CONNECTED STRENGTH
DEVICE HOLDER INSTALL,
HS-HG
November 2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the HAMMER STRENGTH HS-HG and is the answer not in the manual?

Questions and answers

Summary of Contents for LifeFitness HAMMER STRENGTH HS-HG

  • Page 1 CONNECTED STRENGTH DEVICE HOLDER INSTALL, HS-HG November 2024...
  • Page 2 SCOPE DEVICE HOLDER INSTALL, HS-HG The aim of this document is to capture • the steps needed to install a connected strength device holder the HS-HG, which has a unique configuration A full machine was not available, so a • mock-up was used that contained only the relevant weldments.
  • Page 3 MOCK-UP, HS-HG Actual mock-up shown here • Note the actual mock-up was positioned • at ~64.25” compared with the actual machine 63.50”...
  • Page 4 HANDLEBAR POSITION, HS-HG • Instruction steps 4, 5 & 6 remove the front bolt and rear bolt nut. This method did not work well because • the rear bolt without a nut is prone to dislodging. Because the handlebar is front-heavy, it can fall abruptly and create an unsafe condition.
  • Page 5 HANDLEBAR POSITION, HS-HG • Loosen both bolts, as shown with gaps. Next, a rag was installed between the • handlebar plate and frame to protect the paint. A thin plastic sheet could work as well. Note that the rag was installed up to the •...
  • Page 6 HANDLEBAR POSITION, HS-HG Next step, remove the rear bolt as shown •...
  • Page 7 HANDLEBAR POSITION, HS-HG With the rear bolt removed, carefully • rotate the handlebar to create necessary tool access.
  • Page 8 MARK AND CENTERPUNCH BRACKET, HS-HG These pictures show the steps taken to • mark and centerpunch the device holder bracket. The main goal is to get screw installed • accurately so if the installer is comfortable skipping the marking step that and using only the centerpunch that is OK.
  • Page 9 MARK AND CENTERPUNCH BRACKET, HS-HG Marking ¾” from bottom hole and centerpunching • Note that it’s better to perform this step off the machine as • the handlebar does not provide good support...
  • Page 10 SELF-DRILLING SCREWS BRACKET, HS-HG Install self drilling screws, (no impact driver) • Start with the bottom screw •...
  • Page 11 SELF-DRILLING SCREWS BRACKET, HS-HG It takes a bit more to get through the top • position since there is no pre-punched hole.
  • Page 12 SELF-DRILLING SCREWS CLEAN-UP, HS-HG With drilling complete, it makes sense to • clean up the chips before they can disperse and get into areas where they could cause scratches etc. Recommend a vacuum to minimize • scratching...
  • Page 13 RE-ASSEMBLE HANDLEBAR, HS-HG With paint guard still in position, rotate • the bar back to original position and re- install bolts Remove paint guard and tighten bolts •...
  • Page 14 INSTALL DEVICE HOLDER SHELF, HS-HG Install shelf with M6 hardware •...
  • Page 15 DEVICE HOLDER INSTALL COMPLETE, HS-HG Some views of the completed install •...
  • Page 16 THANK YOU...
