  • Page 2: Table Of Contents

    Chapter 1 Product Introductions 1.1 Overview ……………………………………………………………….. 12 1.1.1 Key Feature …………………………………..……………..12 1.2 Hardware Specification ………………………………..……………… 13 1.3 System I/O ……………………………………………………………… 14 1.3.1 DE-1000 …………………………………………………….…… 14 1.3.2 DE-1000(L/P) ……………………………………………….…… 16 1.3.3 DE-1001 …………………………………………………….…… 18 1.3.4 DE-1001(L/P) ……………………………………………….…… 20 1.3.5 DE-1002 …………………………………………………….…… 22 1.3.6 DE-1002(L/P) ……………………………………………….……...
  • Page 3 DE-1000 | User’s Manual Power Efficient Fanless Computer 3.6 Installing a SATA Hard Drive on Upper Side ……..….……………..59 3.7 Installing a SATA Hard Drive on Bottom Side ……..….……..……..61 3.8 Installing SO-DIMM 1 …..….……………………………….………..62 3.9 Installing SO-DIMM 2 …..….……………………………….………..64 3.10 Installing a Half Size Mini PCIe Card on Bottom Side …..…….…..

  • Page 4: Revision

    2015/01/12 Copyright Notice © 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd.

  • Page 5: Product Warranty Statement

    (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.

  • Page 6: Technical Support And Assistance

    | User’s Manual Power Efficient Fanless Computer Prefaces Technical Support and Assistance 1. Visit the Cincoze website at www.cincoze.com/support.php where you can find the latest information about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Safety Precaution

    DE-1000 | User’s Manual Power Efficient Fanless Computer Prefaces Safety Precautions Before installing and using this device, please note the following precautions: 1. Read these safety instructions carefully. 2. Keep this User’s Manual for future reference. 3. Disconnected this equipment from any AC outlet before cleaning.

  • Page 8: Package Contents

    Before installation, please ensure all the items listed in the following table are included in the package. Q’ty Item Description DE-1000(L/P) / DE-1001(L/P) / DE-1002(L/P) Embedded System Utility DVD Driver DIO Terminal Block Connector (Female) Power Terminal Block Connector (Female)

  • Page 9: Ordering Information

    DE-1000 | User’s Manual Power Efficient Fanless Computer Prefaces Ordering Information Model No. Product Description Intel® Atom™ E3845 Quad Core Power Efficient Fanless Computer DE-1000 Intel® Atom™ E3845 Quad Core Power Efficient Fanless Computer, 6x LAN DE-1000L Intel® Atom™ E3845 Quad Core Power Efficient Fanless Computer, 4x PoE and 2x LAN DE-1000P Intel®...

  • Page 10: Optional Accessory

    DE-1000 | User’s Manual Power Efficient Fanless Computer Prefaces Optional Accessories Model Name Description Adapter AC/DC 12V 5A 60W with 3pin Terminal Block Plug 5.0mm Pitch, GSM60A12-CIN GS60MA12-P1J Adapter AC/DC 24V 5A 120W with 3pin Terminal Block Plug 5.0mm Pitch,...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 12: Overview

    2.5” SATA HDD, CFast and SIM card. Supporting up to 6x LAN or 4x POE versions, and power ignition function, DE-1000 series can meet various applications, such as: surveillance, in-vehicle, and industrial automation applications, etc.

  • Page 13: Hardware Specification

    Watchdog Timer • Software Programmable Supports 1~255 sec. Metal • Mounting: Wall Mounting (Side / VESA / DIN-Rail System Reset For DE-1000(L/P) Only) Storage Operating System • 2x 2.5” SATA HDD Bay • Windows® 8 • 1x Internal mSATA Slot (Shared by Mini-PCIe •...

  • Page 14: System I/O

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3 System I/O 1.3.1 DE-1000 Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system...
  • Page 15 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 16: De-1000(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3.2 DE-1000(L/P) Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system CFast and SIM card...
  • Page 17 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 18: De-1001

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3.3 DE-1001 Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system CFast and SIM card...
  • Page 19 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 20: De-1001(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3.4 DE-1001(L/P) Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system CFast and SIM card...
  • Page 21 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 22: De-1002

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3.5 DE-1002 Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system CFast and SIM card...
  • Page 23 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 24: De-1002(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.3.6 DE-1002(L/P) Front Panel AT/ATX mode select switch ATX power on/off switch Used to select AT or ATX power mode Press to power-on or power-off the system CFast and SIM card...
  • Page 25 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions Rear Panel Antenna hole DC IN Used to connect an antenna for optional Mini-PCIe Used to plug a DC power input with terminal block WiFi module DVI-I port...

  • Page 26: Mechanical Dimension

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4 Mechanical Dimensions 1.4.1 DE-1000 Unit: mm...

  • Page 27: De-1000(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4.2 DE-1000(L/P) Unit: mm...

  • Page 28: De-1001

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4.3 DE-1001 Unit: mm...

  • Page 29: De-1001(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4.4 DE-1001(L/P) Unit: mm...

  • Page 30: De-1002

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4.5 DE-1002 Unit: mm...

  • Page 31: De-1002(L/P)

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 1: Product Introductions 1.4.6 DE-1002(L/P) Unit: mm...

  • Page 32: Chapter 2 Jumpers And Connectors

    Chapter 2 Jumpers and Connectors...

  • Page 33: Jumper Settings

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors 2.1 Jumpers Settings When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is short. If you remove the jumper cap, or place the jumper cap on just one pin, the jumper is open.

  • Page 34: Bottom View

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors 2.2.2 Bottom View...

  • Page 35: Connector / Jumper / Switch Definition

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors 2.3 Connector / Jumper / Switch Definition List of Connector / Jumper / Switch Connector Location Definition 12V_24V_1 12V / 24V Car Battery Switch AT_ATX1 AT / ATX Power Mode Switch...

  • Page 36: Switch Definition

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors 2.4 Switches Definition 12V_24V_1: 12V / 24V Car Battery Switch Definition 24V Car Battery Input (Default) 12V Car Battery Input AT_ATX1: AT / ATX Power Mode Switch...

  • Page 37: Jumper Definition

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors PWR_SW1: Power Switch Definition Power Button 2.5 Jumpers Definition COM12_SEL1: COM1 / COM2 with Power Select Connector Type: 2X5 10-pin Header, 2.54mm pitch COM1 COM2 Definition Definition...

  • Page 38: Connector Definition

    DE-1000 | User’s Manual Power Efficient Fanless Computer 2.6 Connector Definition CFAST1: CFast (Cerebrospinal Fluid Artifact Suppression Technique) Connector Definition Definition Definition PC10 PC11 PC12 PC13 +3.3V PC14 +3.3V PC15 PC16 PC17 COM1_2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub...
  • Page 39 DE-1000 | User’s Manual Power Efficient Fanless Computer COM2 RS422 / 485 Full RS485 Half RS232 Definition Duplex Definition Duplex Definition DCD2 TX2- DATA2- RxD2 TX2+ DATA2+ TxD2 RX2+ DTR2 RX2- GND2 DSR2 RTS2 CTS2 COM3_4_1: RS232 / RS422 / RS485 Connector...
  • Page 40 DE-1000 | User’s Manual Power Efficient Fanless Computer COM4 RS422 / 485 Full RS485 Half RS232 Definition Duplex Definition Duplex Definition DCD4 TX4- DATA4- RxD4 TX4+ DATA4+ TxD4 RX4+ DTR4 RX4- GND4 DSR4 RTS4 CTS4 COM5_6_1: RS232 / RS422 / RS485 Connector...
  • Page 41 DE-1000 | User’s Manual Power Efficient Fanless Computer COM6 RS422 / 485 Full RS485 Half RS232 Definition Duplex Definition Duplex Definition DCD6 TX6- DATA6- RxD6 TX6+ DATA6+ TxD6 RX6+ DTR6 RX6- GND6 DSR6 RTS6 CTS6 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch...
  • Page 42 DE-1000 | User’s Manual Power Efficient Fanless Computer...
  • Page 43 DE-1000 | User’s Manual Power Efficient Fanless Computer DP1: DisplayPort Connector Definition Definition DPC_LANE0_P DPC_LANE3_N DPC_LANE0_N DPC_LANE1_P DPC_AUX_P DPC_LANE1_N DPC_LANE2_P DPC_AUX_N DPC_HPD DPC_LANE2_N DPC_LANE3_P DPC_PWR DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ DDC_CLOCK DDC_DATA...
  • Page 44 DE-1000 | User’s Manual Power Efficient Fanless Computer CN2: PS/2 and USB2.0 Ports Connector Type: 6-pin Mini-DIN and dual USB 2.0 ports Definition Definition Definition USB_HUB_D1- USB_HUB_D2- MS_DATA USB_HUB_D1+ USB2_HUB_D2+ KB_DATA MS_CLK KB_CLK CN3: LAN1 and LAN2 Ports Connector Type: RJ45 with LEDs Port...
  • Page 45 DE-1000 | User’s Manual Power Efficient Fanless Computer CN4: Mini PCI-Express / mSATA Socket Definition Definition Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN / +3.3V SATA_RXP +1.5V +3.3V MINIPCIE_RXP / CLKREQ# SATA_RXN +1.5V MINIPCIE_CLKN SMB_CLK +1.5V MINIPCIE_TXN /...
  • Page 46 DE-1000 | User’s Manual Power Efficient Fanless Computer MINIPCIE1: Mini PCI-Express Socket Definition Definition Definition WAKE# +3.3V +3.3V USB2_D+ +3.3V MINIPCIE RST# MINIPCIE_RXN7 +3.3V +1.5V +3.3V CLKREQ# MINIPCIE_RXP7 UIM_PWR UIM_DATA +1.5V MINIPCIE_CLKN UIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP MINIPCIE_TXN UIM_RESET SMB_DATA MINIPCIE_TXP UIM_VPP +3.3V...
  • Page 47 DE-1000 | User’s Manual Power Efficient Fanless Computer PCIE2: PCI-Express X1 Socket Connector Type: PCI-Express X1 Slot Definition Definition CPUFAN_ CONTROL +12V +12V +12V +12V +12V SMB_CLK SMB_DATA +3.3V +3.3V +3.3V +3.3VSB PCIE_RESET# PCIE_WAKE# +12V PCIE_CLKP PCIE_CLKN PCIE_TXP PCIE_TXN PCIE_RXP...
  • Page 48 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 2: Jumpers and Connectors USB2_1, USB2_2: USB2.0 Connector, Type A USB2_1 Definition USB2_2 Definition USB_HUB_D3- USB_HUB_D4- USB_HUB_D3+ USB_HUB_D4+ USB3_1: USB 3.0 Port , Type A Definition Definition USB3_RX+ USB_HUB_D5- USB_HUB_D5+ USB3_TX-...

  • Page 49: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 50: Removing The Chassis Bottom Cover

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.1 Removing the Chassis Bottom Cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 51: Removing The Chassis

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.2 Removing the Chassis 1. Loosen 4 screws as they are marked on photo, remove the base holders, and place them aside for later use. 2. Lift up the body unit vertically by holding the front and rear panel.

  • Page 52: Installing A Half Size Mini Pcie Card On Upper Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.3 Installing a Half Size Mini PCIe Card on Upper Side 1. Flip over the body unit and place it on the table gently. 2. Locate the Mini PCIe slot.
  • Page 53 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. Fasten the module and bracket together with 2 screws. 4. Tilt the Mini PCIe module at 45 degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly.
  • Page 54 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 5. Press down the module and fasten the module with 2 screws.

  • Page 55: Installing A Full Size Mini Pcie Card On Upper Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.4 Installing a Full Size Mini PCIe Card on Upper Side 1. Flip over the body unit and place it on the table gently. 2. Locate the Mini PCIe slot.
  • Page 56 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. Tilt the Mini PCIe module at 45 degree angle and insert it to the Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly.

  • Page 57: Installing Antenna

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.5 Installing Antenna Please installing a Mini PCIe Wireless LAN Card on top side before you put on washer and fasten the nut with antenna jack. 1. Remove the antenna covers on rear panel.
  • Page 58 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the other end of cable onto the module.

  • Page 59: Installing A Sata Hard Drive On Upper Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.6 Installing a SATA Hard Drive on Upper Side 1. Flip over the body unit and place it on the table gently. 2. Loosen the 3 screws on HDD bracket and remove the bracket.
  • Page 60 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. To have PCB side up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to fasten HDD and HDD bracket together.

  • Page 61: Installing A Sata Hard Drive On Bottom Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.7 Installing a SATA Hard Drive on Bottom Side 1. Flip over the body unit and locate SATA socket on the bottom side. Loosen the 3 screws on HDD bracket and remove the bracket.

  • Page 62: Installing So-Dimm 1

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. Flip over the HDD bracket. Connect the HDD bracket to SATA connector and fasten it with 3 screws. 3.8 Installing SO-DIMM 1 1. Flip over the body unit and locate SO-DIMM socket on the bottom.
  • Page 63 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 2. Tilt the SO-DIMM module at 45 degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM slot firmly. 45° 3. Press the module down until its fixed firmly by the two locking latches on each side.

  • Page 64: Installing So-Dimm 2

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.9 Installing SO-DIMM 2 1. Flip over the body unit and locate SO-DIMM socket on the bottom. Loosen screws and take expansion module out of system. 2. Locate SO-DIMM socket on the bottom.
  • Page 65 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. Tilt the SO-DIMM module at 45 degree angle and insert it to SO-DIMM socket. Be sure the gold-plated connects to SO-DIMM socket firmly. 45° 4. Press the module down and it’s fixed firmly by the two locking latches on each side.

  • Page 66: Installing A Half Size Mini Pcie Card On Bottom Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 5. Place the expansion module back to chassis and fasten it with screws afterwards. 3.10 Installing Half Size Mini PCIe Card on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom side. Loosen...
  • Page 67 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 2. Locate the Mini PCIe slot. 3. Fasten the module and bracket together with 2 screws.
  • Page 68 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 4. Tilt the Mini PCIe module at 45 degree angle and insert it to Mini PCIe slot . Be sure the gold-plated connects to the Mini PCIe slot firmly.

  • Page 69: Installing A Full Size Mini Pcie Card On Bottom Side

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 6. Place the expansion module back to chassis and fasten the screws afterwards. 3.11 Installing Full Size Mini PCIe Cards on Bottom Side 1. Flip over the body unit and locate Mini PCIe or mSATA slot on the bottom. Loosen screws...
  • Page 70 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 2. Locate the Mini PCIe slot. 3. Tilt the Mini PCIe or mSATA module at 45 degree angle and insert it to Mini PCIe slot. Be sure the gold-plated connects to the Mini PCIe slot firmly.
  • Page 71 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 4. Press down the module and use previous two screws to fix the module. 5. Place the expansion module back to chassis and fasten the screws afterwards.

  • Page 72: Installing The Pci/Pcie Cards On Expansion Module

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.12 Installing the PCI/PCIe Cards on Expansion Module (DS-1001 and DS-1002 Only) 1. Locate the PCI/ PCIe expansion module, loosen screws , and take expansion module out of system (Take DE-1001 for example).
  • Page 73 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3. Loosen the screw to remove the card retainer . 4. Please check the following photos for instruction of placing expansion module. Insert the PCI or PCIe card to the slot and fasten the screw on PCI bracket.
  • Page 74 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 5. Before fastening the screw, you need to have the edge of PCI or PCIe module in the grooves properly. Be sure the card retainer holds the expansion module firmly.

  • Page 75: Installing The Chassis

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.13 Installing the Chassis 1. Be sure to align the grooves with front and rear panels. Put the cover back on and fasten the screws to fix the cover.

  • Page 76: Installing The Chassis Bottom Cover

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.14 Installing the Chassis Bottom Cover 1. Be sure to align the grooves with front and rear panels. Have the bottom cover back on the system and fasten the screws to fix the cover.

  • Page 77: Installing A Sim Card

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.15 Installing a SIM Card 1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the SIM card slot to insert SIM card (according to the icon instruction aside).

  • Page 78: Installing A Cfast Card

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 3.16 Installing a CFast Card 1. Loosen the screws in order to remove the expansion plate in the front. 2. Locate the CFast card slot to insert the CFast card.

  • Page 79: Wall Mount Bracket

    Chapter 3: System Setup 3.17 Wall Mount Brackets DE-1000 series offers wall mount that customers can install system on the wall in convenient and economical ways. 1. The mounting holes are on the bottom of system. Use provided 8 screws to fasten the...
  • Page 80 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 3: System Setup 2. Fasten the screws through the mounting hole to mount system on the wall.

  • Page 81: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 82: Bios Introduction

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.1 BIOS Introduction The BIOS (Basic Input/Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first...

  • Page 83: Main Setup

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu.

  • Page 84: Advanced Setup

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3 Advanced Setup 4.3.1 ACPI Settings Enable or disable BIOS ACPI Auto Configuration.

  • Page 85: Super Io Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.2 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ...
  • Page 86 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup ■ Serial Port 2 Configuration  Serial Port This item will allow users to enable or disable serial port.  COM2 Mode Select Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.
  • Page 87 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup ■ Serial Port 4 Configuration  Serial Port This item will allow users to enable or disable serial port.  COM4 Mode Select Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.
  • Page 88 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup ■ Serial Port 6 Configuration  Serial Port This item will allow users to enable or disable serial port.  COM6 Mode Select Change the Serial interface. Select <RS232> ,<RS422> or <RS485> interface.

  • Page 89: Hardware Monitor

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.3 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. ■ PWM Fan Function This item will allow users to enable or disable PWM Fan.

  • Page 90: Cpu Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.5 CPU Configuration ■ Socket 0 CPU Information This section provides information on your CPU, frequency, and cache memory. ■ Active Processor Cores Change the active processor cores. Select <All> or <1> mode.

  • Page 91: Ppm Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.6 PPM Configuration ■ EIST Enable or disable Intel SpeedStep. ■ CPU C state Report Enables or disables support for CPU's power-saving functions. ■ Enhanced C state Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system halt state.

  • Page 92: Thermal Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.7 Thermal Configuration ■ Critical Trip Point Allows user to set the CPU temperature threshold. If the CPU temperature reaches this value, the operating system will shut down the system. This item is configurable only when DTS is enabled.

  • Page 93: Ide Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.8 IDE Configuration ■ Serial-ATA (SATA) This item will allow users to enable or disable Serial ATA. ■ SATA Mode This item will allow users to select IDE or AHCI Mode.

  • Page 94: Os Selection

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.9 OS Selection ■ OS Selection This item will allow users to select Windows 8.X or Windows 7 OS.

  • Page 95: Csm (Compatibility Support Module) Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.10 CSM (Compatibility Support Module) Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter Allows user to select which type of operating system to boot.

  • Page 96: Usb Configuration

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.3.11 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 97: Chipset

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.4 Chipset 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics- related configuration options.
  • Page 98 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup ■ Intel IGD Configuration This section provides onboard graphics-related configuration options.  GOP Driver This item will allow users to enable or disable GOP Driver.  Integrated Graphics Device This item will allow users to enable or disable Integrated Graphics Device.

  • Page 99: South Bridge

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azaliadevice.  Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ...
  • Page 100 DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup ■ PCI Express Configuration  PCI Express Port 0 This item will allow users to enable or disable PCI Express Port 0.  Speed Change the PCI Express interface speed. Select <AUTO> ,<Gen 2> or <Gen 1>...

  • Page 101: Security

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.5 Security This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility.

  • Page 102: Boot

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.6 Boot This section allows you to configure the boot settings. 4.6.1 Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key.

  • Page 103: Save & Exit

    DE-1000 | User’s Manual Power Efficient Fanless Computer Chapter 4: BIOS Setup 4.7 Save & Exit This section allows you to configure the boot settings. 4.7.1 Save Changes and Reset This item allows user to reset system setup after saving changes.
  • Page 104 © 2014 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
