- Page 1 Floor Single Monitor Stand with VESA mount (120mm Crossbar) Assembly Guide IMPORTANT: Different regions may have different models. Please ensure the part number below matches that on your product's box. MS-FM-SIN6 Published 2024-6-26...
- Page 2 TABLE OF CONTENTS Symbol Legend Part List Assembly Notes Assembly Instructions...
- Page 3 IMPORTANT: Since there are different versions of each product based on your region, please make sure you are using the correct set of instructions. The part number below should match the one on your box. IMPORTANT: Due to the nature of cut aluminum profiles, some metal shavings may remain despite our thorough QA cleaning process.
-
Page 4: Part Lists
PART LISTS tooltip tooltip tooltip 600mm 540mm 380mm Aluminum Profile Aluminum Profile Aluminum Profile Aluminum Profile TR-4080-600 TR-4080-540 TR-4080-380 TR-80B tooltip tooltip tooltip tooltip tooltip 40x40 End Cap, 40x40 Connector Part Connecting Part TV Vesa Mount EC-40 VM-1 CP-2 CP-1 tooltip tooltip Logo Bracket... - Page 5 PART LISTS NOTE: Some screws and washers may be pre-installed. These are included in the parts list and will need to be loosened and reattached according to the instructions. tooltip tooltip M8x20mm M8x16mm Washer (Lock), M8 Ball Bearing Nut Ball Bearing Nut, M8 Washer (Flat) Washer (Flat) NS-M8...
- Page 6 NOTE ltip TOP SIDE INSIDE OUTSIDE FRONT SIDE INSTALLATION ORDER FOR SCREWS & WASHERS HOW TO MEASURE SCREWS ① SCREW ② LOCK WASHER ③ WASHER (IF APPLICABLE) FLAT SCREW HEX SCREW BUTTON SCREW If you have any issues, please contact us at support@trakracer.com...
- Page 7 NOTE T-NUTS It is strongly advised that spring T-Nuts are inserted by sliding from the ends of profiles. Please take careful note of each step of all T-nuts as some are to be installed in anticipation of future steps. If T-Nuts are skipped, and the ends are no longer accessible, they can be inserted by “rocking”...
- Page 8 NS-M8 SH-M8-20 FR-01 WF-M8 TR-4080-600 tooltip tooltip 600mm M8x20mm tooltip Warning: Using the stand without The rubber feet may cause Damage to your floor tooltip tooltip M8-LN TR-4080-600 tooltip 600mm 330mm tooltip Place the long nuts (M8-LN) into the slots of two aluminum profiles (AL-8080-600) (front and back).
- Page 9 tooltip CP-3 CP-2 SH-M8-20 WL-M8 WF-M8-20 tooltip M8x20mm M8x20mm tooltip Ensure as you tighten the long nuts (M8-LN) that the aluminum profiles (AL-8040-600) stay flat to one another and in place. It helps if you tighten and hold onto one side of the leg only. tooltip BC-40 NS-M8...
- Page 10 NS-M8 SH-M8-20 WL-M8 tooltip WF-M8-20 tooltip tooltip M8x20mm M8x20mm tooltip Position the corner bracket toward the back of the ‘foot’, approximately 1cm or ½” from the end. tooltip tooltip tooltip tooltip M8-LN TR-4080-540 TR-4080-330 540mm 330mm 100mm tooltip Slide 4 long nuts (M8-LN) into the back, and 2 into the bottom of the aluminum profile (AL-4080 -540).
- Page 11 BC-40 SH-M8-20 WL-M8 WL-M8-20 tooltip M8x20mm M8x20mm tooltip Ensure as you tighten the long nuts (M8-LN) that the aluminum profiles stay flat to one another and in place. It helps if you tighten and hold onto one piece of aluminum profiles at one time as you tighten.
- Page 12 NS-M8 SH-M8-20 WL-M8 WF-M8-20 tooltip M8x20mm M8x20mm Position the part from step 7 onto the ‘legs’ from step 5 and secure by tightening. You may decide to tooltip adjust the height depending on your monitor height preference. tooltip M-SB TR-80B SF-M6-16 M6-LW tooltip...
- Page 13 NS-M8 SH-M8-20 WL-M8 WF-M8-20 tooltip M8x20mm M8x20mm Slide 3 x T Nuts into the top of the horizontal monitor mount tooltip then position the parts from Step 10 in the center of the profile and screw down tight. tooltip EC-40 EC-40 tooltip tooltip...
- Page 14 IMPORTANT: If your monitor screws are smaller than 8mm (M8), you will need to use washers (not supplied) to secure the screw to the VESA TV bracket.
- Page 15 FINISHED...
