Only) 1x USB 3.0, 4x USB 2.0 ⚫ ⚫ 6x RS232/422/485 Port with 5V/12V Power ⚫...

  • Page 14: Hardware Specification

    Dual Display Expansion Module • 1x DVI and 1x DisplayPort • 1x Universal I/O Bracket (DE-1001) • 1x DVI-D and 1x VGA (w/ Optional Split Cable) • 2x Universal I/O Bracket (DE-1002) • 1x DisplayPort and 1x VGA (w/ DVI-I to VGA Adapter)

  • Page 15: System I/O

    1.5 System I/O 1.5.1 DE-1000 Front Panel ATX Power On/Off AT/ATX Mode Select Switch Used to power-on or power-off the system Used to select AT or ATX power mode Power LED CFast and SIM Card Slot Indicates the power status of the system Used to insert a CFast card and a SIM card HDD LED COM Port...

  • Page 16: Rear Panel

    Rear Panel DC IN Antenna Hole Used to plug a DC power input with terminal Used to connect an antenna for optional wireless block module DVI-I Port COM Port Used to connect a DVI monitor or connect Used to connect to RS-232/422/485 serial optional split cable for dual display mode devices PS/2 Port...
  • Page 17 1.5.2 DE-1001 Front Panel ATX Power On/Off AT/ATX Mode Select Switch Used to power-on or power-off the system Used to select AT or ATX power mode Power LED CFast and SIM Card Slot Indicates the power status of the system...
  • Page 18 Rear Panel DC IN Antenna Hole Used to plug a DC power input with terminal Used to connect an antenna for optional wireless block module DVI-I Port COM Port Used to connect a DVI monitor or connect Used to connect to RS-232/422/485 serial optional split cable for dual display mode devices PS/2 Port...
  • Page 19 1.5.3 DE-1002 Front Panel ATX Power On/Off AT/ATX Mode Select Switch Used to power-on or power-off the system Used to select AT or ATX power mode Power LED CFast and SIM Card Slot Indicates the power status of the system Used to insert a CFast card and a SIM card HDD LED COM Port...
  • Page 20 Rear Panel DC IN Antenna Hole Used to plug a DC power input with terminal Used to connect an antenna for optional wireless block module DVI-I Port COM Port Used to connect a DVI monitor or connect Used to connect to RS-232/422/485 serial optional split cable for dual display mode devices PS/2 Port...

  • Page 21: Mechanical Dimension

    1.6 Mechanical Dimension 1.6.1 DE-1000 Unit: mm DE-1000 Series | User Manual...
  • Page 22 1.6.2 DE-1001 Unit: mm DE-1000 Series | User Manual...
  • Page 23 1.6.3 DE-1002 Unit: mm DE-1000 Series | User Manual...
  • Page 24 Chapter 2 Jumpers, Switches & Connectors DE-1000 Series | User Manual...

  • Page 25: Jumpers Settings

    2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open. Refer to below for examples of the 2-pin and 3-pin jumpers when they are short (on) and open (off).

  • Page 26: Bottom View

    2.2.2 Bottom View DE-1000 Series | User Manual...

  • Page 27: Definition Of Jumpers/Switches/Connectors

    2.3 Definition of Jumpers/Switches/Connectors List of Jumpers/Switches/Connectors Location Definition 12V_24V_1 12V / 24V Car Battery Switch AT_ATX1 AT / ATX Power Mode Switch AUDIO1 Audio Jack CAR_PWR1 Car Power Enable / Disable Switch CFAST1 CFast Connector CLR_CMOS1 Clear CMOS Switch Remote Power on / off and Remote Reset Switch PS/2 and USB2.0 Ports LAN1 and LAN2 Ports...

  • Page 28: Definition Of Jumpers

    2.4 Definition of Jumpers COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.54mm pitch COM1 COM2 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V Reserved Reserved 7-9 On 8-10 On (Default) (Default) COM34_SEL1: COM3 / COM4 with Power Select Connector Type: 2X5 10-pin Header, 2.54mm pitch COM3...

  • Page 29: Definition Of Switches

    2.5 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch (based on bottom view) Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode (Default) CLR_CMOS1: Clear CMOS Switch (based on top view) Definition 1-2 (Right) Normal Status (Default) 2-3 (Left) Clear CMOS CN1: Remote Power on / off and Remote Reset Switch...
  • Page 30 SW1: Set shutdown delay timer when ACC is turned off Pin 1 Pin 2 Pin 3 Definition 0 second (Default) 1 minute 5 minutes 10 minutes 30 minutes 1 hour 2 hours Reserved When ignition (IGN or ACC) is turned on, the system will power on in 10 seconds. When the system has shut down with IGN switched off and the shutdown delay timer, it needs at least 60 seconds to be able to start ignition again.

  • Page 31: Definition Of Connectors

    2.6 Definition of Connectors CFAST1: CFast Connector Definition Definition Definition PC10 PC11 PC12 PC13 +3.3V PC14 +3.3V PC15 PC16 PC17 COM1~COM6: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232 Full Duplex Half Duplex Definition Definition Definition...
  • Page 32 DC_IN1: DC Power Input Connector (+9-48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9-48VIN Chassis GND Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X5 10-pin, 3.5mm pitch Definition Definition...
  • Page 33 DP1: DisplayPort Connector Definition Definition DPC_LANE0_P DPC_LANE3_N DPC_LANE0_N DPC_LANE1_P DPC_AUX_P DPC_LANE1_N DPC_LANE2_P DPC_AUX_N DPC_HPD DPC_LANE2_N DPC_LANE3_P DPC_PWR DE-1000 Series | User Manual...
  • Page 34 DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ DDC_CLOCK DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC CN2: PS/2 and USB2.0 Ports Connector Type: 6-pin Mini-DIN and dual USB 2.0 ports Definition Definition Definition USB_HUB_D1-...
  • Page 35 CN3: LAN1 and LAN2 Ports Connector Type: RJ45 with LEDs Port Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N LAN2_MDI0P LAN2_MDI2N LAN2_MDI0N LAN2_MDI1N LAN2_MDI1P LAN2_MDI3P LAN2_MDI2P LAN2_MDI3N Act LED Link LED Definition Definition Status Status Blinking Steady Data Activity 1Gbps Network Link Yellow Green...
  • Page 36 CN4: Mini PCI-Express / mSATA Socket Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN +3.3V / SATA_RXP +1.5V +3.3V MINIPCIE_RXP / CLKREQ# SATA_RXN +1.5V MINIPCIE_CLKN 29 SMB_CLK +1.5V MINIPCIE_TXN / MINIPCIE_CLKP 31 SATA_TXN SMB_DATA MINIPCIE_TXP / SATA_TXP +3.3V...
  • Page 37 MINIPCIE1: Mini PCI-Express Socket (Support mPCIE/ USB2 + 4G module) Pin Definition Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN7 41 +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP7 43 UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN 29 UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP 31 MINIPCIE_TXN UIM_RESET SMB_DATA...
  • Page 38 PCIE2: PCI-Express X1 Socket Connector Type: PCI-Express X1 Slot Definition Definition CPUFAN_ CONTROL +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3V B10 +3.3VSB PCIE_RESET# PCIE_WAKE# B12 +12V PCIE_CLKP B13 GND PCIE_CLKN B14 PCIE_TXP B15 PCIE_TXN PCIE_RXP B16 GND PCIE_RXN B17 CPUFAN_SENSE B18 GND...
  • Page 39 POWER2: Power Connector Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V USB2_1, USB2_2: USB2.0 Connector, Type A USB2_1 Definition USB2_2 Definition USB_HUB_D3- USB_HUB_D4- USB_HUB_D3+ USB_HUB_D4+ USB3_1: USB 3.0 Port, Type A Definition Definition USB3_RX+ USB_HUB_D5- USB_HUB_D5+ USB3_TX- USB3_TX+ USB3_RX- DE-1000 Series | User Manual...

  • Page 40: Chapter 3 System Setup

    Chapter 3 System Setup DE-1000 Series | User Manual...

  • Page 41: Remove The Chassis Bottom Cover

    This chapter takes DE-1000 as an example to demonstrate the installation of hardware components, except for chapter 3.12. 3.1 Remove the Chassis Bottom Cover 1. Flip over the unit to have the bottom side up. Loosen the 6 screws from bottom cover and place them aside for later use.

  • Page 42: Removing The Chassis

    3.2 Removing the Chassis Loosen 4 screws as they are marked on photo, remove the base holders, and place them aside for later use. Lift up the body unit vertically by holding the front and rear panel. DE-1000 Series | User Manual...

  • Page 43: Installing A Half Size Mini Pcie Card On Upper Side

    3.3 Installing a Half Size Mini PCIe Card on Upper Side Flip over the body unit and place it on the table gently. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 44 Fasten the module and bracket together with 2 screws. Tilt the Mini PCIe module at 45-degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. Press down the module and fasten the module with 2 screws. DE-1000 Series | User Manual...

  • Page 45: Installing A Full Size Mini Pcie Card On Upper Side

    3.4 Installing a Full Size Mini PCIe Card on Upper Side Flip over the body unit and place it on the table gently. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 46 Tilt the Mini PCIe module at 45-degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. Press down the module and fasten the module with 2 screws. DE-1000 Series | User Manual...

  • Page 47: Installing Antenna

    3.5 Installing Antenna 1. Remove the antenna covers on rear panel. 2. Have antenna jack penetrate through the hole. 3. Place on washer and fasten the nut with antenna jack. DE-1000 Series | User Manual...
  • Page 48 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the other end of cable onto the module. DE-1000 Series | User Manual...

  • Page 49: Installing A Sata Hard Drive On Upper Side

    3.6 Installing a SATA Hard Drive on Upper Side 1. Flip over the body unit and place it on the table gently. 2. Loosen the 3 screws on HDD bracket and remove the bracket. DE-1000 Series | User Manual...
  • Page 50 3. To have PCB side up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to fasten HDD and HDD bracket together. 4. Flip over the HDD bracket. Connect the HDD bracket to the SATA connector and fasten it with 3 screws.

  • Page 51: Installing A Sata Hard Drive On Bottom Side

    3.7 Installing a SATA Hard Drive on Bottom Side 1. Flip over the body unit and locate SATA socket on the bottom side. Loosen the 3 screws on HDD bracket and remove the bracket. 2. To have the PCB side up, and place the HDD on HDD bracket. Ensure the direction of bracket is correct and use 4 provided screws to fasten HDD and HDD bracket together.

  • Page 52: Installing So-Dimm 1

    3. Flip over the HDD bracket. Connect the HDD bracket to SATA connector and fasten it with 3 screws. 3.8 Installing SO-DIMM 1 1. Flip over the body unit and locate SO-DIMM socket on the bottom. DE-1000 Series | User Manual...
  • Page 53 2. Tilt the SO-DIMM module at 45-degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM slot firmly. 3. Press the module down until its fixed firmly by the two locking latches on each side. DE-1000 Series | User Manual...

  • Page 54: Installing So-Dimm 2

    3.9 Installing SO-DIMM 2 1. Flip over the body unit and locate SO-DIMM socket on the bottom. Loosen screws and take expansion module out of system. 2. Locate SO-DIMM socket on the bottom. DE-1000 Series | User Manual...
  • Page 55 3. Tilt the SO-DIMM module at 45-degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM socket firmly. 4. Press the module down and it’s fixed firmly by the two locking latches on each side. DE-1000 Series | User Manual...
  • Page 56 5. Place the expansion module back to chassis and fasten it with screws afterwards. DE-1000 Series | User Manual...

  • Page 57: Installing Half Size Mini Pcie Card On Bottom Side

    3.10 Installing Half Size Mini PCIe Card on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom side. Loosen screws and take expansion module out of system gently. 2. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 58 3. Fasten the module and bracket together with 2 screws. 4. Tilt the Mini PCIe module at 45-degree angle and insert it to Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. 5. Press down the module and use previous two screws to fix the module. DE-1000 Series | User Manual...

  • Page 59: Installing Full Size Mini Pcie Cards On Bottom Side

    6. Press down the module and use previous two screws to fix the module. 3.11 Installing Full Size Mini PCIe Cards on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom. Loosen screws and take expansion module out of system.
  • Page 60 2. Locate the Mini PCIe slot. 3. Tilt the Mini PCIe or mSATA module at 45-degree angle and insert it to Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. DE-1000 Series | User Manual...
  • Page 61 4. Press down the module and use previous two screws to fix the module. 5. Place the expansion module back to chassis and fasten the screws afterwards. DE-1000 Series | User Manual...

  • Page 62: Installing The Pci/Pcie Cards On Expansion Module (De-1001 And De-1002 Only)

    Module (DE-1001 and DE-1002 Only) 1. Locate the PCI/ PCIe expansion module, loosen screws, and take expansion module out of system (Take DE-1001 for example). 2. Loosen the screw on PCI bracket to remove the bracket. DE-1000 Series | User Manual...
  • Page 63 3. Loosen the screw to remove the card retainer. 4. Please check the following photos for instruction of placing expansion module. Insert the PCI or PCIe card to the slot and fasten the screw on PCI bracket. DE-1000 Series | User Manual...
  • Page 64 5. Before fastening the screw, you need to have the edge of PCI or PCIe module in the grooves properly. Be sure the card retainer holds the expansion module firmly. 6. Place the expansion module back to chassis and fasten the screws afterwards. DE-1000 Series | User Manual...

  • Page 65: Installing The Chassis

    3.13 Installing the Chassis 1. Be sure to align the grooves with front and rear panels. Put the cover back on and fasten the screws to fix the cover. 2. When place back the body of unit, you need to have 4 pieces of base holders and edges of front and rear panels are in the chassis groves in order to assemble the body onto chassis firmly.

  • Page 66: Installing The Chassis Bottom Cover

    3.14 Installing the Chassis Bottom Cover 1. Be sure to align the grooves with front and rear panels. Have the bottom cover back on the system and fasten the screws to fix the cover. DE-1000 Series | User Manual...

  • Page 67: Installing A Sim Card

    3.15 Installing a SIM Card 1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the SIM card slot to insert SIM card (according to the icon instruction aside). 3. Fasten the cover back on by using 2 screws. DE-1000 Series | User Manual...

  • Page 68: Installing A Cfast Card

    3.16 Installing a CFast Card 1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the CFast card slot to insert the CFast card. 3. Fasten the cover back on by using 2 screws. DE-1000 Series | User Manual...

  • Page 69: Wall Mount Bracket

    3.17 Wall Mount Bracket DE-1000 series offers wall mount that customers can install system on the wall in convenient and economical ways. 1. The mounting holes are on the bottom of system. Use provided 8 screws to fasten the brackets on each side of the system. DE-1000 Series | User Manual...
  • Page 70 2. Fasten the screws through the mounting hole to mount system on the wall. DE-1000 Series | User Manual...

  • Page 71: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup DE-1000 Series | User Manual...

  • Page 72: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 73: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date.

  • Page 74: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Setting Enable or disable BIOS ACPI Auto Configuration. DE-1000 Series | User Manual...

  • Page 75: Super Io Configuration

    4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1~6 Configuration ❑ Serial Port This item will allow users to enable or disable serial port. ❑...

  • Page 76: Hardware Monitor

    ■ Watch Dog Mode Changes the Watch dog mode. Select [Sec] or [Min] mode. ■ Watch Dog Timer User can set a value in the range of 0 to 255. 4.3.3 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures.

  • Page 77: Serial Port Console Redirection

    4.3.4 Serial Port Console Redirection ■ Console Redirection These items allow users to enable or disable console redirection function. 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores.

  • Page 78: Ppm Configuration

    ■ Limit CPUID Maximum Allows user to determine whether to limit CPUID maximum value. Set this item to Disabled: For Windows XP operating system. Enabled: For legacy operating system such as Windows NT4.0. (Default: Disabled) ■ Execute Disable Bit Enables or disables Intel Execute Disable Bit function. ■...

  • Page 79: Thermal Configuration

    ■ Enhanced C state Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system halt state. When enabled, the CPU core frequency and voltage will be reduced during system halt state to decrease power consumption. This item is configurable only when CPU C state Report is enabled.

  • Page 80: Ide Configuration

    4.3.8 IDE Configuration ■ Serial-ATA (SATA) This item will allow users to enable or disable Serial ATA. ■ SATA Mode This item will allow users to select IDE or AHCI Mode. ■ Serial – ATA Port 0 This item will allow users to enable or disable Serial-ATA Port 0. ■...

  • Page 81: Csm (Compatibility Support Module) Configuration

    ■ OS Selection This item will allow users to select Windows 8.X or Windows 7 OS. 4.3.10 CSM (Compatibility Support Module) Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■...

  • Page 82: Usb Configuration

    ■ Video Allows user to select whether to enable the UEFI or legacy option ROM for the storage device controller. Do not launch: Disables option ROM. UEFI only: Enables UEFI option ROM only. Legacy only: Enables legacy option ROM only. 4.3.11 USB Configuration ■...

  • Page 83: Chipset Setup

    4.4 Chipset Setup 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. ■ Intel IGD Configuration This section provides onboard graphics-related configuration options DE-1000 Series | User Manual...
  • Page 84 ❑ GOP Driver This item will allow users to enable or disable GOP Driver. ❑ Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device. ❑ IGD Turbo Enable This item will allow users to enable or disable IGD Turbo. ❑...

  • Page 85: South Bridge

    4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azaliadevice. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This setting disables/enables the USB XHCI controller. The eXtensible Host Controller Interface (XHCI) is a computer interface specification that defines a register-level description of a Host Controller for Universal Serial Bus (USB), which is capable of interfacing to USB 1.0, 2.0, and 3.0 compatible devices.
  • Page 86 ❑ USB Port 3 This item will allow users to enable or disable USB Port 3. ■ PCI Express Configuration ❑ PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0. ❑ Speed Change the PCI Express interface speed.

  • Page 87: Security Setup

    Power On: Leave the computer in the power on state. Last State: Restore the system to the previous status before power failure or interrupt occurred. ■ Mini-PCIe/MSATA Select (CN4) This item allows users to select Mini-PCIE or MSATA interface. 4.5 Security Setup This section allows users to configure BIOS security settings.

  • Page 88: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State Select the Power-on state for Numlock. 4.6.3 Full Screen Logo Show This item allows user to enable or disable full screen logo show.

  • Page 89: Save & Exit

    4.7 Save & Exit 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes. 4.7.2 Discard Changes and Reset This item allows user to reset system setup without saving any changes. 4.7.3 Restore Defaults This item allows user to restore/ load default values for all the options.

  • Page 90: Chapter 5 Product Application

    Chapter 5 Product Application DE-1000 Series | User Manual...

  • Page 91: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O for Cincoze DE series product Item Standard GPIO74 (Pin107)
  • Page 92 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. DE-1000 Series | User Manual...
  • Page 93 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP74 to GP77 (DI1 ~ DI4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) //Select logic device 06h...
  • Page 94 <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) 5.1.1.4.2 Control of GP80 to GP83 (DO1 ~ DO4) #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h...
  • Page 95 5.1.1.5 Change base address - DIO base address (Cincoze default 0xA00) <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 96 DATA Bit Table (DIO) 5.1.1.6 DIO I/O Port Address 5.1.1.7 Pin Definition Data Bits 0xA03 0xA02 I/O Port address DE-1000 Series | User Manual...
  • Page 97 5.2 DE-1000 DIO Hardware Specification XCOM+: Isolated power in V+ ⚫ XCOM-: Isolated power in V- ⚫ Isolated power in DC voltage: 9-30V ⚫ 8x Digital Input (Source Type) ⚫ Input Signal Voltage Level ⚫ Signal Logic 0: XCOM+ = 9V, Signal Low <...
  • Page 98 © 2020 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.

This manual is also suitable for:

De-1000 seriesDe-1002De-1002pDe-1002lDe-1001pDe-1001l
