Cincoze GM-1100 User Manual

Embedded gpu computing system 14/13/12th gen intel core series embedded gpu computer, supports 1x mxm 3.1 gpu expansion socket
Hide thumbs

Advertisement

Quick Links

Download this manual
GM-1100
User Manual
Embedded GPU Computing System
14/13/12th Gen Intel® Core™ Series Embedded GPU Computer,
Supports 1x MXM 3.1 GPU Expansion Socket
Version: V1.00

Advertisement

loading
Need help?

Need help?

Do you have a question about the GM-1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze GM-1100

Summary of Contents for Cincoze GM-1100

  • Page 1 GM-1100 User Manual Embedded GPU Computing System 14/13/12th Gen Intel® Core™ Series Embedded GPU Computer, Supports 1x MXM 3.1 GPU Expansion Socket Version: V1.00...
  • Page 2 Chapter 3 System Setup ........................37 3.1 Removing Top Cover .......................... 38 3.2 Installing CPU ............................. 40 3.3 Installing SO-DIMM ..........................45 3.4 Installing M.2 Key B Module ......................46 3.4.1 M.2 Key B type 3052 Socket ....................46 GM-1100 | User Manual...
  • Page 3 4.3.5 Trusted Computing Settings ....................93 4.3.6 ACPI Settings .......................... 94 4.3.7 F81966 Super IO Configuration ....................94 4.3.8 Hardware Monitor ......................... 96 4.3.9 S5 RTC Wake Settings ......................97 4.3.10 Serial Port Console Redirection .................... 98 GM-1100 | User Manual...
  • Page 4 4.6 Boot Setup ............................108 4.7 Save & Exit ............................109 4.8 MEBx ..............................110 Chapter 5 Product Application ......................113 5.1 Where to download drivers? ......................114 5.2 Where to find the technical documents? ..................114 GM-1100 | User Manual...
  • Page 5 2024/11/29 Copyright Notice © 2024 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.
  • Page 6 (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.
  • Page 7 Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
  • Page 8 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. 13. Never open the equipment. For safety reasons, the equipment should be opened only by GM-1100 | User Manual...
  • Page 9 9-48 VDC, minimum 13-2.2A, with minimum rated maximum ambient temperature 70°C, and has to be evaluated according to IEC/EN 60950-1 and/or IEC/EN 62368-1. If need further assistance, please contact Cincoze for further information. 17. Ensure to connect the power cord of power adapter to a socket-outlet with earthing connection.
  • Page 10 Ordering Information Model No. Product Description 14/13/12th Gen Intel® Core™ Series Embedded GPU Computer, Supports GM-1100 1x MXM 3.1 GPU Expansion Socket GM-1100 | User Manual...
  • Page 11 Chapter 1 Product Introductions GM-1100 | User Manual...
  • Page 12 1.1 Overview The GM-1100 is a compact and rugged embedded MXM GPU computer for high-performance computing needs. It combines powerful computing and graphics processing capabilities with highly flexible expansion, making it ideal for edge AI applications with limited installation space.
  • Page 13 Performance boost Equipped with a 14th generation Intel® Core (Raptor Lake-S Refresh) processor, the GM-1100 is capable of three times the computing performance of its predecessor. For highly complex or specialized tasks the hybrid or P-core monolithic architecture can be chosen for the best performance based on specific needs.
  • Page 14 The harsh challenges of the Edge AI environment are overcome with industrial grade wide temperature (-40 to 70°C) and wide voltage (9 to 48 VDC) support, and passing the US military shock standard (MIL-STD-810H) to ensure product stability and safety. GM-1100 | User Manual...
  • Page 15 • Integrated Intel® UHD Graphics 730: Core™ i3 Graphics Engine • Integrated Intel® UHD Graphics 710: Pentium®/Celeron® • Supports Triple Independent Display Maximum Display Output • 1x DisplayPort Connector (4096 x 2304 @60Hz) *Verified maximum resolution: 3840 x 2160@60Hz GM-1100 | User Manual...
  • Page 16 • 1x High Speed CMI Interface for optional CMI Module Expansion CMI (Combined Multiple • 1x Low Speed CMI Interface for optional CMI Module Expansion I/O) Interface CFM (Control Function • 1x CFM IGN Interface for optional CFM-IGN Module Expansion Module) Interface Other Function GM-1100 | User Manual...
  • Page 17 Over Voltage Protection • Protection Type: shut down operating voltage, re-power on at the present level to recover • 30A Over Current Protection • SuperCap Integrated for CMOS Battery Maintenance-free Operation CMOS Battery Backup • 313,541 Hours MTBF GM-1100 | User Manual...
  • Page 18 • UL, cUL, CB, IEC, EN 62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. GM-1100 | User Manual...
  • Page 19 IGN Setting Switch Front Accessible 2.5” HDD Tray 1.3.2 Rear Antenna DisplayPort LAN2 LAN1 DC Input COM4 COM2 Line-Out HDMI COM1 COM3 Mic-in External FAN Power USB3.2 Gen1 x1 Antenna Type A Remote Universal I/O Bracket Power On/Off GM-1100 | User Manual...
  • Page 20 1.4 Dimensions GM-1100 | User Manual...
  • Page 21 Chapter 2 Switches & Connectors GM-1100 | User Manual...
  • Page 22 2.1.1 Top View COM_1_1 COM_1_2 FAN2 FAN1 DP_HDMI1 DC_IN1 PWR_SW2 AUDIO1 VGA1 BTB_FH4 CN12 LED_B1 USB3_4 USB3_3 USB3_1 PWR_SW1 USB1 2.1.2 Bottom View BTB_FH1 DEBUG1 CN13 CN14 GDC1 SATA1 SATA2 IGN_PH1 CN15 SIM2 SIM1 RESET1 AT_ATX1 24V_12V_1 GM-1100 | User Manual...
  • Page 23 IGN Module Function and Boot Delay Time Setting Switch Super CAP Control Switch USB1 USB3.2 GEN2x2 TYPE C Connector USB3_1, USB3_3, USB3_4 USB3.2 GEN2x1 TYPE A Connector VGA1 VGA DB 15 Connector 24V_12V_1 IGN Module Voltage Mode Setting Switch GM-1100 | User Manual...
  • Page 24 (Après avoir effectué Clear CMOS, le système prendra plusieurs minutes pour démarrer. Cela est normal. Pendant ce processus, le système effectuera trois fois le POST, et la LED d'alimentation du système alternera entre les lumières verte et bleue.) GM-1100 | User Manual...
  • Page 25 No Link PWR_SW1: System Power Button with Power on LED Switch Definition Push Power System LED Type LED Status Status Blue Power off (S4/S5) Power LED Green Power on (S0) Blinking Blue & Green Stand by (S3) GM-1100 | User Manual...
  • Page 26 Function DIP5 DIP6 ON (Default) ON (Default) COM3 Location Function DIP7 DIP8 ON (Default) ON (Default) COM4 SW3: Super CAP Control Switch Location Function DIP1 DIP2 Super CAP Enabled ON (Default) ON (Default) Super CAP Disabled GM-1100 | User Manual...
  • Page 27 BRI_RSP WGR_CLKP RGI_DT RGI_RSP PETP0 BRI_DT PETN0 CLINK_RST# CLINK_DATA PERP0 CLINK_CLK PERN0 COEX3 COEX_TXD REFCLKP0 COEX_RXD REFCLKN0 SUSCLK PERST0# CLKREQ0# W_DISABLE2# (PU to +3.3V) PEWAKE0# W_DISABLE1# (PU to +3.3V) I2C_DATA WTD1N/PETP1 I2C_CLK WTD1P/PETN1 WTD0N/PERP1 WTD0P/PERN1 CLKREQ1# GM-1100 | User Manual...
  • Page 28 +3.3V FULLCARD_PWROFF# (PU to +3.3V) USB2_D+ W_DISABLE1# (PU to +3.3V) USB2_D‐ DAS/DSS#/LED#1 CFG0 PERN1/USB3_RX‐ USIM_RESET PERP1/USB3_RX+ USIM_CLK USIM_DATA PETN1/USB3_TX‐ USIM_PWR PETP1/USB3_TX+ DEVSLP USIM_DET2 PERN0/SATA_B+ USIM_DATA2 PERP0/SATA_B‐ USIM_CLK2 USIM_RESET2 PETN0/SATA_A‐ USIM_PWR2 PETP0/SATA_A+ RESET# CLKREQ# REFCLKN WAKE# REFCLKP GM-1100 | User Manual...
  • Page 29 CN13, CN14 : M.2 Key B Type 2242 Connector (Support PCIE/SATA) Pin No. PIN Name Pin No. Pin name +3.3V +3.3V USB2_D+ USB2_D‐ DAS/DSS#/LED#1 PERN1 PERP1 PETN1 PETP1 DEVSLP PERN0/SATA_B+ PERP0/SATA_B‐ PETN0/SATA_A‐ PETP0/SATA_A+ RESET# CLKREQ# REFCLKN WAKE# REFCLKP GM-1100 | User Manual...
  • Page 30 +3.3V +3.3V PERN3 PERP3 DAS/DSS* PETN3 +3.3V PETP3 +3.3V +3.3V PERN2 +3.3V PERP2 CFG0 (PU to +3.3V) PETN2 PETP2 PERN1 PERP1 PETN1 PETP1 DEVSLP SMB_CLK PERN0/SATA_B+ SMB_DATA PERP0/SATA_B‐ ALERT# PETN0/SATA_A‐ PETP0/SATA_A+ PERST# CLKREQ# REFCLKN PEWAKE# REFCLKP GM-1100 | User Manual...
  • Page 31 DC power cables or connecting the DC power connector to system. (Seule une source d'alimentation unique peut être connectée à DC_IN1. Veuillez débrancher la source d'alimentation avant d'installer les câbles d'alimentation DC ou de connecter le connecteur d'alimentation DC au système.) GM-1100 | User Manual...
  • Page 32 Link Speed LED Status Definition Steady Green 1 Gbps Network Link Steady Orange 100 Mbps Network Link 10 Mbps Network Link Link Act LED Status Definition Blinking Yellow Link and Data Activity Steady Yellow Link but No Activity No Link GM-1100 | User Manual...
  • Page 33 * Before installing CMI-10GLAN04-R10 module, users need to enter BIOS to complete the following setting first. When entering BIOS, get to Chipset > PCH-IO Configuration page, and change the [BTB_FH1 Mode Selection] setting from default mode [4x1] to mode [1x4]. GM-1100 | User Manual...
  • Page 34 SW2 (on the module) : COM5 Power Select Switch Location Function DIP1 DIP2 ON (Default) ON (Default) COM5 SW2 (on the module) : COM6 Power Select Switch Location Function DIP3 DIP4 ON (Default) ON (Default) COM6 GM-1100 | User Manual...
  • Page 35 Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ (DC INPUT) XCOM- (GND) DIO2 (on the module) : Digital OUT Connector Connector Type: Terminal Block 1X10 10-pin, 3.5mm pitch Definition Definition XCOM+ (DC INPUT) XCOM- (GND) GM-1100 | User Manual...
  • Page 36 Default setting of Pin1 to Pin4 is OFF / OFF / OFF / OFF. 24V_12V_1：IGN Module Voltage Mode Setting Switch 12V / 24V Car Battery Switch. This switch functions only when applying CFM-IGN04 module. Switch Definition Left 12V Car Battery Input Right 24V Car Battery Input (Default) GM-1100 | User Manual...
  • Page 37 Chapter 3 System Setup GM-1100 | User Manual...
  • Page 38 Step 1. Turn over the unit to have the bottom side face up, loosen the 6 screws on the bottom cover and place them aside for later use. Step 2. Remove the bottom cover from the chassis. GM-1100 | User Manual...
  • Page 39 Step 3. Loosen the 4 screws. Pull out 4 latches as marked on photo. Step 4. Hold front and rear panel together and then remove the system body from the top cover. Step 5. Place the system body aside gently. GM-1100 | User Manual...
  • Page 40 CPU to the new CPU, which may cause performance issues or startup failures. Therefore, Cincoze performs a Clear CMOS procedure before shipping. When customers power on the system for the first time, it will take several minutes to start.
  • Page 41 Step 3. Lift the lever to the fully open position as shown below. Step 4. Hold the end of the lead connected to the socket cover and lift it to the fully open position, as shown below. GM-1100 | User Manual...
  • Page 42 Step 6. Hold the end of the lead connected to the socket cover to press down the socket cover. Step 7. Keep pressing the end of the lead and press down to lock the lever simultaneously. During this process, the cover will automatically pop up, as shown below. GM-1100 | User Manual...
  • Page 43 “▽ Front” means to face the side of the thermal block to the front panel. Step 10. Peel off the protective film from one side of the Thermal Pad (included in the package). GM-1100 | User Manual...
  • Page 44 Before assembling the system’s chassis cover, please make sure the protective films on the Thermal Pad have been removed! (Avant d'assembler le couvercle du châssis du système, assurez-vous que le film protecteur sur le coussin thermique a été retiré !) GM-1100 | User Manual...
  • Page 45 Step 2. Align the SO-DIMM notch with the socket notch. Insert it at a 45-degree angle until the edge connector is securely connected to the SO-DIMM socket. 45° 45° Lower socket Upper socket Step 3. Press down the module until the retaining clips snap back in place. Lower socket Upper socket GM-1100 | User Manual...
  • Page 46 Step 2. Insert the M.2 Key B type 3052 module at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° Step 3. Press down the module and fasten the screw to secure the module. (M3X5, included in the Screw Pack). GM-1100 | User Manual...
  • Page 47 Secure the bracket in place and fasten the screw (M3x4, included in the Screw Pack). Step 3. Insert the M.2 Key B module at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° GM-1100 | User Manual...
  • Page 48 M.2 Key B 2242 module.) CN13 CN14 Step 2. Insert the M.2 Key B type 2242 module at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° GM-1100 | User Manual...
  • Page 49 Step 1. Locate the M.2 Key E connector (CN5) on the top side of the system motherboard. Step 2. Tilt the M.2 Key E module at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° GM-1100 | User Manual...
  • Page 50 Step 3. Press the module down and secure it with the screw (M3X5, included in the Screw Pack). 3.6 Installing Antenna Step 1. Remove the antenna rubber cover(s) on the rear panel of the system. Antenna 1 Antenna 2 Step 2. For Antenna 1, penetrate the antenna jack through the hole. GM-1100 | User Manual...
  • Page 51 Step 3. For Antenna 1, put on the washer and fasten the nut of antenna jack. For Antenna 2, put the rear panel back onto the system and fasten the screws removed previously. Then put on the washer and fasten the nut of antenna jack. GM-1100 | User Manual...
  • Page 52 Steps 1 to 4 introduce the installation method for the carrier board of the MXM module. Steps 5 to 10 detail the installation of the MXM module itself. In this section, we use the MXM-A2000 module as an example. Step 1. Remove the two screws to remove the cover plate as indicated below. GM-1100 | User Manual...
  • Page 53 Step 2. Insert the MXM carrier board vertically to the connector on the system mainboard. Step 3. Insert the MXM carrier board vertically to the connector on the system mainboard, and fasten the screws (M3x5L) as indicated below. This slot is used to connect the MXM Module GM-1100 | User Manual...
  • Page 54 Before putting on the thermal block (in the next step), please make sure the protective film on the Thermal Pad has been removed! (Avant de poser le bloc thermique (à l'étape suivante), veuillez vous assurer que le film protecteur sur le coussinet thermique a été retiré !) GM-1100 | User Manual...
  • Page 55 (Avant d'assembler le couvercle du châssis du système, veuillez vous assurer que le film protecteur sur le coussinet thermique a été retiré !) Step 9. Fix the accompanying bracket with 4x DP cutout by fastening the two screws back. GM-1100 | User Manual...
  • Page 56 HDD bay cover bracket. (In this section, we will use the SATA2 connector as an example for installing a 2.5" SATA HDD/SSD.) Step 2. Pull the rotating arm and pull the HDD bracket out of system. GM-1100 | User Manual...
  • Page 57 Step 4. Align the HDD bracket with the entrance of HDD bay. Insert the HDD bracket and push it until the HDD connector is fully inserted into the SATA slot. Step 5. Place the rotating arm back and fasten the screw. GM-1100 | User Manual...
  • Page 58 Step 2. Tilt the M.2 Key M module at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° Step 3. Press the module down and secure it with the screw (M3X5, included in the Screw Pack). GM-1100 | User Manual...
  • Page 59 Step 2. Insert a SIM card into SIM slot with the gold contacts facing up. Please pay attention to the insert orientation as illustrated. Please note if both SIM slots are installed with SIM cards, the network connection will prioritize the card at SIM1. GM-1100 | User Manual...
  • Page 60 Step 1. Loosen the 2 screws on the front panel to remove the cover plate. Step 2. Locate the connector of CMI-module (BTB_FH4) on the top side of the system. Step 3. Replace the screw by a copper pillar (M3x10L) before inserting the CMI module. GM-1100 | User Manual...
  • Page 61 Step 4. Insert the CMI module vertically to the female connector on the system mainboard. Step 5. Fasten the 4 screws (M3x5L) to fix it. Step 6. Attach the M12 I/O bracket, and fasten the two screws and four hex rings to fix it. GM-1100 | User Manual...
  • Page 62 M12 I/O bracket Rubber rings Hex rings Step 1. Loosen the 2 screws on the front panel to remove the cover plate. Step 2. Locate the connector of CMI-module (BTB_FH4) on the top side of the system. GM-1100 | User Manual...
  • Page 63 Step 4. Insert the CMI module vertically to the female connector on the system mainboard. Step 5. Fasten the 4 screws (M3x5L) to fix it. Step 6. Attach the M12 I/O bracket, and fasten the two screws and four hex rings to fix it. GM-1100 | User Manual...
  • Page 64 Penetrate hex rings through the M12 I/O bracket holes, and fix them with hex washers. Step 2. Loosen the 2 screws on the front panel to remove the cover plate. Step 3. Locate the connector of CMI-module (BTB_FH4) on the top side of the system. GM-1100 | User Manual...
  • Page 65 Step 5. Insert the CMI module vertically to the female connector on the system mainboard. Step 6. Fasten the 4 screws to fix it. Step 7. Attach the assembled M12 I/O bracket on to the system, and fasten the two screws to fix it. GM-1100 | User Manual...
  • Page 66 When entering BIOS, get to Chipset > PCH-IO Configuration page, and change the [BTB_FH4 Mode Selection] setting from default mode [4x1] to mode [1x4]. Step 1. Loosen the 2 screws on the front panel to remove the cover plate. GM-1100 | User Manual...
  • Page 67 Before putting on the thermal block (in the next step), please make sure the protective film on the Thermal Pad has been removed! (Avant de poser le bloc thermique (à l'étape suivante), veuillez vous assurer que le film protecteur sur le coussinet thermique a été retiré !) GM-1100 | User Manual...
  • Page 68 Step 5. Put on the heatsink and turn over the module. Fasten the screw to fix the heatsink. Step 6. Insert the CMI module vertically to the female connector on the system mainboard. Step 7. Fasten the 4 screws to fix it. GM-1100 | User Manual...
  • Page 69 (Avant d'assembler le couvercle du châssis du système, veuillez vous assurer que le film protecteur sur le coussinet thermique a été retiré !) Step 9. Attach the I/O bracket, and fasten the two screws to fix it. GM-1100 | User Manual...
  • Page 70 Step 2. Loosen the 2 screws on rear panel to remove the cover plate Step 3. Penetrate the CMI-COM module through the area with an inclined angle as indicated, and then insert the CMI-COM module carefully to the CMI connector on main board. GM-1100 | User Manual...
  • Page 71 Step 4. Fix it with the two screws (M3x5L) as indicated. Step 5. Attach the CMI-COM bracket, and fasten the screws to fix it. GM-1100 | User Manual...
  • Page 72 Step 2. Loosen the 2 screws on rear panel to remove the cover plate Step 3. Penetrate the CMI-DIO module through the area with an inclined angle, and then insert the CMI-DIO module carefully to the CMI connector on main board. GM-1100 | User Manual...
  • Page 73 Step 4. Fix it with the two screws (M3x5L) as indicated. Step 5. Attach the CMI-DIO bracket, and fasten the two screws to fix it. GM-1100 | User Manual...
  • Page 74 3.13 Installing CFM Module 3.13.1 CFM-PoE01 The CFM-PoE module for GM-1100 series is installed on the CMI-LAN01, CMI-M12LAN01 or CMI-XM12LAN01 module. The photo example in this section is illustrated by CMI-M12LAN01/UB1310/CFM-PoE01 module. If you use CMI-LAN module, you will note that the shading tape has been placed on the module; if not, please paste the shading tape to the place which was marked by red circle.
  • Page 75 (Avant de poser le bloc thermique (à l'étape suivante), veuillez vous assurer que le film protecteur sur le coussinet thermique a été retiré !) Step 4. Paste the heatsink onto the CMI-PoE module carefully and connect the PoE module to the CMI-M12LAN module. GM-1100 | User Manual...
  • Page 76 The yellow surface is part of the thermal pad. Do not tear it off as it would affect the thermal conductivity. (La surface jaune fait partie du coussinet thermique. Ne la retirez pas, car cela affecterait la conductivité thermique.) GM-1100 | User Manual...
  • Page 77 Step 2. Insert the connector of power ignition board to the female connector on system motherboard. (Make sure all the pins of IGN module’s connector are firmly connected.) Step 3. Fasten two screws (M3x5L) to secure the power ignition board. GM-1100 | User Manual...
  • Page 78 3.14 Installing Top Cover Step 1. Hold the system body and reattach it to the top cover. Step 2. Push the 4 latches back and fasten the 4 screws. Step 3. Place the bottom cover on the chassis. GM-1100 | User Manual...
  • Page 79 Step 4. Fasten the 6 screws back to the bottom cover. 3.15 Installing Maintenance Area Panel Step 1. Fasten the screws as indicated to install the Maintenance Area Panel back to the system. GM-1100 | User Manual...
  • Page 80 Step 1. The mounting holes are at the bottom side of system. Use provided 8 screws (M3x5L) to fasten the bracket on each side. Step 2. Then user can fix the system onto the wall by fastening 2 mounting holes on each side of the wall mount bracket on the wall. GM-1100 | User Manual...
  • Page 81 3.17 Installing Side Mount Kit GM-1100 series offers Side Mount Kit (Model No.: SIDE-GM, 1 bracket and 8 screws) that customer can install system to the right or left side of wall to create effective of space. Step 1. The mounting holes are at the bottom side of system. Fasten the 8 screws (M3x5L*4pcs, M4x5L*4pcs) as indicated below to fix the side mount bracket with system together.
  • Page 82 3.18 Installing VESA Mount Accessories The picture below shows the VESA mounting holes on the GM-1100 series, which comply with the VESA mounting standard. The blue holes correspond to the 75x75mm VESA mounting standard, and the red holes correspond to the 100x100mm VESA mounting standard. Users can use this system with VESA accessories of the corresponding sizes.
  • Page 83 3.19 Installing DIN-Rail Mount Kit GM-1100 series offers DIN-Rail Mount Kit (Model No.: DIN01, 2 clips and 4 screws) that customer can install system on the DIN Rail. Step 1. Please refer to section 3.17 Wall Mount Brackets to install mounting bracket at both sides of system.
  • Page 84 3.20 Installing External FAN The GM-1100 series offers an optional accessory of the External FAN (Model No.: FAN-EX102) as shown in step 1. If you have acquired this accessory, please refer to the installation instructions hereafter. Step 1. Locate the two screws on the mounting frame.
  • Page 85 FAN2: GPU (MXM) smart fan connector. For pin-out details, please refer to FAN1 and FAN2 in Chapter 2.4. Right Left External Fan External Fan Fan1 Fan2 FAN2 GM-1100 | User Manual FAN1 Connector...
  • Page 86 Chapter 4 BIOS Setup GM-1100 | User Manual...
  • Page 87 ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. GM-1100 | User Manual...
  • Page 88 Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ◼ System Date Set the date. Please use <Tab> to switch between date elements. ◼ System Time Set the time. Please use <Tab> to switch between time elements. GM-1100 | User Manual...
  • Page 89 4.3 Advanced Setup This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.3.1 CPU Configuration ◼ Efficient-core Information This page displays the E-core Information. GM-1100 | User Manual...
  • Page 90 ◼ Active Performance-cores Allows you to choose the number of active performance cores. Configuration options: [All] [7] [6] [5] [4] [3] [2] [1]. ◼ Active Efficient-cores Allows you to choose the number of active efficient cores. GM-1100 | User Manual...
  • Page 91 ◼ SKU Power Config [Auto] Allows users to choose the upper limit of CPU power. Configuration options: [Auto] [35W] 4.3.3 SATA Configuration ◼ SATA Controller(s) [Enabled] Enables or disables SATA device. ◼ SATA Mode Selection [AHCI] GM-1100 | User Manual...
  • Page 92 Enables or disables CN12. ◼ CN13 Port [Enabled] Enables or disables CN13. ◼ CN14 Port [Enabled] Enables or disables CN14. ◼ CN15 Port [Enabled] Enables or disables CN15. 4.3.4 PCH-FW Configuration ◼ Firmware Update Configuration Configure Management Engine Parameters GM-1100 | User Manual...
  • Page 93 ◼ SHA256 PCR Bank [Enabled] Enables or disables SHA256 PCR Bank function. ◼ SHA384 PCR Bank [Disabled] Enables or disables SHA384 PCR Bank function. ◼ SM3_256 PCR Bank [Disabled] Enables or disables SM3_256 PCR Bank function. GM-1100 | User Manual...
  • Page 94 [Suspend Disabled]: Disables entering suspend state. [S3 (suspend to RAM)]: Enables suspend to RAM state. 4.3.7 F81966 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and select an optimal setting for the Super IO Device. GM-1100 | User Manual...
  • Page 95 Allows you to select Serial Port Mode. Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] ◼ Watch Dog [Disabled] Enables or disables watch dog function. ◼ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. GM-1100 | User Manual...
  • Page 96 Enables or disables CPU Smart Fan function. ◼ CPU Smart Fan Configuration Allows users to setting CPU smart fan parameters. ◼ Smart Fan Mode [Auto] Allows you to select Smart Fan Mode. Configuration options: [Auto] [Manual] GM-1100 | User Manual...
  • Page 97 ◼ Smart Fan Mode [Auto] Allows you to select Smart Fan Mode. Configuration options: [Auto] [Manual] ◼ Fan Speed Mode [RPM] Allows you to select Fan Speed Mode. Configuration options: [RPM] [Duty] 4.3.9 S5 RTC Wake Settings GM-1100 | User Manual...
  • Page 98 [Dynamic Time]: Sets an increase minute(s) from current time to wake system from S5. 4.3.10 Serial Port Console Redirection ◼ Console Redirection [Disabled] Allow users to enable or disable COM1, COM2 console redirection function. 4.3.11 USB Configuration GM-1100 | User Manual...
  • Page 99 USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. 4.3.12 Network Stack Configuration ◼ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.13 CSM Configuration This option controls legacy/UEFI ROMs priority. GM-1100 | User Manual...
  • Page 100 The screen allows users to select options for the NVMe configuration, and change the value of the selected option. If there is NVMe Device detected, the options will show as the NVMe Device is found. 4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. GM-1100 | User Manual...
  • Page 101 4.4.1 System Agent (SA) Configuration ◼ Memory Configuration This item displays detailed memory configuration in the system. GM-1100 | User Manual...
  • Page 102 This item allows users to enable or disable Internal Graphics. When set to [Auto], it will detect by BIOS. Configuration options: [Auto] [Disabled] [Enabled] ◼ VMD setup menu ◼ Enable VMD controller [Disabled] Allows users to enable or disable VMD controller. GM-1100 | User Manual...
  • Page 103 Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ◼ VT-d [Enabled] Enables or disables Intel® Virtualization Technology for Directed I/O (VT-d) capability. ◼ Above 4GB MMIO BIOS assignment [Enabled] Enables or disables the above 4GB Memory-Mapped-IO (MMIO) BIOS assignment. GM-1100 | User Manual...
  • Page 104 ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ◼ PCI Express Root Port (CN5) ◼ PCI Express Root Port [Enabled] Enables or disables PCI Express Root Port. GM-1100 | User Manual...
  • Page 105 ◼ LAN i219LM Controller [Enabled] Enables or disables I219 LAN Controller. ◼ Wake on LAN (i219) [Enabled] Enables or disables integrated LAN Wake on LAN function. ◼ LAN i225IT [Enabled] Enables or disables I225 LAN Controller. GM-1100 | User Manual...
  • Page 106 Allows you to specify which power state system will enter when power is resumed after a power failure (G3 state). [Always on]: Enters to power on state. [Always off]: Enters to power off state. [Keep last state]: Enters to the last power state before a power failure. GM-1100 | User Manual...
  • Page 107 User Password controls access to the system at boot and to the BIOS Setup utility. ◼ Security Boot ◼ Secure Boot [Disabled] Enable or disable Secure Boot function. ◼ Secure Boot Mode [Standard] Allows you to select Secure Boor Mode. GM-1100 | User Manual...
  • Page 108 Allows you to enable or disable Quiet Boot function. ◼ Fast Boot [Disabled] Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. GM-1100 | User Manual...
  • Page 109 Save as User Defaults This item allows you to save the changes done so far as user defaults. ◼ Restore User Defaults This item allows you to restore the user defaults to all the setup options. GM-1100 | User Manual...
  • Page 110 This page is dedicated to configuring the ME function. After the system powers on, press the delete key promptly to access the BIOS menu, allowing users to view the following MEBx page. Press enter key to enter the default password "admin" to enter the next step for password creation. GM-1100 | User Manual...
  • Page 111 Create a new password using 8 characters including uppercase and lowercase letters, numbers and special symbols. (For example, “Abc123!!”) Enter the created password again for confirmation. GM-1100 | User Manual...
  • Page 112 Afterward, you will be directed to the MEBx function setting page." GM-1100 | User Manual...
  • Page 113 Chapter 5 Product Application GM-1100 | User Manual...
  • Page 114 5.1 Where to download drivers? Please go to the CINCOZE website to download the drivers for GM-1100 series. 5.2 Where to find the technical documents? Please go to the CINCOZE website to find the technical documents for GM-1100 series. Catalog...
  • Page 115 © 2024 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
