Encore
System Controller
Operator Interface Help Guide
Document Number TCP0711-00
– English –
Issued 01/25
For parts and technical support, call the Industrial Coating
Solutions Customer Support Center at (800) 433-9319 or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.
NORDSON CORPORATION • 100 NORDSON DRIVE AMHERST, OHIO 44001 USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Encore and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nordson Encore

Summary of Contents for Nordson Encore

  • Page 1 For parts and technical support, call the Industrial Coating Solutions Customer Support Center at (800) 433-9319 or contact your local Nordson representative. This document is subject to change without notice. Check http://emanuals.nordson.com for the latest version. NORDSON CORPORATION • 100 NORDSON DRIVE AMHERST, OHIO 44001 USA...
  • Page 2 Contact Us Notice Nordson Corporation welcomes requests for information, This is a Nordson Corporation publication which is protected comments, and inquiries about its products. General by copyright. Original copyright date 01/25. No part of this information about Nordson can be found on the Internet...

  • Page 3: Table Of Contents

    Purge Control Gun Display Brightness Gun Display Errors Auxiliary Trigger Function Atomize Air Delay Gun Purge Functions Encore Total On Hours Gun Total On Hours Pump Total Hours Backup Settings and Recipes Restore Settings and Recipes Reset to Nordson Defaults...
  • Page 4 Network Machine Maintenance Part Name Part Number Spray Hours Warning Alert Notifications VT Powder Flow Settings HD Powder Flow Settings About the Encore System Controller System Update System Information Operation Navigation Menu Logo Date and Time Alarms Gun Configuration Settings...
  • Page 5 Encore System Controller Operator Interface Help Guide v Spray Settings Assist Air Pump Flow Mode Electrostatic Output Mode Perform a Color Change Shutdown Backup Settings and Recipes Restore Settings and Recipes Reset to Nordson Defaults Troubleshooting Alarms and Activity Log...

  • Page 6: Navigating Help Topics

    Encore System Controller Operator Interface Help Guide 1 Navigating Help Topics Access the Help through the main Menu > Help Selecting Help opens a related topic to the current screen open on the system controller interface. Once Help is open, the Help toolbar appears with the following: Help On the Help toolbar, the Help icon opens the Help Table of Contents.

  • Page 7: Setup

    Network Maintenance VT Powder Flow Settings HD Powder Flow Settings About the Encore System Controller Initial Startup WARNING: Allow only qualified personnel to perform the following tasks. Follow the safety instructions in this document and all other related documentation. Once the manual system is assembled and a powder source is in place, the system controller will allow the user to spray immediately with a default recipe.

  • Page 8: Change Date Format

    Encore System Controller Operator Interface Help Guide 3 Change Date Format Use the Date Format drop down on the second Preferences screen to choose a date format by country. Change Current Time 1. Select the Current time field on the second Preferences screen.

  • Page 9: Gun Settings

    Encore System Controller Operator Interface Help Guide 4 Use the Security Templates to quickly populate the Security Table using default profiles. Continue to customize the table, as needed. NOTE: Only users with Administrator level security can edit security levels. Gun Settings Access the Gun Settings screen by selecting the Configuration button on the Home screen.

  • Page 10: Gun Display Brightness

    Encore System Controller Operator Interface Help Guide 5 Adjust the Purge Control setting through the Gun Settings screens. Gun Display Brightness NOTE: Only appears on HD systems. Adjusts the brightness on the spray gun display. Gun Display Errors NOTE: Only available on HD systems.

  • Page 11: Encore Total On Hours

    Purge air directed in pulses from the pump Siphon Pulses 1-99 to the powder supply. Encore Total On Hours Total time the Encore system has been ON. Review the Encore Total On Hours through the Gun Settings screens. Gun Total On Hours Total time the spray gun has been ON.

  • Page 12: Restore Settings And Recipes

    Access the Restore Settings and Recipes command through the Gun Settings screens. Reset to Nordson Defaults Selecting Reset to Nordson Defaults restores the factory default settings. Access the Reset to Nordson Defaults command through the Gun Settings screens. Flow Module Zero Offset NOTE: Only available on HD systems.

  • Page 13: Create Recipe

    Encore System Controller Operator Interface Help Guide 8 Create Recipe 1. Access the Recipes screens through the main Menu 2. Select Create New. 3. Enter a name in the Recipe Name field to assign a name to the recipe. 4. Swipe through Recipe screens to adjust recipe and save settings for: Spray Settings Spray settings can be adjusted from the Home and Edit Recipe screens using the toggles.

  • Page 14: Pump Flow Mode

    Access the Network screen through main Menu > Settings > Network Use the Network screen to connect the Encore controller to the user's network using the following settings: Machine The Machine addresses are used to communicate with other specific Nordson equipment.

  • Page 15: Part Name

    Powder Flow output from 0−100% Air (Pattern Air) air from 0.20−4.00 cfm in 0.05 increments About the Encore System Controller Access the About screen through main Menu > Settings > About The About screen contains the following: ©2025 Nordson Corporation...

  • Page 16: System Update

    Use the Update button  to start system updates. This feature will be available in future version. System Information View the About screen for information on the Encore system controller and other Nordson connected devices including addresses, serial numbers, and versions. ©2025 Nordson Corporation...

  • Page 17: Operation

    Encore System Controller Operator Interface Help Guide 12 Operation Navigation Home Screen How to Log In Adjust Spray Settings Control Details Screen Edit Recipe Perform a Color Change Shutdown Backup Settings and Recipes Restore Settings and Recipes Reset to Nordson Defaults Navigation Use the Navigation Bar and the Home screen to navigate the user interface.

  • Page 18: Menu

    Encore System Controller Operator Interface Help Guide 13 Menu The Menu provides additional navigation for the user. The Menu provides additional navigation to: Settings, Activity Log, Recipes, and Maintenance Help User Profile and Login ©2025 Nordson Corporation TCP0711-00...

  • Page 19: Logo

    Encore System Controller Operator Interface Help Guide 14 Logo Select Logo to return to the Home screen. Date and Time The Navigation Bar displays the current date and time.  The date and time can be reset through Preferences under the Settings menu.

  • Page 20: Gun Configuration Settings

    Use the Configuration button to access the Gun Settings screens to adjust settings related to the spray guns. Home Screen NOTE: To learn more about navigating the Encore controller operator interface using the Navigation Bar, see the Navigation topic. The Home screen allows the user to select recipes and adjust and save changes to recipes.

  • Page 21: Color Change

    Encore System Controller Operator Interface Help Guide 16 Color Change NOTE: Only available on HD systems. Use the Color Change button to push air throughout the system. Refer to the Perform a Color Change topic for color change procedure. Recipe Drop Down Use the Recipe drop down to select a programmed recipe.

  • Page 22: Setpoints

    How to Log In A user can navigate and view any of the screens on the Encore system controller operator interface.  To edit or change options on the screen, a user must have an assigned login.  If you require a login, contact your system administrator to create a login profile.

  • Page 23: Save Recipe

    Encore System Controller Operator Interface Help Guide 18 Save Recipe Save any manual adjustments made to a recipe. NOTE: Default Factory recipes can only be edited from the Recipes screens. Only the Powder and Air Spray Settings can be edited for default factory recipes.

  • Page 24: Control Details Screen

    Encore System Controller Operator Interface Help Guide 19 Spray Settings Icon Label Description Controls the amount of powder delivered from the pump. In VT systems, Flow Air is used to the volume. Powder In HD systems, Flow is controlled by timing valves to adjust volume.

  • Page 25: Spray Settings

    Encore System Controller Operator Interface Help Guide 20 Spray Settings Spray settings can be adjusted from the Home and Edit Recipe screens using the toggles. Alternatively, the user can select a Spray Setting button to go to the Gun Details screen and adjust the setting using the scroll bar.

  • Page 26: Spray Settings

    Encore System Controller Operator Interface Help Guide 21 1. Access the Recipes screens through the main Menu 2. Select the Edit button next to recipe. 3. Swipe through Recipe screens to adjust recipe settings and save settings. Spray Settings Spray settings can be adjusted from the Home and Edit Recipe screens using the toggles. Alternatively, the user can select a Spray Setting button to go to the Gun Details screen and adjust the setting using the scroll bar.

  • Page 27: Pump Flow Mode

    Encore System Controller Operator Interface Help Guide 22 Pump Flow Mode NOTE: Only available on HD systems. Switch between Normal or Fast to change the operating parameters of the pump software to cycle the pump slower or faster. Electrostatic Output Mode Custom - Manually adjust both kV and uA.

  • Page 28: Backup Settings And Recipes

    Access the Restore Settings and Recipes command through the Gun Settings screens. Reset to Nordson Defaults Selecting Reset to Nordson Defaults restores the factory default settings. Access the Reset to Nordson Defaults command through the Gun Settings screens. ©2025 Nordson Corporation...

  • Page 29: Troubleshooting

    Encore System Controller Operator Interface Help Guide 24 Troubleshooting Alarms and Activity Log Troubleshooting Alarms and Warnings Test uA Output Alarms and Activity Log Access the Activity Log screen by selecting the Alarms bell in the Navigation Bar or through the main Menu The Activity Log screen lists all the alarms, notifications, and activities.

  • Page 30: Resolve All

    Encore System Controller Operator Interface Help Guide 25 Calendar Notations Notation Description Notates current date. Notates selected date. Notates an activity. Resolve All Use the Resolve All button to change an Alarm  or Warning  to Resolved in the Activity Log. NOTE: Before resolving an alarm or warning, make sure to perform any associate troubleshooting steps. ...

  • Page 31: Activity Log Status Icons

    Encore System Controller Operator Interface Help Guide 26 Status Icon Date Time Gun Name Type of Activity Username that performed action or resolved alarm Activity Log Status Icons Refer to the table below for the Activity Log status icons. Activity Log Status Icons...
  • Page 32 Encore System Controller Operator Interface Help Guide 27 0x1010u Message Powder Airflow Low Corrective Action VT Check if input pressure is greater than 100 psi (6.9 bar). Check for blocked flow tubing to pump. Check wiring for proportional valve VY1B for shorts or opens J5 pins 1,2 and 3 on backplane.
  • Page 33 Encore System Controller Operator Interface Help Guide 28 0x1012u Message VT Atomizing Airflow Low Message HD Pattern Airflow Low Corrective Action VT Check if input pressure is greater than 100 psi (6.9 bar). Check for blocked atomizing air tubing to pump.
  • Page 34 Encore System Controller Operator Interface Help Guide 29 0x1013u Message VT Atomizing Airflow High Message HD Pattern Airflow High Corrective Action VT Check if input pressure is greater than 100 psi (6.9 bar). Check for blocked atomizing air tubing to pump.
  • Page 35 Encore System Controller Operator Interface Help Guide 30 0x2011u Message Over Current Foldback Corrective Action VT This fault can occur if the gun tip touches a grounded part while spraying. This fault turns the electrostatic output OFF. Release the trigger to reset the fault and resume spraying. Resolve the fault on the system controller Activity Log screen.
  • Page 36 0x5003u Message Device Invalid Node ID Corrective Action The device controller address should always be 1. If system malfunctions call Nordson Service for assistance. 0x501 Au Message HD Valve 5 Delivery Pinch Corrective Action HD Check J11-5 for loose harness connection on the iFlow® module.
  • Page 37 Encore System Controller Operator Interface Help Guide 32 0x501 Bu Message HD Valve 6 Suction Pinch Corrective Action HD Check J11-6 for loose harness connection on the iFlow module. Check valve 6 for loose connection on the pump manifold. Refer to Manifold Troubleshooting.
  • Page 38 Encore System Controller Operator Interface Help Guide 33 0x5011u Message HD Valve Pattern Air Corrective Action HD Check the wiring harness connection (J8) to the proportional valve solenoid on the iFlow module. Check the solenoid operation. Replace the valve if the solenoid is not working.
  • Page 39 Check valve 4 for loose connection on the pump manifold. Refer to Manifold Troubleshooting. 0x6000u Message Device Hw Sw Mismatch Corrective Action Call Nordson Service for assistance. 0x6100u Message Watchdog Alarm Corrective Action System controller is resetting. Check for proper chassis grounding.
  • Page 40 Encore System Controller Operator Interface Help Guide 35 0x6101u Message Calibration Invalid Corrective Action Pump calibration values for A or C are out of range. Call Nordson Service for assistance. 0x6200u Message Device Validation Corrective Action Call Nordson Service for assistance.

  • Page 41: Test Ua Output

    Encore System Controller Operator Interface Help Guide 36 0x9001u Message Supply Undervoltage Corrective Action Check the DC power supply located in the pump controller. Measure power on SK2. If the voltage is less than 22 Vdc, replace the power supply in the pump controller.

  • Page 42: Glossary

    Encore System Controller Operator Interface Help Guide 37 Glossary Atomizing Air Dilutes and atomizes the powder stream, and increases its velocity, as it exits the pump. Electrode Air Wash Electrode air wash air continually washes the spray gun electrode to prevent powder from collecting on it.
