Replaceable Electrical Parts
Replaceable Electrical Parts List (Cont.)
Component Tektronix
Number Part Number
A1U40 156–1998–00
A1U40 156–1998–00
A1U41 160–8608–00
136–0925–00
A1U42 156–4150–00
136–0728–00
A1U43 156–4197–00
136–0755–00
A1U44 156–3131–00
A1U46 156–1191–01
A1U47 156–1226–01
A1U48 156–2093–00
A1U50 156–0853–00
A1U51 156–1173–00
A1U52 156–0277–00
A1U53 156–0846–00
A1U54 156–0316–04
A1U55 156–1640–00
A1U56 156–0158–07
A1U57 156–1707–00
A1U59 156–1367–00
A1U60 156–1850–00
A1U61 156–0158–07
A1U62 156–0316–04
A1U63 156–1640–00
A1U64 234–0428–20
136–0752–00
A1U65 155–0316–02
136–0871–00
A1U67 156–4150–00
8–26
www.valuetronics.com
Serial No. Serial No.
Effective Discont'd
Name & Description
*END MOUNTING PARTS*
B010100 B010229 IC,DIGITAL:ALSTTL,FLIP FLOP;OCTAL D–TYPE, W/CLEAR
(STANDARD ONLY)
B010100 B010229 IC,DIGITAL:ALSTTL,FLIP FLOP;OCTAL D–TYPE, W/CLEAR
(OPTION 1J ONLY)
IC,DIGITAL:CMOS,PLD;OPT,22V10,25NS,33.3MHZ,90MA
*MOUNTING PARTS*
SOCKET,DIP:PCB;24 POS,2 X 12,0.1 X 0.3 CTR,0.196 H X 0.130
TAIL,BECU,TIN,ACCOM 0.008–0.015THRU 0.014 X 0.022 LEADS
*END MOUNTING PARTS*
IC,LINEAR:BIPOLAR,AMPLIFIER;100MHZ,CURRENT
FEEDBACK,SAMPLE/HOLD,VIDEO DC RESTORATION
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCKT,14 CONTACT
*END MOUNTING PARTS*
IC,MISC:BIPOLAR,VIDEO SUBSYSTEM;ANALOG INTFC WITH
8–BIT,30MSPS A/D
*MOUNTING PARTS*
SOCKET,DIP:PCB;FEM,STR,2 X 14,28 POS,0.1 X 0.6 CTR,0.175
H X0.130 TAIL,BECU,TIN,ACCOM 0.008–0.0015 X 0.014–0.022
*END MOUNTING PARTS*
IC,MISC:BIPOLAR,VIDEO SUBSYSTEM;HORIZ SYNC
PROCESSOR
IC,LINEAR:BIFET,OP–AMP;6MV VOS
IC,LINEAR:BIPOLAR,COMPARATOR
IC,DIGITAL:ALSTTL,GATE;QUAD 2–INPUT OR
IC,LINEAR:BIPOLAR,OP–AMP;DUAL,SINGLESUPPLY
IC,LINEAR:BIPOLAR,V REF;POS,2.5V,1.0%,40PPM,SERIES
IC,LINEAR:BIPOLAR,VR;POSITIVE,5.0V,1.0A,4%
IC,LINEAR:BIPOLAR,VR;NEGATIVE,–5.0V,1.0A,4.0%
IC,DIGITAL:ECL,TRANSLATOR;QUAD ECL TOTTL
IC,DIGITAL:ECL,RECEIVER;TRIPLE LINE
IC,LINEAR:BIPOLAR,OP–AMP
IC,DIGITAL:FTTL,GATE;QUAD 2–INPUT NAND
IC,CONV:CMOS,D/A;8 BIT,400NS,CUR OUT,MPU COMPATIBLE
IC,MISC:CMOS,ANALOG SWITCH;QUAD
IC,LINEAR:BIPOLAR,OP–AMP
IC,DIGITAL:ECL,TRANSLATOR;QUAD ECL TOTTL
IC,DIGITAL:ECL,RECEIVER;TRIPLE LINE
QUICK CHIP:VIDEO CHANNEL SWITCH,PKG
*MOUNTING PARTS*
SKT,PL–IN ELEK:MICROCIRCUIT,20 DIP
*END MOUNTING PARTS*
IC,ASIC:BIPOLAR,12 BIT D/A CONV;FULL CUSTOM,M460
*MOUNTING PARTS*
SOCKET,PLCC:PCB;68 POS,0.05 CTR,0.360H X0.125
TAIL,TIN,0.1 CTRPCB,0.060 SHOULDER HEIGHT
*END MOUNTING PARTS*
IC,LINEAR:BIPOLAR,AMPLIFIER;100MHZ,CURRENT
FEEDBACK,SAMPLE/HOLD,VIDEO DC RESTORATION
VITS100 NTSC VITS Inserter Instruction Manual
Mfr.
Code
Mfr. Part Number
01295 SN74ALS273N
01295 SN74ALS273N
80009 160860800
00779 2–641932–3
64762 EL2090CN
09922 DILB14P–108
1CH66 TDA8708N
09922 DILB28P–108
1CH66 TDA2595N
01295 TL072ACP
1CH66 LM319N
01295 SN74ALS32N
01295 LM358P
04713 MC1403U
01295 UA7805CKC
27014 LM7905CT
04713 MC10125P
04713 MC10H116P
01295 MC1458P
04713 MC74F00N
24355 AD7524JN
17856 DG211CJ
01295 MC1458P
04713 MC10125P
04713 MC10H116P
TK2598 234042820
09922 DILB20P–108
TK2598 155031602
00779 3–821574–1
64762 EL2090CN
