TRAK RACER MS-CM-QD2 Assembly Manual

Single monitor stand with overhead monitor stand
Hide thumbs

Advertisement

Quick Links

Download this manual
Single Monitor Stand with
Overhead Monitor Stand
Assembly Guide
tooltip
IMPORTANT: Different regions may have different models. Please ensure
the part number below matches that on your product's box.
MS-CM-QD2
Published 2024-12-30
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS-CM-QD2 and is the answer not in the manual?

Questions and answers

Related Manuals for TRAK RACER MS-CM-QD2

Summary of Contents for TRAK RACER MS-CM-QD2

  • Page 1 Single Monitor Stand with Overhead Monitor Stand Assembly Guide tooltip IMPORTANT: Different regions may have different models. Please ensure the part number below matches that on your product's box. MS-CM-QD2 Published 2024-12-30...
  • Page 2 TABLE OF CONTENTS Symbol Legend Assembly Notes MS-FS-SIN6 TR80-4M4 TR80-TMARM5 MS-FS-QD2...
  • Page 3 IMPORTANT: Since there are different versions of each product based on your region, please make sure you are using the correct set of instructions. The part number below should match the one on your box. IMPORTANT: Due to the nature of cut aluminum profiles, some metal shavings may remain despite our thorough QA cleaning process.
  • Page 4 NOTE TOP SIDE tooltip INSIDE OUTSIDE FRONT SIDE INSTALLATION ORDER FOR SCREWS & WASHERS HOW TO MEASURE SCREWS ① SCREW ② LOCK WASHER ③ WASHER (IF APPLICABLE) FLAT SCREW HEX SCREW BUTTON SCREW If you have any issues, please contact us at support@trakracer.com...
  • Page 5 NOTE NS-M8 & NS-M6 Slide T-Nuts into the ends of the profiles. Some must be added early, so follow the steps in this manual carefully. If you miss one, tilt it in from the outer edge. Use the Allen key to push it into place, ensuring the hole lines up.

  • Page 6: Part Lists

    MOUNTED SINGLE MONITOR STAND - 580MM / 22.8” WIDE tooltip PART LISTS tooltip tooltip tooltip 300mm 330mm 540mm Aluminum Profile Aluminum Profile Aluminum Profile Aluminum Profile TR-8080-300 TR-8080-330 TR-8080-540 TR-80B tooltip tooltip tooltip tooltip tooltip 40x40 End Cap, 40x40 Logo Bracket Connecting Part TV Vesa Mount EC-40...
  • Page 7 tooltip tooltip SF-M8-20 TR-8080-300 tooltip 300mm M8x20mm tooltip tooltip tooltip NS-M8 SF-M8-20 tooltip M8x20mm Join part from Step 1 to side bracket ( L & R ) tooltip Side Bracket...
  • Page 8 tooltip tooltip tooltip M8-LN NS-M8 TR-8080-540 TR-8080-330 tooltip tooltip 540mm 330mm 100mm tooltip SH-M8-20 WL-M8 WL-M8-20 tooltip M8x20mm M8x20mm tooltip Use part from step 3 tooltip...
  • Page 9 WL-M8 HF-M8-20 NS-M8 WF-M8-20 tooltip M8x20mm M8x20mm tooltip Use parts from step 4 & 2 tooltip tooltip M-SB SF-M6-16 NL-M6 tooltip tooltip M6x16mm tooltip Part ‘A’ has 2 side variations tooltip...
  • Page 10 WL-M8 WL-M8 HF-M8-20 NS-M8 tooltip M8x20mm M8x20mm Slide ‘D’ to the middle tooltip First. EC-80 tooltip tooltip tooltip...

  • Page 11: Vesa Mount

    Overhead Monitor Stand with tooltip VESA mount PART LISTS tooltip 400mm 500mm 500mm Aluminum Profile Aluminum Profile Aluminum Profile Aluminum Profile TR-8040-400 TR-8040-500 TR-8080-500 TR-80B tooltip tooltip tooltip tooltip tooltip tooltip tooltip tooltip 40x40 End Cap, 40x40 Corner Bracket Angle Adjust Part TV Vesa Mount EC-40 VM-1...
  • Page 12 CB-01 SH-M8-16 NS-M8 TR-8040-500 tooltip tooltip tooltip tooltip tooltip 500mm M8x16mm tooltip First slide ‘D’ into position tooltip WF-M8 WL-M8 SH-M8-20 NS-M8 BM-QA tooltip tooltip tooltip M8x20mm ooltip First slide ‘D’ into position tooltip...
  • Page 13 M-SB SF-M6-16 NL-M6 tooltip tooltip tooltip tooltip M6x16mm Part ‘A’ has 2 side variations tooltip tooltip WL-M8 SH-M8-20 NS-M8 TR-8080-500 WF-M8-20 tooltip M8x20mm 500mm tooltip Adjust according to Liking/size. tooltip...
  • Page 14 SH-M8-16 NS-M8 BC-40 WF-M8-20 tooltip tooltip tooltip M8x20mm M8x16mm Use parts from step 4 & 2 tooltip SH-M8-16 NS-M8 TR-8040-400 WF-M8-20 tooltip tooltip tooltip M8x20mm M8x16mm 400mm tooltip...
  • Page 15 WL-M8 SH-M8-20 NS-M8 WF-M8-20 tooltip M8x20mm M8x20mm tooltip Adjust position angle To liking. tooltip BC-40-CAP EC-40 tooltip...
  • Page 16 Arms for Tripple Monitors with VESA mount PART LISTS tooltip tooltip tooltip tooltip 580mm Aluminum Profile Bracket (Plate) BM-TA End Cap TR-8040-580 BM-TA BP-IS EC-80 tooltip tooltip tooltip Vesa Mount Washer (Flat), M8x20 Nut, M6 Washer (Lock), M8 VB-03 NL-M6 WF-M8 WL-M8 tooltip...
  • Page 17 SH-M8-20 NS-M8 BM-TA TR-8040-580 WF-M8-20 tooltip tooltip 580mm 580mm M8x20mm tooltip This step can also be done with Step 5 tooltip M-SB SF-M6-16 NL-M6 tooltip tooltip tooltip tooltip Part ‘A’ has 2 side variations tooltip...
  • Page 18 WL-M8 SH-M8-20 NS-M8 WF-M8-20 tooltip M8x20mm M8x20mm tooltip Slide parts ‘D’ to allign it first tooltip EC-80 tooltip tooltip Use part from step 3 tooltip...
  • Page 19 Triple Monitor Stands with Overhead Monitor Stand tooltip tooltip tooltip MS-CM-SIN2 TR80-4M4 TR80-TMARM5 PART LISTS tooltip tooltip M8X16mm M8x20mm Ball Bearing Nut Hex Screw Washer (Flat) Washer (Lock), M8 NS-M8 SH-M8-16 WL-M8-20 WL-M8 M8X20mm Hex Screw SH-M8-20 NOTE: Some screws and washers may be pre-installed. These are included in the parts list and will need to be loosened and reattached according to the instructions.
  • Page 20 SH-M8-16 NS-M8 tooltip M8x16mm tooltip tooltip Slide ‘B’ to the position Remove End cap and slide First. ‘C’ in each side first Slide ‘B’ to the position Slide ‘B’ to the position First. First. tooltip WF-M8-20 WL-M8 SH-M8-20 M8x20mm M8x20mm tooltip...
  • Page 21 WF-M8-20 WL-M8 SH-M8-20 NS-M8 tooltip M8x20mm M8x20mm tooltip tooltip IMPORTANT: If your monitor screws are under 8mm (M8), you will need to use washers (not supplied) tooltip...
  • Page 22 FINISHED...
