REALTRUCK 9000104 Quick Start Manual

Molle jack mount
Hide thumbs
1
2
3

Advertisement

Quick Links

Download this manual
Part # 9000104
Components and Hardware:
1.
5.
Components and Hardware:
1. Molle Jack Mount ........................................................................... (2)
2. Thumb Screw .................................................................................. (2)
3. M8 Flange Bolt ................................................................................ (4)
4. M8 Locking Flange Nuts ................................................................ (4)
5. M8 Flat Washer .............................................................................(16)
6. M6 Flange Bolt ................................................................................ (4)
7. M6 Locking Flange Nuts ................................................................ (4)
Page 1
2.
6.
REALTRUCK
SERVICE/SUPPORT: 855-477-1529 or visit realtruck.com/contact-us
Molle Jack Mount
3.
7.
Tools for Installation:
• 10mm Wrench
• 10mm Ratchet
• 13mm Wrench
• 13mm Ratchet
4.
Rev 0.0 11/20/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the 9000104 and is the answer not in the manual?

Questions and answers

Related Manuals for REALTRUCK 9000104

Summary of Contents for REALTRUCK 9000104

  • Page 1 • 13mm Wrench 4. M8 Locking Flange Nuts ..............(4) • 13mm Ratchet 5. M8 Flat Washer ................(16) 6. M6 Flange Bolt ................(4) 7. M6 Locking Flange Nuts ..............(4) REALTRUCK SERVICE/SUPPORT: 855-477-1529 or visit realtruck.com/contact-us Page 1 Rev 0.0 11/20/23...
  • Page 2 Part # 9000104 Molle Jack Mount Extrusion T-Slot Top & Middle Bottom Holes Holes 1. Using the provided hardware, attach the Molle Jack Mount (#1) to your desired location. See mounting options shown in images. The M6 Flange Bolts (#6) and the M6 Locking Flange Nuts (#7) install in the Middle Row Holes.
  • Page 3 Part # 9000104 Molle Jack Mount 2. Place your jack in the Molle Jack Mounts (#1) once both are installed. Install the Thumb Screw (#2) through the mount hole, as shown in the hardware installation image, then through the hole in the jack’s neck.
