DG-GS1510L Quick Installation Guide
DG-GS1510L
8 PORTS GIGA WEB MANAGED SWITCH,
2GIG SFP
Quick Installation Guide
As our products undergo continuous development the specifications are subject to change without prior notice
Copyright
Copyright 2017 by Digisol Systems Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into
any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission
of this company.
Trademarks
TM
DIGISOL is a trademark of Digisol Systems Ltd. All other
trademarks are the property
manufacturers.
Package Contents
The following items should be present in your package:

DG-GS1510L Switch

AC to DC External PSU

Power Cord

QIG

Installation Guide CD

Rubber Feet (4 Nos.)
Make sure that the package contains above items. If any
of the listed items is damaged or missing, please contact
your retailer immediately.
Product Overview
The Gigabit Ethernet Smart-Lite Switch Desktop: DG-
GS1510L is a fanless smart-lite switch supporting 8
Gigabit Ethernet ports. The Giga Ethernet Switch
provides a seamless network connection with integrated
1000Mbps Gigabit Ethernet, 100Mbps Fast Ethernet and
10Mbps Ethernet network capabilities.
V1.0
2017-03-21
Product Views
The front panel and rear panel of the switch are shown
below:
of the respective
DG-GS1510L Quick Installation Guide
Front Panel
Rear Panel
DG-GS1510L Quick Installation Guide
Name Details
1 Reset Press (6 sec.) to restore factory
button default parameters.
Designed to connect to network
Ethernet
devices with
2
(LAN)
10Mbps, 100Mbps or 1000Mbps.
ports
Each has
10/100/1000Mbps LED.
Supports AC 100 – 240V, 50-
3 AC
power in 60Hz.
LED Indicators
The LED Indicators will allow you to monitor, diagnose and
troubleshoot any potential problem with the Switch,
connection or attached devices.
Rev. 1.0 Copyright All rights reserved
a bandwidth of
a corresponding
