IMS20B Series Medium Power Servo Motor Product Manual
4.1 Product features
Comprehensive motor model: Involves 200 and 263 frame size motors, with a power

range of 6.3kW to 74kW.
Excellent motor performance: The motor has strong overload capacity.

High control precision: The motor includes a 12-bit resolver encoder and a 23-bit

absolute encoder.
4.2 Model and nameplate
4.3 Product parameters
Output Rated
Frame
power speed
size
(kW) (rpm)
8.0 2000 3000 14.4
200
7.1 1700 2700 13.3
4 Product overview
Max. Rated Peak Rated
speed current current torque
(rpm) (A) (A) (Nm)
38.1
34.6
Peak
torque
(Nm)
IMS20B-20M80C20C-4-R7F
38 96 IMS20B-20M80C20C-4-P9F
IMS20B-20M80C20C-4-P94F
IMS20B-20M71C17C-4-R7F
40 100
IMS20B-20M71C17C-4-P9F
Selectable
Motor model encoder
type
R7
P9
11
