Endress+Hauser Micropilot FMR60B Brief Operating Instructions page 19

Micropilot FMR60B HART
Connection example of relay
 5 Connection example of relay
Connection example for the digital input
 6 Connection example for the digital input
1 Pull-up resistor
2 Digital input
Endress+Hauser
3+
R
+
i
-
4-
+
1
2
3+
R
i
4-
Electrical connection
A0015909
A0015910
19
