HULALA HOME SBHM0840 Manual

Hide thumbs

Advertisement

Table of Contents

HULALA
H
O
M
E
SBHM0840
ITEM NO.
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBHM0840 and is the answer not in the manual?

Questions and answers

Related Manuals for HULALA HOME SBHM0840

Summary of Contents for HULALA HOME SBHM0840

  • Page 1 HULALA SBHM0840 ITEM NO. NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/20...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3 2PERSONEN 03/20...

  • Page 4: Parts List

    PARTS LIST 04/20...

  • Page 5: Hardware List

    HARDWARE LIST Ø 3.5*35mm*7 Ø3*14mm*6 Ø1/4 Ø1/4 Ø3.5*14m*7 Ø3.5*20mm*8 Ø1/4*1-3/4 Ø1/4 Ø3*16m*6 TOOL LIST HARDWARE SPARE LIST 05/20...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.picture shows.Use bolt #3 to attach rebound device #11 to top panel A ， tighten bolts with screwdriver #15. #11*2 06/20...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Insert gasket #5 and #4 in sequence into screw #7, install leg I on of bottom panel B, ensure the corresponding holes are aligned and fix with screw #7, then tighten the screw with an Allen key #14. 07/20...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Insert side panel (C ＆ D) into bottom panel (B),make sure all holes aligned and then tighten it with allen key #14 as picture show. 08/20...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.Insert top panel(A) into the corresponding hole of preassembled step 3 ， make sure all holes aligned and use allen key #14 to tighten it as picture show. 09/20...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Open the back panel (E),insert back panel(E) into the groove of preassembled step 4,make sure all holes aligned and use screw#2 to attach them ，tighten screw #2 with screwdriver #2*16 10/20...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.Attention:After installation, adjust the adjustable leveler to keepthe cabinet balanced . Attention: After installation, adjust the adjustable leveler to keep the cabinet balanced . 11/20...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Insert shelf holder #8 into the corresponding hole of panel (C)&(D) and then attach panel (F） to it. Shelf holder can be adjusted up or down Ø1/4 12/20...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1.Use screw #1 to attach hinge #13 to door (G)&(H) , tighten screw #1 with screwdriver #15 . #13x4 13/20...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 1.Use screw #1 to attach left door (G) and right door (H) to pre-assemble unit at step 7 ,tighten screw with screwdriver #15. D&C G&H D&C H&G 14/20...
  • Page 15 ASSEMBLY INSTRUCTIONS Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 15/20...
  • Page 16 ASSEMBLY INSTRUCTIONS Attention: If the door looks over out or over in,you can adjust the head rebounder as image. G&H 16/20...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 to attach part #12 to back panel(E),tighten screw #16 with Use screw screwdriver #15 . #16x4 17/20...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP-13 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part#12 on the back of panel (E); Drill and insert the expandable screw by hammer. Assemble the part #12 to the wall. Align the hole in the part #12 with the expandable screw #9 , use screw #6 to attach it and tighten by screwdriver#15.
  • Page 19 ASSEMBLY INSTRUCTIONS #10 x2 STEP-14 Let the plastic belt #10 pass through the both part #12 and pull tightly. #10x2 #10x2 19/20...

  • Page 20: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
