- Page 1 The Visionary Eye Creating the Future Style of Manufacturing Non-contact 3D digitizer suitable for industrial applications requiring high accuracy and reliability...
-
Page 2: Konica Minolta
• Rapid prototyping • Creation of machining data • Digital mockup KONICA MINOLTA RANGE7 opens up the future possibilities of non-contact 3D measurement by adding the elements of increased reliability, improved operability and easier transportability to Konica Minolta's accumulated optical technologies and auto-focus function. - Page 3 SOLUTION KONICA MINOLTA RANGE7 will change the process of manufacturing. Problems can be solved by using KONICA MINOLTA RANGE7 and 3D CAD data, without the need for 2D drawings. The direct comparison of 3D scan data against 3D CAD data provides visual and quantitative evaluation of surface distortion and cross-sections of part exteriors, even those with multiple free-form surfaces.
- Page 4 The 3D preview function reduces erro- camera and controller neous measurements The KONICA MINOLTA RANGE7 is a new 3D digitizer series full The 3D preview function allows users to predict measurement of 3D digitizing know-how accumulated from Konica Minolta's results quickly. With a pre-scan of only 0.4 seconds, users can over 10 years of experience.
- Page 5 USABILITY The newly developed software RANGE VIEWER allows comfortable scanning operations. The software, designed specifically for KONICA MINOLTA RANGE7, makes the process from scanning to data integration quick and easy. User-friendly software with navigation messages Navigation message "RANGE VIEWER" is newly developed 3D data processing software included as standard.
- Page 6 RELIABLE Toward new horizons for optical 3D digitizers The KONICA MINOLTA RANGE7 boasts high accuracy and reliability. Points Konica Minolta Sensing cannot compromise as a manufacturer of measuring instruments. Stable scanning with light sectioning High measurement accuracy based on method...
- Page 7 VERSATILE Increased mobility and operability of the compact, lightweight KONICA MINOLTA RANGE7 Various accessories specifically designed for KONICA MINOLTA RANGE7 offer flexible system configuration according to the application and operating environment. Measuring Stand Set with laptop shelf Rotating Stage Kit (3 kg/20 kg)
-
Page 8: System Configuration
Specifications and appearance shown herein subject to change without notice. • surement target: Konica Minolta standard planar chart; Software used: Konica Minolta processing software; 1 σ value Company names and product names used herein are trademarks or registered trademarks of their respective com- •...
