THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
Please note that the way the kit is packed does not necessarily represent the way of
T
HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY
All the above settings are general and the manufacturers setting should be followed unless stated
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
FITTING INSTRUCTIONS FOR FAP0020BK
FRONT INDICATOR ADAPTORS
SUZUKI GSX 250R '17-
mounting to the bike.
GENERAL TORQUE SETTINGS
M4 BOLT = 8Nm
M5 BOLT = 12Nm
M6 BOLT = 15Nm
M8 BOLT = 20Nm
M10 BOLT = 40Nm
TOOLS REQUIRED
•
5mm Allen keys or socket bits.
•
10 & 12mm spanner.
R&G Racing
(
FOR CLARITY OF INSTRUCTIONS ONLY
www.rg-racing.com
Email:
FAP0020
).
info@rg-racing.com
Advertisement
Related Manuals for R&G FAP0020
Summary of Contents for R&G FAP0020
- Page 1 FAP0020 FITTING INSTRUCTIONS FOR FAP0020BK FRONT INDICATOR ADAPTORS SUZUKI GSX 250R ’17- Page | 1 THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW. DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT. Please note that the way the kit is packed does not necessarily represent the way of mounting to the bike.
- Page 2 FAP0020 FITTING INSTRUCTIONS • Disconnect both front indicator bullet connectors located behind the fairing. • Remove the nut that holds the indicator in place from the inside of the fairing. Repeat the procedure to the opposite side of front indicator.
- Page 3 FAP0020 NOTICE DE MONTAGE POUR FAP0020BK ADAPTATEURS DE CLIGNOTANT AVANT SUZUKI GSX 250R ’17- Page | 3 Le kit contient les articles exposés ci-dessous, vérifier que toutes les pièces soient présentes avant de procéder au montage. La façon dont le kit est emballé ne correspond pas forcément à la façon de monter les pièces sur la moto.
- Page 4 FAP0020 NOTICE DE MONTAGE: • Déconnecter les 2 connecteurs de clignotants avant placés derrière le carénage. • Enlever l’écrou qui fixe le clignotant en place depuis l’intérieur du carénage. Répéter la Page | 4 procédure pour le clignotant avant du côté opposé.
