Replaceable Electrical Parts
Replaceable Electrical Parts List (Cont.)
Component Tektronix
Number Part Number
A1U21 156–0470–02
A1U22 156–2141–00
A1U23 156–2141–00
A1U24 160–8615–00
A1U24 160–8615–01
A1U24 160–8615–00
A1U24 160–8615–01
A1U24 160–8615–02
136–0925–00
A1U25 160–8609–00
136–0755–00
A1U26 156–1998–00
A1U27 160–8764–00
136–0925–00
A1U28 160–8616–00
A1U28 160–8616–01
A1U28 160–8616–02
A1U28 160–8616–00
A1U28 160–8616–01
A1U28 160–8616–00
A1U28 160–8616–01
A1U28 160–8616–02
A1U28 160–8616–01
A1U28 160–8616–02
136–0925–00
8–24
www.valuetronics.com
Serial No. Serial No.
Effective Discont'd
Name & Description
IC,DIGITAL:LSTTL,MUX/ENCODER
IC,DIGITAL:LSTTL,SHIFT REGISTER;8–BIT, WITH
IC,DIGITAL:LSTTL,SHIFT REGISTER;8–BIT, WITH
B010100 B010112 IC,DGTL:CMOS,PLD;OPT,DUAL CLK,16MACROCELL,35NS
(STANDARD ONLY)
B010113 B010229 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(STANDARD ONLY)
B010100 B010112 IC,DGTL:CMOS,PLD;OPT,DUAL CLK,16MACROCELL,35NS
(OPTION 1J ONLY)
B010113 B010229 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(OPTION 1J ONLY)
B010230 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(STANDARD AND OPTION 1J ONLY)
*MOUNTING PARTS*
SOCKET,DIP:PCB;24 POS,2 X 12,0.1 X 0.3 CTR,0.196 H X 0.130
TAIL,BECU,TIN,ACCOM 0.008–0.015THRU 0.014 X 0.022 LEADS
*END MOUNTING PARTS*
IC,MEMORY:CMOS,EPROM;16K X 8,150NS,27C128
*MOUNTING PARTS*
SOCKET,DIP:PCB;FEM,STR,2 X 14,28 POS,0.1 X 0.6 CTR,0.175
H X0.130 TAIL,BECU,TIN,ACCOM 0.008–0.0015 X 0.014–0.022
*END MOUNTING PARTS*
IC,DIGITAL:ALSTTL,FLIP FLOP;OCTAL D–TYPE, W/CLEAR
IC,MEMORY:CMOS,PROM;1K X 8,4ONS
*MOUNTING PARTS*
SOCKET,DIP:PCB;24 POS,2 X 12,0.1 X 0.3 CTR,0.196 H X 0.130
TAIL,BECU,TIN,ACCOM 0.008–0.015THRU 0.014 X 0.022 LEADS
*END MOUNTING PARTS*
B010100 B010112 IC,DGTL:CMOS,PLD;OPT,DUAL CLK,16MACROCELL,35NS
(STANDARD ONLY)
B010113 B020300 IC,DIGITAL:CMOS,PLD;OTP,EP610,35NS,37MHZ
(STANDARD ONLY)
B020301 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(STANDARD ONLY)
B010100 B010112 IC,DGTL:CMOS,PLD;OPT,DUAL CLK,16MACROCELL,35NS
(OPTION 1J ONLY)
B010113 IC,DIGITAL:CMOS,PLD;OTP,EP610,35NS,37MHZ
(OPTION 1J ONLY)
B020288 B020294 IC,DGTL:CMOS,PLD;OPT,DUAL CLK,16MACROCELL,35NS
(OPTION 1M ONLY)
B020295 B020300 IC,DIGITAL:CMOS,PLD;OTP,EP610,35NS,37MHZ
(OPTION 1M ONLY)
B020301 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(OPTION 1M ONLY)
B020288 B020300 IC,DIGITAL:CMOS,PLD;OTP,EP610,35NS,37MHZ
(OPTION 02 ONLY)
B020301 IC,DIGITAL:CMOS,PLD;OPT,DUAL CLOCK
(OPTION 02 ONLY)
*MOUNTING PARTS*
SOCKET,DIP:PCB;24 POS,2 X 12,0.1 X 0.3 CTR,0.196 H X 0.130
TAIL,BECU,TIN,ACCOM 0.008–0.015THRU 0.014 X 0.022 LEADS
VITS100 NTSC VITS Inserter Instruction Manual
Mfr.
Code
Mfr. Part Number
01295 SN74LS251N
01295 SN74LS597N
01295 SN74LS597N
80009 160861500
80009 160861501
80009 160861500
80009 160861501
80009 160861502
00779 2–641932–3
80009 160860900
09922 DILB28P–108
01295 SN74ALS273N
80009 160876400
00779 2–641932–3
80009 160861600
80009 160861601
80009 160861602
80009 160861600
80009 160861601
80009 160861600
80009 160861601
80009 160861602
80009 160861601
80009 160861602
00779 2–641932–3
