Page 3
M051-00K20-0426 Operation Manuals and other Product Information available at https://www.lftechsupport.com/web/document-library/documents عقوملا ىلع ةحاتم زاهجلا نع ىرخأ تامولعمو ليغشتلا ةلدأhttps://www.lftechsupport.com/web/document-library/documents 操作マニュアルおよびその他の製品情報については、 https://www.lftechsupport.com/web/document-library/documents をご覧く ださい。 如需操作手册和其他产品信息,请登录:https://www.lftechsupport.com/web/document-library/documents 操作手冊和其他產品資訊請見 https://www.lftechsupport.com/web/document-library/documents 작동 설명서 및 기타 제품 정보는 https://www.lftechsupport.com/web/document-library/documents 에서 찾을 수 있습니다. Trobareu el manual de funcionament i altra informació de producte a https://www.lftechsupport.com/web/document-library/documents Mae Llawlyfrau Gweithredu a Gwybodaeth Arall am Beiriannau ar gael yn https://www.lftechsupport.com/web/document-library/ documents Die Betriebsanleitung und andere Produktinformationen erhalten Sie unter https://www.lftechsupport.com/web/document-library/...
Page 4
21 Wong Chuk Hang Road Operating Hours: 9.00h-17.00h (CET) HONG KONG Telephone: (+852) 2575.6262 Fax: (+852) 2575.6894 Service Email: HongKongEnquiry@lifefitness.com Sales/Marketing Email: * Also check www.lifefitness.com for local representation or distributor/dealer Marketing.HK.Asia@lifefitness.com Operating Hours: 9.00h-17.00h Service Operating Hours: 9.00h-18.00h...
Safety Information It is the sole responsibility of the purchaser of LIFE FITNESS products to read the owner’s manual and warning labels and instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the equipment. UNDERSTANDING EACH AND EVERY WARNING TO THE FULLEST IS IMPORTANT.
Page 7
INSPECTION (CONTINUED) 5. EQUIPMENT MAINTENANCE - Preventative maintenance is the key to smooth operating equipment as well as to keep your liability to a minimum. Equipment needs to be inspected at regular intervals. 6. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
Warranty WHAT IS COVERED This Life Fitness commercial exercise equipment (.Product.) is warranted to be free of all defects in material and work- manship. WHO IS COVERED The original purchaser or any person receiving the product as a gift from the original purchaser. WHO PAYS TRANSPORTATION &...
HOW TO OBTAIN PARTS & SERVICE 1. Verify the symptom and review the operating instructions. The problem may be unfamiliarity with the product and its features and workouts. 2. Locate and write down the serial number of the unit. 3. Contact the nearest Life Fitness Customer Support Services Group. WARRANTY COVERAGE * There is no warranty coverage for labor on Strength Products.
Maintenance Schedule ACTION ACTION DAILY WEEKLY MONTHLY AS NEEDED CLEAN Upholstery Guide Rods Shrouds Hand Grips Frames INSPECT Accessories Cables Frame Hand Grips Hardware Jam Nuts Paint Shrouds LUBRICATE Guide Rods CLEAN... • Upholstery with an approved or compatible cleaner. •...
Page 11
ONCE A DAY 1. Wipe down upholstery with a mild soap and water or comparable all purpose cleaner. 2. Visually inspect cables for wear at and around connections and along the entire length of the cable. Always replace at first sign of wear. ONCE A WEEK 1.
Page 12
Gym Wipes are large, durable pre-moistened wipes to use on the equipment before and after workouts. Use Gym Wipes on the equipment for at least 2 minutes for general disinfection purposes. Contact Customer Support Services to order these cleaners (1-800-351-3737 or email: customersupport@lifefitness. com).
Page 33
Adjustable Pulley (MJAP-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 260 lbs / 117 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 190 lbs / 95 kg Effective User Resistance 95 lbs / 47.5 kg Product Dimensions...
Page 34
Adjustable Pulley (MJAP41-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 460 lbs / 209 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 390 lbs / 195 kg Effective User Resistance 97.5 lbs / 47.5 kg Product Dimensions...
Page 35
Adjustable Crossover - core to core (MJAXO-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 600 lbs / 272 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 2 x 190 lbs / 2 x 95 kg Effective User Resistance 2 x 95 lbs / 2 x 47.5 kg Product Dimensions...
Page 36
Adjustable Crossover - to core (MJACO-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 600 lbs / 272 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 2 x 190 lbs / 2 x 95 kg Effective User Resistance 2 x 95 lbs / 2 x 47.5 kg...
Page 37
Assited Dip Chin (MJADC-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 610 lbs / 291 kg Maximum User Weight 300 lbs / 136 kg Weight Stack 295 lbs / 147.5 kg Reisistance Ratio Effective User Resistance 118.75 lbs / 59.68 kg Product Dimensions...
Page 38
Blank Shroud (MJBLNKSHRD-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 10 lbs / 5 kg Maximum User Weight Weight Stack Effective User Resistance Product Dimensions...
Page 39
Handle Accessory Rack (MJHAR-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 31 lbs / 14 kg Maximum User Weight Reisistance Ratio Weight Stack Effective User Resistance Product Dimensions...
Page 40
Dual Pulley Pulldown (MJLPD-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 340 lbs / 154 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 260 lbs / 130 kg Effective User Resistance 130 lbs / 65 kg Product Dimensions...
Page 41
Dual Pulley High (MJDPH-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 430 lbs / 195 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 290 lbs / 145 kg Effective User Resistance 72.5 lbs / 36.25 kg Product Dimensions...
Page 42
Dual Pulley Low (MJDPL-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 430 lbs / 195 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 290 lbs / 145 kg Effective User Resistance 72.5 lbs / 36.25 kg Product Dimensions...
Page 43
Dual Pulley Row (MJRWD-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 360 lbs / 163 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 260 lbs / 130 kg Effective User Resistance 2 x 130 lbs per handle / 2 x 65 kg per handle Product Dimensions...
Page 44
Fixed Crossover - to core (MJFCO-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 600 lbs / 272 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 2 x 190 lbs / 2 x 95 kg Effective User Resistance 2 x 95 lbs / 2 x 47.5 kg Product Dimensions...
Page 45
Fixed Crossover - core to core (MJFXO-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 600 lbs / 272 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 2 x 190 lbs / 2 x 95 kg Effective User Resistance 2 x 95 lbs / 2 x 47.5 kg Product Dimensions...
Page 46
High Low Pulley (MJHL-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 260 lbs / 117 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 190 lbs / 95 kg Effective User Resistance 95 lbs / 47.5 kg Product Dimensions...
Page 47
Lat Pulldown (MJLP-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 360 lbs / 163 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 260 lbs / 130 kg Effective User Resistance 260 lbs / 130 kg Product Dimensions...
Page 48
Low Row (MJRW-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 360 lbs / 163 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 260 lbs / 130 kg Effective User Resistance 260 lbs / 130 kg Product Dimensions...
Page 49
Tricep Pushdown (MJTP-STA) Product Specifications DESCRIPTION MEASUREMENT Machine Weight 225 lbs / 102 kg Maximum User Weight 300 lbs / 136 kg Reisistance Ratio Weight Stack 190 lbs / 95 kg Effective User Resistance 190 lbs / 95 kg Product Dimensions...
Page 68
Adjust Carriage Adjust Carriage Assembly ITEM # DESCRIPTION QTY. Carriage Assembly 17mm Open End Wrench 7mm Allen Wrench NOTE: Apply downward force on each side while tightening. This allows the rear-roller to travel along its slotted bolt-holes, reducing the gap between it and the cable column. 25-30 FT-LBS.
Cable Handling Guide Cable connections with threaded cable ends are required to be installed and maintained following the specifications identified below. Failure to follow these specifications can lead to the dislocation of the threaded cable during use and can cause serious injury. Along with securing the threaded cable end and jam nut, it is important to check the entire unit and hardware is securely fastened and not left loose upon completion of cable installation.
Page 70
Cable Terminations Check Cable Terminations Cable terminations must have a minimum thread engagement of at least 1/2” (12.7mm). Check each cable end to ensure it is properly connected. Heim Joint and Carriage Terminations: • Measure cable’s threaded plug to determine the minimum depth requirement has been met. Heim Joint Terminal Carriage Terminal Head Plate Cable Terminations...
Page 71
Strain-Relief Ends Assembly Assemble Strain-Relief cable ends to cable assembly. ITEM # DESCRIPTION QTY. Cable Assembly Allen Screw Housing Insert Link 25-30 FT-LBS. (27-34 Nm) Cable Tensioning Check Cable Tension Cable should have enough tension so it stays seated in the pulley but not so tight that it lifts the headplate off the weight plate below it.
Page 72
Cable Inspection Check Cables Daily Inspect cables daily and replace at first sign of wear or any of the following cable issues: Fractures Casing can crack, or fracture, under use. Any crack in the casing merits cable replacement even if no wire rope is exposed. Be especially observant for fractures near the components on the cable assembly.
Bolt to Floor Guidelines Introduction LIFE FITNESS designs its products to be stable when used as designed. Because strength training is dynamic, we can- not predict how users will ultimately use the products in all circumstances. Therefore, LIFE FITNESS recommends that the strength training equipment listed below be secured to a solid, level surface to stabilize and eliminate rocking or tipping over.
Page 74
Anchor Types Subfloor between unit and con- Subfloor between unit and con- PRODUCT ANCHOR crete 0” to 1/2” (12.7mm) thick crete over 1/2” (12.7mm) thick KH-EZ KH-EZ 3/8” x 4” 3/8” x 5” Any Multi-Jungle (MJ) unit with 3 or Static less weight stacks HUS-H...
Page 75
Pullout Force LIFE FITNESS specifies Hilti™ static and dynamic anchors. According to the anchor manufacturer, the recommended design pullout force (in tension) for the specified anchors, when properly installed in cracked concrete, is provided in the side table. This table should be used for reference only; for additional and up-to-date information on the anchor capabilities or the design pullout force in other substrates, please consult Hilti directly at https://www.us.hilti.com.
Page 76
Foot Dimensions Use below images to determine foot specifications. Dynamic Anchor Procedure If it is possible that the length of your bolt will not provide the minimum requirement of 2.5” (63.5mm) of engagement, a longer anchor should be used. 1. Place unit into position to be mounted and cycle unit to set stance.
