MODEL DP1050
10-INCH 5-SPEED
DRILL PRESS
Instruction Manual
NEED HELP? CONTACT US!
Have product questions? Need technical support? Please feel free to contact us:
1-847-429-9263 (M-F 8AM-5PM CST)
TECHSUPPORT@WENPRODUCTS.COM
IMPORTANT: Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use
your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
WENPRODUCTS.COM
For replacement parts and the most up-to-date instruction manuals, visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP1050 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen DP1050

Summary of Contents for Wen DP1050

  • Page 1 1-847-429-9263 (M-F 8AM-5PM CST) TECHSUPPORT@WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    CONTENTS WELCOME Introduction ......................3 Specifications ....................3 SAFETY General Safety Rules ..................4 Drill Press Safety Warnings ................6 Electrical Information ..................8 BEFORE OPERATING Know Your Drill Press ..................9 Assembly & Adjustments ................10 OPERATION & MAINTENANCE Operation ......................17 Maintenance ....................19 Troubleshooting Guide ..................20 Exploded View &...

  • Page 3: Welcome

    INTRODUCTION Thanks for purchasing the WEN Drill Press. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. Safe operation of this tool requires that you read and understand this operator’s manual and all the labels affixed to the tool.

  • Page 4: Safety

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 5: California Proposition 65 Warning

    GENERAL SAFETY RULES WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Safety is a combination of common sense, staying alert and knowing how your item works. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

  • Page 6: Drill Press Safety Warnings

    DRILL PRESS SAFETY WARNINGS WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This drill press is designed to drill through metal wood, plastic, and tiles. Drilling through other materials could result in fire, injury, or damage to the workpiece.
  • Page 7 SPECIFIC RULES FOR THE DRILL PRESS DRILL PRESS SAFETY WARNINGS WARNING! Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 12. DRILLING THE WORKPIECE. •...

  • Page 8: Grounding Instructions

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS In the event of a malfunction or breakdown, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 9: Before Operating

    KNOW YOUR DRILL PRESS TOOL PURPOSE Drill presses are mainly used to drill clean, precise cylindrical holes into workpieces or enlarge existing holes. You may also find other uses for your drill press such as reaming, countersinking, counterboring, tapping, etc. Refer to the diagram below to become familiarized with the parts and controls of your drill press.

  • Page 10: Packing List

    ASSEMBLY & ADJUSTMENTS UNPACKING With the help of a friend or trustworthy foe, carefully remove the drill press from the packaging. Make sure to take out all contents and accessories. Do not discard the packaging until the drill press is completely assembled. Before using the drill press, you must assemble the unit using the instructions in this section.
  • Page 11 ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according on the instructions. Failure to follow the safety instructions may result in serious personal injury. ATTACHING THE COLUMN TO THE BASE Fig.
  • Page 12 ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according on the instructions. Failure to follow the safety instructions may result in serious personal injury. ATTACHING THE HEAD ASSEMBLY TO THE COLUMN Fig.

  • Page 13: Installing The Chuck

    ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according on the instructions. Failure to follow the safety instructions may result in serious personal injury. INSTALLING THE CHUCK Fig. 7 1. Unlock the table lock handle and raise the drill press table within 6 in.

  • Page 14: Adjusting The Table

    ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according on the instructions. Failure to follow the safety instructions may result in serious personal injury. ADJUSTING THE TABLE Fig. 8 1. To adjust the table around the column, loosen the table locking handle (Fig.

  • Page 15: Adjusting The Belt Tension

    ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according on the instructions. Failure to follow the safety instructions may result in serious personal injury. ADJUSTING THE BELT TENSION Fig. 10 1.

  • Page 16: Laser Alignment

    ASSEMBLY & ADJUSTMENTS WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Failure to follow the safety instructions may result in serious personal injury. RECOMMENDED SPEED FOR DRILL SIZE & MATERIAL Alum.

  • Page 17: Operation & Maintenance

    OPERATION TURNING THE DRILL PRESS ON / OFF Fig. 14 1. Make sure that the drill press is fully assembled according to the assembly instructions. 2. Plug the drill press into the power source. 3. To turn the drill press ON, insert the safety key (Fig. 14 - 1) into the ON / OFF switch (Fig.

  • Page 18: Drilling Metal

    OPERATION DRILLING METAL • Use metal-piercing twist drill bits. • It is always necessary to lubricate the tip of the drill with oil to prevent overheating of the drill bit. • All metal workpieces should be clamped down securely. Any tilting, twisting, or shifting causes a rough drill hole, and increases the potential of drill bit breakage.

  • Page 19: Product Disposal

    WARNING! Any attempt to repair or replace electrical parts on this tool may be hazardous. Servicing of the tool must be performed by a qualified technician. When servicing, use only identical WEN replacement parts. Use of other parts may be hazardous or induce product failure.

  • Page 20: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at 1-847-429-9263, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM CAUSE SOLUTION...
  • Page 21 TROUBLESHOOTING GUIDE WARNING! Stop using the tool immediately if any of the following problems occur. Repairs and replacements should only be performed by an authorized technician. For any questions, please contact our customer service at 1-847-429-9263, M-F 8-5 CST or email us at techsupport@wenproducts.com. PROBLEM CAUSE SOLUTION...

  • Page 22: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST...
  • Page 23 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. DP1050-001 Circlip, 22mm 4212B-029 Handle Fixed Piece DP1050-002 Spindle Pulley DP1050-044 Handle Hub DP1050-003 Spindle Pulley Shaft DP1050-045 V-Belt, K-30, 750x8 DP1050-004 Bearing, 6203-2RZ 4225-138 Label Rivets...
  • Page 24 EXPLODED VIEW & PARTS LIST Part No. Description Qty. Part No. Description Qty. DP1050-077 Chuck Key DP1050-100 Power Cord DP1050-078 Rack Collar DP1050-101 Column 4225-153 Hex Wrench, 3mm DP1050-102 Hex Bolt. M8x20 4225-156 Hex Wrench, 4mm DP1050-103 Manual DP1050-081 Table Locking Handle...

  • Page 25: Warranty Statement

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
  • Page 26 NOTES...
  • Page 27 NOTES...
  • Page 28 THANKS FOR REMEMBERING V. 2024.10.21...
