TRAK RACER MS-CM-SIN2 Assembly Manual

Mounted single monitor stand

Advertisement

Quick Links

MOUNTED SINGLE MONITOR
STAND - 580MM / 22.8" WIDE
Assembly Guide
IMPORTANT: Different regions may have different models. Please ensure
the part number below matches that on your product's box.
MS-CM-SIN2
Published 2024-6-26
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS-CM-SIN2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TRAK RACER MS-CM-SIN2

  • Page 1 MOUNTED SINGLE MONITOR STAND - 580MM / 22.8” WIDE Assembly Guide IMPORTANT: Different regions may have different models. Please ensure the part number below matches that on your product's box. MS-CM-SIN2 Published 2024-6-26...
  • Page 2 TABLE OF CONTENTS Symbol Legend Part List Assembly Notes Assembly Instructions...
  • Page 3 IMPORTANT: Since there are different versions of each product based on your region, please make sure you are using the correct set of instructions. The part number below should match the one on your box. IMPORTANT: Due to the nature of cut aluminum profiles, some metal shavings may remain despite our thorough QA cleaning process.
  • Page 4: Part Lists

    PART LISTS tooltip tooltip tooltip 300mm 330mm 540mm Aluminum Profile Aluminum Profile Extended Film Aluminum Profile TR-8080-300 TR-8080-330 TR-8080-540 TR-80B tooltip End Cap, Logo Bracket TV Vesa Mount Connecting Part EC-80 VM-1 CP-1 tooltip Package Monitor Side Bracket Logo Sticker CP-3...
  • Page 5 PART LISTS NOTE: Some screws and washers may be pre-installed. These are included in the parts list and will need to be loosened and reattached according to the instructions. M8x20mm Washer (Lock), M8 Ball Bearing Nut Ball Bearing Nut, M8 Washer (Flat) M6 Nut NS-M8...
  • Page 6 NOTE TOP SIDE INSIDE FRONT SIDE OUTSIDE INSTALLATAION ORDERFOR SCREWS HOW TO MEASURE SCREWS ① SCREW ② LOCK WASHER ③ WASHER (IF APPLICABLE) FLAT SCREW HEX SCREW BUTTON SCREW...
  • Page 7 NOTE NS-M8 & NS-M6 Slide T-Nuts into the ends of the profiles. Some must be added early, so follow the steps in this manual carefully. If you miss one, tilt it in from the outer edge. Use the Allen key to push it into place, ensuring the hole lines up.
  • Page 8 tooltip SF-M8-20 TR-8080-300 300mm 300mm M8x20mm NS-M8 SF-M8-20 tooltip M8x20mm Join part from Step 1 to side bracket ( L & R ) Side Bracket...
  • Page 9 M8-LN NS-M8 TR-8080-540 TR-8080-330 540mm 330mm 100mm tooltip BC-40 SH-M8-20 WL-M8 WL-M8-20 M8x20mm M8x20mm tooltip Use part from step 3...
  • Page 10 WL-M8 HF-M8-20 NS-M8 WF-M8-20 M8x20mm M8x20mm tooltip Use parts from step 4 & 2 tooltip M-SB SF-M6-16 M6-LW tooltip M6x16mm Part ‘A’ has 2 side variations...
  • Page 11 WL-M8 HF-M8-20 NS-M8 WL-M8-20 M8x20mm M8x20mm Slide ‘D’ to the middle First. EC-80...
  • Page 12 FINISHED...
