Summary of Contents for Wen 2307
-
Page 2: Table Of Contents
Using the Attachments……………………………………. 8 Using the ROTARY TOOL KIT…………………………. 9 Maintenance………………………………………………. 9 Exploded View and Parts List……………………………. 10 Warranty………………………………………………….. 11 TECHNICAL DATA ROTARY TOOL KIT MODEL: 2307 RATING: 120V, 60Hz, AC only INPUT: 1.0AMP NO LOAD SPEED: 8,000-30,000 rpm COLLET SIZE: Supplied with 3/32"... -
Page 3: Rules For Safe Operation
IMPORTANT Servicing requires extreme care and knowledge and should be performed only by a qualified service ® technician. For service we suggest you return the tool to WEN PRODUCTS a division of Great ® Lakes Technologies, LLC for repair. When servicing, use only identical WEN replacement parts. - Page 4 Keep children and visitors away. All visitors should wear ANSI-Z87.1 approved safety glasses and be kept a safe distance from work area. Make workshop childproof with padlocks, master switches, or by removing starter keys. Don‟t force the tool. It will do the job better and safer at the rate for which it was designed. ...
-
Page 5: Extension Cords
Replacement parts. All repairs, whether electrical or mechanical, should be made by a qualified service technician at an authorized service center. ® WARNING: when servicing use only identical WEN replacement parts. Use of any other parts may create a hazard or cause product damage... -
Page 6: Specific Safety Rules For Rotary Tool Kit
Use only three (3) wire extension cords that have three (3) prong grounding plugs, and three (3) pole receptacles that accept the tool‟s plug. AMERICAN WIRE GAUGE RATING CHART EXTENSION CORD LENGTH (FEET) AMPS 0 to 10.0 10.1 to 13.0 13.1 to 15 15 to 18 Class II construction double insulated. -
Page 7: List Of Accessories (100 Sets)
LIST OF ACCESSORIES (100 pieces) Bit changing spanner wrench 2 felt polishing wheels 2 high speed cutters 10 grinding stones 54 sanding discs 1 dressing stone 20 cut-off wheels 4 sander bands ... -
Page 8: Using The Attachments
Low Speed uses: Certain materials (some plastics) require a relatively slow speed because at high speed the friction of the tool generates heat and causes the plastic to melt. Slow speeds usually are best for polishing operations employing the felt polishing accessories. They may also be for working on delicate projects. -
Page 9: Using The Rotary Tool Kit
Sanding Disc Arbor 1. To fit a disc to the Sanding Disc Arbor, unscrew the fitting screw. 2. Remove the screw and washer. 3. Place the required disc over the end of the arbor. 4. Replace the washer and screw. 5. -
Page 10: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST Part# Stock # Description 2307-001 COLLET NUT 2307-002 BRASS COLLET 2307-003 BEARING 626zz 2307-004 ROTOR 2307-005 BEARING 698zz 2307-006 STATOR 2307-007 PREVENT SPRING 2307-008 SPINDLE LOCK BUTTON 2307-009 LOCKING SLEEVE 2307-010 BRUSH 2307-011 BRUSH SPRING... -
Page 11: Warranty
GREAT LAKES TECHNOLOGIES, LLC ("Seller") warrants to the original purchaser only, that all WEN consumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase. Ninety days for all WEN products, if the tool is used for professional use.
