Owner's Manual
Fixed Flat-Screen
Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY
DAMAGE MAY OCCUR!
150x100 / 150x150 /
200x100 / 200x200 /
200x400 / 300x200 /
300x300 / 350x350 /
400x200 / 400x300 /
400x400 / 600x200 /
600x300 / 600x400
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Eaton по адресу: Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:
Tripplite.Eaton.com/support
80"
MAX
PRODUCT REGISTRATION
Register your product today for a
chance to win an ISOBAR
surge
®
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
Model:
DWF3780X
165 lb.
165 lb.
(75 kg)
(75 kg)
MAX
MAX
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRIPP LITE DWF3780X and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP LITE DWF3780X

Summary of Contents for Eaton TRIPP LITE DWF3780X

  • Page 1 600x300 / 600x400 Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support Русскоязычная версия настоящего руководства представлена на веб-сайте компании Eaton по адресу: Tripplite.Eaton.com/support Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:...

  • Page 2: Important Safety Instructions

    PRODUCT REGISTRATION Visit Tripplite.Eaton.com/warranty today to register your new product. You’ll be automatically entered into a drawing for a chance to win a FREE Eaton Tripp Lite series product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit Tripplite.Eaton.com/support for service. M5x6 (x3) (x1) (x1) (x6) (x1) (x1) Package M M6x25 M8x45 M5x14...
  • Page 4 Assembly Assemble the Wall Plate...
  • Page 5 Assembly Mount on Wood Stud Wall 50mm 50mm (2.2") (2.2") O 4.5mm O 4.5mm (O 3/16") (O 3/16") Find and mark the exact location of mounting holes Drill pilot holes Screw the assembled wall plate onto the wall WARNING • Make sure mounting screws are anchored into the center of the studs.
  • Page 6 Assembly Mount on Solid Brick and Concrete Block 60mm 60mm (2.4") (2.4") O 10mm O 10mm (O 3/8") (O 3/8") Mark the exact location of mounting holes Drill pilot holes Screw the assembled wall plate onto the wall WARNING • When installing wall mounts onto a concrete masonry unit (also known as a CMU or “cinder block”), verify that the actual concrete thickness is at least 35mm (1-3/8”)
  • Page 7 Assembly Install Adapter Brackets Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. • Screw the adapter brackets onto the display. Firmly secure all screws.
  • Page 8 Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit Tripplite.Eaton.com/support if you have any questions. Eaton 1000 Eaton Boulevard Cleveland, OH 44122 United States Eaton.com...
