Cincoze DE-1000 Series User Manual

Hide thumbs Also See for DE-1000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
DE-1000 Series
User Manual
Version: V1.43
Power Efficient Fanless Computers
DE-1000
Power Efficient Fanless Computers
DE-1001
Power Efficient Fanless Computers
DE-1002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DE-1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze DE-1000 Series

Summary of Contents for Cincoze DE-1000 Series

  • Page 1 DE-1000 Series User Manual Power Efficient Fanless Computers DE-1000 Power Efficient Fanless Computers DE-1001 Power Efficient Fanless Computers DE-1002 Version: V1.43...

  • Page 2: Table Of Contents

    3.1 Remove the Chassis Bottom Cover………………………….….…………………..41 3.2 Removing the Chassis…………………………………………………….………………….42 3.3 Installing a Half Size Mini PCIe Card on Upper Side………..…………….……………43 3.4 Installing a Full Size Mini PCIe Card on Upper Side.…….……...……………….....45 3.5 Installing Antenna………………………………………..….…………………....47 DE-1000 Series | User Manual...
  • Page 3 4.3.11 USB Configuration………….…………………………………………………..82 4.4 Chipset Setup …...……….…………………..…..….…..…………………………………...83 4.4.1 North Bridge……………………………………..……………………………………..83 4.4.2 South Bridge………….………………….……………………………………………..85 4.5 Security Setup …...……….………………….…..…….…………..……………………...…87 4.5.1 Administrator Password …….…...……………………………………………………87 4.5.2 User Password …….…………………………………………………..………………87 4.6 Boot Setup …...……….….……………………………...…..….…..………..…………..…88 4.6.1 Setup Prompt Timeout………………………….……………………………………..88 4.6.2 Bootup NumLock State…………………..……………………………………………88 DE-1000 Series | User Manual...
  • Page 4 4.7.4 Save as User Defaults …………………..…………………………………………….89 4.7.5 Restore User Defaults ..…………………………….…………………………………89 Chapter 5 Product Application 5.1 Digital I/O (DIO) application ………..…………………………………………………………91 5.1.1 Digital I/O Programming Guide ……………………………………………………..91 5.2 DE-1000 Digital I/O (DIO) Hardware Specification ………………………………….……..97 DE-1000 Series | User Manual...

  • Page 5: Revision

    LVD Number Updated Copyright Notice © 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Product Warranty Statement

    Product Warranty Statement Warranty Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and workmanship for 2 years from the date of purchase by the original purchaser. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.

  • Page 7: Technical Support And Assistance

    Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Conventions Used In This Manual

    Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to avoid DE-1000 Series | User Manual...
  • Page 9 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. DE-1000 Series | User Manual...

  • Page 10: Package Contents

    Intel Atom E3845 Quad Core Power Efficient Fanless Computer DE-1001-P with 1x PCI Expansion Intel Atom E3845 Quad Core Power Efficient Fanless Computer DE-1002-EE with 2x PCIex1 Expansions Intel Atom E3845 Quad Core Power Efficient Fanless Computer DE-1002-PP with 2x PCI Expansions DE-1000 Series | User Manual...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions DE-1000 Series | User Manual...

  • Page 12: Overview

    2.5” SATA HDD, CFast and SIM card. Supporting up to 6x LAN or 4x PoE versions, and power ignition function, DE-1000 series can meet various applications, such as: surveillance, in-vehicle, and industrial automation applications, etc.

  • Page 13: Key Features

    2x Mini-PCIe Slot for Wi-Fi, GSM, or I/O Expansion ⚫ 1x PCI or 1x PCIe x1 Expansion (DE-1001) ⚫ 2x PCI or 2x PCIe x1 Expansion (DE-1002) Power Ignition ⚫ ⚫ EN50155 (EN50121-3-2) / EN62368-1 Certified DE-1000 Series | User Manual...

  • Page 14: Hardware Specification

    Support maximum dimension of add-on card (H x L): • EN 50155 111.15mm x 174.63mm • EN 50121-3-2 • DE-1001-P: • LVD EN62368-1 ✓ 1x PCI Support maximum dimension of add-on card (H x L): 111.15mm x 174.63mm DE-1000 Series | User Manual...

  • Page 15: System I/O

    Used to connect to RS-232/422/485 serial USB2.0 devices Digital I/O Terminal Block Used to connect to USB 2.0/1.1 compatible devices The Digital I/O terminal block supports 8 isolated DIO (4 digital input and 4 digital output) DE-1000 Series | User Manual...
  • Page 16 A terminal block used to connect to a remote USB2.0 power on/off switch and a remote power reset Used to connect to USB 2.0/1.1 compatible switch devices Display Port Used to connect a monitor with DisplayPort interface DE-1000 Series | User Manual...
  • Page 17 Used to connect to RS-232/422/485 serial USB2.0 devices Digital I/O Terminal Block Used to connect to USB 2.0/1.1 compatible devices The Digital I/O terminal block supports 8 isolated DIO (4 digital input and 4 digital output) DE-1000 Series | User Manual...
  • Page 18 Used to connect to USB 2.0/1.1 compatible switch Universal I/O Bracket devices Display Port Used to customized I/O output with optional Used to connect a monitor with DisplayPort modules interface DE-1000 Series | User Manual...
  • Page 19 Used to connect to RS-232/422/485 serial USB2.0 devices Digital I/O Terminal Block Used to connect to USB 2.0/1.1 compatible devices The Digital I/O terminal block supports 8 isolated DIO (4 digital input and 4 digital output) DE-1000 Series | User Manual...
  • Page 20 Used to connect to USB 2.0/1.1 compatible switch Universal I/O Bracket devices Display Port Used to customized I/O output with optional Used to connect a monitor with DisplayPort modules interface DE-1000 Series | User Manual...

  • Page 21: Mechanical Dimension

    1.6 Mechanical Dimension 1.6.1 DE-1000 Unit: mm DE-1000 Series | User Manual...
  • Page 22 1.6.2 DE-1001 Unit: mm DE-1000 Series | User Manual...
  • Page 23 1.6.3 DE-1002 Unit: mm DE-1000 Series | User Manual...
  • Page 24 Chapter 2 Jumpers, Switches & Connectors DE-1000 Series | User Manual...

  • Page 25: Jumpers Settings

    Refer to below for examples of the 2-pin and 3-pin jumpers when they are short (on) and open (off). 2.2 Location of the Jumpers/Switches/Connectors 2.2.1 Top View DE-1000 Series | User Manual...

  • Page 26: Bottom View

    2.2.2 Bottom View DE-1000 Series | User Manual...

  • Page 27: Definition Of Jumpers/Switches/Connectors

    PCI-Express X1 Socket POWER1 Power Connector POWER2 Power Connector PWR_SW1 Power Switch SATA1, SATA2 SATA with Power Connector SIM1 SIM Card Socket System Power off Timing Setting USB2_1, USB2_2 USB 2.0 Ports USB3_1 USB 3.0 Port DE-1000 Series | User Manual...

  • Page 28: Definition Of Jumpers

    COM56_SEL1: COM5 / COM6 with Power Select Connector Type: 2X5 10-pin Header, 2.54mm pitch COM5 COM6 Definition Definition 1-3 On 2-4 On 3-5 On +12V 4-6 On +12V Reserved Reserved 7-9 On 8-10 On (Default) (Default) DE-1000 Series | User Manual...

  • Page 29: Definition Of Switches

    (based on top view of section 2.2.1) Definition Car Power Disable (Default) Car Power Enable 12V_24V_1: 12V / 24V Car Battery Switch (based on top view) Definition 12V Car Battery Input (Default) 24V Car Battery Input DE-1000 Series | User Manual...
  • Page 30 When ignition (IGN or ACC) is turned on, the system will power on in 10 seconds. When the system has shut down with IGN switched off and the shutdown delay timer, it needs at least 60 seconds to be able to start ignition again. PWR_SW1: Power Switch Definition Power Button DE-1000 Series | User Manual...

  • Page 31: Definition Of Connectors

    PC12 PC13 +3.3V PC14 +3.3V PC15 PC16 PC17 COM1~COM6: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 RS485 RS232 Full Duplex Half Duplex Definition Definition Definition DATA - DATA + DE-1000 Series | User Manual...
  • Page 32 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Chassis GND DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X5 10-pin, 3.5mm pitch Definition Definition DC INPUT DE-1000 Series | User Manual...
  • Page 33 DP1: DisplayPort Connector Definition Definition DPC_LANE0_P DPC_LANE3_N DPC_LANE0_N DPC_LANE1_P DPC_AUX_P DPC_LANE1_N DPC_LANE2_P DPC_AUX_N DPC_HPD DPC_LANE2_N DPC_LANE3_P DPC_PWR DE-1000 Series | User Manual...
  • Page 34 VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC CN2: PS/2 and USB2.0 Ports Connector Type: 6-pin Mini-DIN and dual USB 2.0 ports Definition Definition Definition USB_HUB_D1- USB_HUB_D2- MS_DATA USB_HUB_D1+ USB2_HUB_D2+ 11 KB_DATA MS_CLK KB_CLK DE-1000 Series | User Manual...
  • Page 35 1Gbps Network Link Yellow Green Steady No Activity 100Mbps Network Link Orange 10Mbps Network Link AUDIO1: Line-out Jack (Green) and Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition Definition OUT_L MIC_L OUT_JD MIC_JD OUT_R MIC_R DE-1000 Series | User Manual...
  • Page 36 Pin Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN +3.3V / SATA_RXP +1.5V +3.3V MINIPCIE_RXP / CLKREQ# SATA_RXN +1.5V MINIPCIE_CLKN 29 SMB_CLK +1.5V MINIPCIE_TXN / MINIPCIE_CLKP 31 SATA_TXN SMB_DATA MINIPCIE_TXP / SATA_TXP +3.3V USB2_D- DE-1000 Series | User Manual...
  • Page 37 Pin Definition Pin Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN7 41 +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP7 43 UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN 29 UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP 31 MINIPCIE_TXN UIM_RESET SMB_DATA MINIPCIE_TXP UIM_VPP +3.3V USB2_D- DE-1000 Series | User Manual...
  • Page 38 +3.3V +3.3V B10 +3.3VSB PCIE_RESET# PCIE_WAKE# B12 +12V PCIE_CLKP B13 GND PCIE_CLKN B14 PCIE_TXP B15 PCIE_TXN PCIE_RXP B16 GND PCIE_RXN B17 CPUFAN_SENSE B18 GND POWER1: Power Connector Connector Type: 1X4-pin Wafer, 2.54mm pitch Definition +12V DE-1000 Series | User Manual...
  • Page 39 Connector Type: 1X4-pin Wafer, 2.0mm pitch Definition +12V USB2_1, USB2_2: USB2.0 Connector, Type A USB2_1 Definition USB2_2 Definition USB_HUB_D3- USB_HUB_D4- USB_HUB_D3+ USB_HUB_D4+ USB3_1: USB 3.0 Port, Type A Definition Definition USB3_RX+ USB_HUB_D5- USB_HUB_D5+ USB3_TX- USB3_TX+ USB3_RX- DE-1000 Series | User Manual...

  • Page 40: Chapter 3 System Setup

    Chapter 3 System Setup DE-1000 Series | User Manual...

  • Page 41: Remove The Chassis Bottom Cover

    3.1 Remove the Chassis Bottom Cover 1. Flip over the unit to have the bottom side up. Loosen the 6 screws from bottom cover and place them aside for later use. 2. Remove the bottom cover from the chassis. DE-1000 Series | User Manual...

  • Page 42: Removing The Chassis

    3.2 Removing the Chassis Loosen 4 screws as they are marked on photo, remove the base holders, and place them aside for later use. Lift up the body unit vertically by holding the front and rear panel. DE-1000 Series | User Manual...

  • Page 43: Installing A Half Size Mini Pcie Card On Upper Side

    3.3 Installing a Half Size Mini PCIe Card on Upper Side Flip over the body unit and place it on the table gently. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 44 Tilt the Mini PCIe module at 45-degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. Press down the module and fasten the module with 2 screws. DE-1000 Series | User Manual...

  • Page 45: Installing A Full Size Mini Pcie Card On Upper Side

    3.4 Installing a Full Size Mini PCIe Card on Upper Side Flip over the body unit and place it on the table gently. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 46 Tilt the Mini PCIe module at 45-degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. Press down the module and fasten the module with 2 screws. DE-1000 Series | User Manual...

  • Page 47: Installing Antenna

    3.5 Installing Antenna 1. Remove the antenna covers on rear panel. 2. Have antenna jack penetrate through the hole. 3. Place on washer and fasten the nut with antenna jack. DE-1000 Series | User Manual...
  • Page 48 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the other end of cable onto the module. DE-1000 Series | User Manual...

  • Page 49: Installing A Sata Hard Drive On Upper Side

    3.6 Installing a SATA Hard Drive on Upper Side 1. Flip over the body unit and place it on the table gently. 2. Loosen the 3 screws on HDD bracket and remove the bracket. DE-1000 Series | User Manual...
  • Page 50 3. To have PCB side up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to fasten HDD and HDD bracket together. 4. Flip over the HDD bracket. Connect the HDD bracket to the SATA connector and fasten it with 3 screws. DE-1000 Series | User Manual...

  • Page 51: Installing A Sata Hard Drive On Bottom Side

    HDD bracket and remove the bracket. 2. To have the PCB side up, and place the HDD on HDD bracket. Ensure the direction of bracket is correct and use 4 provided screws to fasten HDD and HDD bracket together. DE-1000 Series | User Manual...

  • Page 52: Installing So-Dimm 1

    3. Flip over the HDD bracket. Connect the HDD bracket to SATA connector and fasten it with 3 screws. 3.8 Installing SO-DIMM 1 1. Flip over the body unit and locate SO-DIMM socket on the bottom. DE-1000 Series | User Manual...
  • Page 53 2. Tilt the SO-DIMM module at 45-degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM slot firmly. 3. Press the module down until its fixed firmly by the two locking latches on each side. DE-1000 Series | User Manual...

  • Page 54: Installing So-Dimm 2

    3.9 Installing SO-DIMM 2 1. Flip over the body unit and locate SO-DIMM socket on the bottom. Loosen screws and take expansion module out of system. 2. Locate SO-DIMM socket on the bottom. DE-1000 Series | User Manual...
  • Page 55 3. Tilt the SO-DIMM module at 45-degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM socket firmly. 4. Press the module down and it’s fixed firmly by the two locking latches on each side. DE-1000 Series | User Manual...
  • Page 56 5. Place the expansion module back to chassis and fasten it with screws afterwards. DE-1000 Series | User Manual...

  • Page 57: Installing Half Size Mini Pcie Card On Bottom Side

    3.10 Installing Half Size Mini PCIe Card on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom side. Loosen screws and take expansion module out of system gently. 2. Locate the Mini PCIe slot. DE-1000 Series | User Manual...
  • Page 58 4. Tilt the Mini PCIe module at 45-degree angle and insert it to Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. 5. Press down the module and use previous two screws to fix the module. DE-1000 Series | User Manual...

  • Page 59: Installing Full Size Mini Pcie Cards On Bottom Side

    3.11 Installing Full Size Mini PCIe Cards on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom. Loosen screws and take expansion module out of system. DE-1000 Series | User Manual...
  • Page 60 2. Locate the Mini PCIe slot. 3. Tilt the Mini PCIe or mSATA module at 45-degree angle and insert it to Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly. DE-1000 Series | User Manual...
  • Page 61 4. Press down the module and use previous two screws to fix the module. 5. Place the expansion module back to chassis and fasten the screws afterwards. DE-1000 Series | User Manual...

  • Page 62: Installing The Pci/Pcie Cards On Expansion Module (De-1001 And De-1002 Only)

    Module (DE-1001 and DE-1002 Only) 1. Locate the PCI/ PCIe expansion module, loosen screws, and take expansion module out of system (Take DE-1001 for example). 2. Loosen the screw on PCI bracket to remove the bracket. DE-1000 Series | User Manual...
  • Page 63 3. Loosen the screw to remove the card retainer. 4. Please check the following photos for instruction of placing expansion module. Insert the PCI or PCIe card to the slot and fasten the screw on PCI bracket. DE-1000 Series | User Manual...
  • Page 64 5. Before fastening the screw, you need to have the edge of PCI or PCIe module in the grooves properly. Be sure the card retainer holds the expansion module firmly. 6. Place the expansion module back to chassis and fasten the screws afterwards. DE-1000 Series | User Manual...

  • Page 65: Installing The Chassis

    2. When place back the body of unit, you need to have 4 pieces of base holders and edges of front and rear panels are in the chassis groves in order to assemble the body onto chassis firmly. Fasten the base holders with 4 screws afterwards. DE-1000 Series | User Manual...

  • Page 66: Installing The Chassis Bottom Cover

    3.14 Installing the Chassis Bottom Cover 1. Be sure to align the grooves with front and rear panels. Have the bottom cover back on the system and fasten the screws to fix the cover. DE-1000 Series | User Manual...

  • Page 67: Installing A Sim Card

    1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the SIM card slot to insert SIM card (according to the icon instruction aside). 3. Fasten the cover back on by using 2 screws. DE-1000 Series | User Manual...

  • Page 68: Installing A Cfast Card

    1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the CFast card slot to insert the CFast card. 3. Fasten the cover back on by using 2 screws. DE-1000 Series | User Manual...

  • Page 69: Wall Mount Bracket

    3.17 Wall Mount Bracket DE-1000 series offers wall mount that customers can install system on the wall in convenient and economical ways. 1. The mounting holes are on the bottom of system. Use provided 8 screws to fasten the brackets on each side of the system.
  • Page 70 2. Fasten the screws through the mounting hole to mount system on the wall. DE-1000 Series | User Manual...

  • Page 71: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup DE-1000 Series | User Manual...

  • Page 72: Bios Introduction

    You can use arrow keys ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. DE-1000 Series | User Manual...

  • Page 73: Main Setup

    Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. DE-1000 Series | User Manual...

  • Page 74: Advanced Setup

    4.3 Advanced Setup 4.3.1 ACPI Setting Enable or disable BIOS ACPI Auto Configuration. DE-1000 Series | User Manual...

  • Page 75: Super Io Configuration

    This item will allow users to enable or disable serial port. ❑ COM Mode Select Change the Serial interface. Select <RS232>, <RS422> or <RS485> interface. ❑ Change Settings This setting is used to change the address & IRQ settings of the specified serial port. DE-1000 Series | User Manual...

  • Page 76: Hardware Monitor

    ■ PWM Fan Function This item will allow users to enable or disable PWM Fan. ■ PWM Fan Mode Configuration ❑ PWM Fan Duty This item allows users to change the PWM Fan duty. DE-1000 Series | User Manual...

  • Page 77: Serial Port Console Redirection

    These items allow users to enable or disable console redirection function. 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores. Select <All> or <1> mode. DE-1000 Series | User Manual...

  • Page 78: Ppm Configuration

    ■ Power Technology Allows user to configure Intel power management features. 4.3.6 PPM Configuration ■ EIST Enable or disable Intel SpeedStep. ■ CPU C state Report Enables or disables support for CPU's power-saving functions. DE-1000 Series | User Manual...

  • Page 79: Thermal Configuration

    Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the CPU frequency will be automatically reduced. This item is configurable only when DTS is enabled. ■ DTS Enables or disables the CPU overheating protection function. (Default: Disabled) DE-1000 Series | User Manual...

  • Page 80: Ide Configuration

    ■ Serial – ATA Port 0 This item will allow users to enable or disable Serial-ATA Port 0. ■ Serial – ATA Port 1 This item will allow users to enable or disable Serial-ATA Port 1. 4.3.9 OS Selection DE-1000 Series | User Manual...

  • Page 81: Csm (Compatibility Support Module) Configuration

    Allows user to select whether to enable the UEFI or legacy option ROM for the storage device controller. Do not launch: Disables option ROM. UEFI only: Enables UEFI option ROM only. Legacy only: Enables legacy option ROM only. DE-1000 Series | User Manual...

  • Page 82: Usb Configuration

    XHCI (USB3.0) Hand-off support. ■ EHCI Hand-off Determines whether to enable EHCI Hand-off feature for an operating system without EHCI Hand-off support. ■ USB Mass Storage Driver Support Enables or disables support for USB storage devices. DE-1000 Series | User Manual...

  • Page 83: Chipset Setup

    4.4 Chipset Setup 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options. ■ Intel IGD Configuration This section provides onboard graphics-related configuration options DE-1000 Series | User Manual...
  • Page 84 This item will allow users to enable or disable DOP CG. ❑ GTT Size GTT size optimal between 1MB or 2MB. ❑ IGD Thermal This item will allow users to enable or disable IGD Thermal. DE-1000 Series | User Manual...

  • Page 85: South Bridge

    This item will allow users to enable or disable USB Port 0. ❑ USB Port 1 This item will allow users to enable or disable USB Port 1. ❑ USB Port 2 This item will allow users to enable or disable USB Port 2. DE-1000 Series | User Manual...
  • Page 86 Enable or disable High Precision Event Timer (HPET) in the operating system. ■ Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: Power Off: Leave the computer in the power off state. DE-1000 Series | User Manual...

  • Page 87: Security Setup

    This section allows users to configure BIOS security settings. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 4.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility. DE-1000 Series | User Manual...

  • Page 88: Boot Setup

    Select the Power-on state for Numlock. 4.6.3 Full Screen Logo Show This item allows user to enable or disable full screen logo show. 4.6.4 Fast Boot This item allows user to enable or disable Fast Boot option. DE-1000 Series | User Manual...

  • Page 89: Save & Exit

    4.7.4 Save as User Defaults This item allows user to save the changes done so far as user defaults. 4.7.5 Restore User Defaults This item allows user to restore the user defaults to all the options. DE-1000 Series | User Manual...

  • Page 90: Chapter 5 Product Application

    Chapter 5 Product Application DE-1000 Series | User Manual...

  • Page 91: Digital I/O (Dio) Application

    This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O for Cincoze DE series product Item Standard GPIO74 (Pin107)
  • Page 92 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. DE-1000 Series | User Manual...
  • Page 93 // Select configuration register 80h WriteByte(DataPort, 0x0X) //Set (bit 4~7) = 0 to select GP 74~77 as Input mode. <input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 4~7(0xFx)= GP74 ~77 as High. DE-1000 Series | User Manual...
  • Page 94 // Set (bit 0~3) = 1 to select GP 80 ~83 as Output mode. <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~3=(0/1) to output GP 80~83 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) DE-1000 Series | User Manual...
  • Page 95 5.1.1.5 Change base address - DIO base address (Cincoze default 0xA00) <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h...
  • Page 96 DATA Bit Table (DIO) 5.1.1.6 DIO I/O Port Address 5.1.1.7 Pin Definition Data Bits 0xA03 0xA02 I/O Port address DE-1000 Series | User Manual...
  • Page 97 DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current Signal High Level: Pull up resistor to XCOM+ Signal Low Level: = XCOM- Sink Current: 1A (Max) DE-1000 Series | User Manual...
  • Page 98 © 2020 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
