IMS20B Series Medium Power Servo Motor Product Manual


















Ensure that the motor is securely installed during transportation to
prevent accidental falls.
Do not transport motor products with items that could cause
damage.
Before handling large motor products, please check the fixed lifting
position of the motor and ensure the safety of the lifting
equipment during the handling process.
Do not move the motor by pulling the cables or the shaft.
Please read this manual carefully before installation and strictly
follow all safety precautions.
Please ensure that the mechanical strength of the installation
location is sufficient to support the weight of the equipment.
Please check for any abnormalities in the motor mounting holes
before installation.
Do not disassemble any components or parts of the motor. If any
modifications are needed, please contact a professional.
When performing installation work, please cover the product to
prevent metal shavings and foreign objects from entering the
motor, which could affect its safety.
Do install the overcurrent protector, leakage current protector and
emergency device and confirm their effectiveness after wiring.
Please ensure that the AC power supply voltage matches the rated
voltage of the servo motor.
Do not place the power cables and encoder cables in a strong
magnetic field environment.
Please ensure that the equipment and products have good
grounding.
Before wiring, please check the integrity of the power cables. Do
not use power cables that are damaged or exposed.
Please ensure that the drive is correctly wired to the motor.
Check before power-on
Please ensure that the product wiring connections are correct.
Please ensure that there are no personnel lingering around the
drive, motor, and related equipment.
Please ensure that the key is securely fixed. If there is no coupling
to secure the key, please remove the key to prevent it from flying
out during motor operation.
Delivery
Installation
Cable selection
2
