VEVOR ZPJ-25A-6 Manual

VEVOR ZPJ-25A-6 Manual

Concretescreed
Hide thumbs Also See for ZPJ-25A-6:

Advertisement

Quick Links

Download this manual
Technical Support and E-Warranty Certificate www.vevor.com/support
CONCRETE SCREED
MODEL:ZPJ-25A-6、ZPJ-25A-8、ZPJ-25A-11
ZPJ-25A-6/8/11
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZPJ-25A-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VEVOR ZPJ-25A-6

Summary of Contents for VEVOR ZPJ-25A-6

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support CONCRETE SCREED MODEL:ZPJ-25A-6、ZPJ-25A-8、ZPJ-25A-11 ZPJ-25A-6/8/11 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 3 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 4: Important Safeguards

    IMPORTANT SAFEGUARDS WARNING: Read and understand this entire manual before operating or servicing this product. Failure to follow these warnings and instructions can cause personal injury or damage to valuable property. Intended Use This screed uses vibration through a screed board to embed aggregate and reduce air voids in concrete, making the slabs stronger.

  • Page 5: Work Area Safety

    and caution when using this tool. Always be aware of the environment and ensure that the tool is used in a safe and responsible manner. • DO NOT allow persons to assemble or operate this product until they have read this manual and have developed a thorough understanding of how the product works.

  • Page 6: Personal Safety

    • Do not use the Screed where there is a risk of causing a fire or an explosion; e.g., in the presence of flammable liquids, gases, or dust. • Do not allow the tool to come into contact with an electrical source. The tool is not insulated, and contact will cause electrical shock.

  • Page 7: Specific Operation Warnings

    • Engine exhaust contains carbon monoxide.This is a poison you can not see or smell. NEVER use. SCREED USE AND CARE • Do not force the Screed to perform an operation other than its intended use. Screeds do a better and safer job when used in the manner for which they are designed.
  • Page 8 • Do not run the engine in enclosed areas to prevent carbon monoxide poisoning. To protect the operator • When fatigue from operation, the operator must stop the machine and take break. • Hearing protection is required as this machine creates a noise emission while 1 m (3 feet)away from the equipment.
  • Page 9 operator. Do not leave the defects which may cause serious injury of the operator. • Do not operate the screed when a defect endangers the safety of the operator until the defect is rectified. • The screed has to be checked by an expert on a regular basis (at least once a year).
  • Page 10 Attach washers, locking screws, Line up blade with assembly. and bolts. Connect accelerator cable to Repeat Step 2 for the second hole. engine. Locate accelerator screw found on Tighten and make sure that when engine and place cable through the you pull accelerator handle, the gap.

  • Page 11: Before Each Use

    Dimension Model L(mm) W(mm) H(mm) ZPJ-25A-6 1830 730-1060 ZPJ-25A-8 2445 730-1060 ZPJ-25A-11 3370 730-1060 ZPJ-25A-6/8/11 3370 730-1060 Before Each Use Preparation for operation 1)Check all bolts, nuts, and bolts and tighten any that are loose. - 9 -...
  • Page 12 2)Get the desired length of screed board. Recommended Fuel 1)The screed engine requires regular unleaded gasoline. Use only fresh, clean fuel. Fuel containing water or dirt will damage the fuel system. Consult engine owner’s manual for complete fuel specifications Before starting Engine 1)Read and understand the safety and operating instructions manual for the engine.
  • Page 13 3.Press the priming bulb repeatedly until fuel can be seen inside the clear plastic bulb. 4.Move the throttle lever slightly in the direction of the arrow. 5.Pull the starter rope (Figure 03) lightly until you feel resistance, then pull briskly in the direction of the arrow. Return the starter rope gently. 6.Once the engine has started, open the choke and allow engine to idle for 3 to 5 minutes to warm-up.

  • Page 14: After Each Use

    Operation Read and understand both the engine and compactor user’s manuals before starting or operating the compactor to avoid incorrect operation that may result in damage or injury. Note:When ever high speed operation is NOT required, slow the engine by moving the throttle lever to a low position to save fuel and extend the life of the equipment.

  • Page 15: Maintenance

    with water to remove all concrete but take care that the engine does not get wet. The screed board can be thinly coated with diesel fuel to help prevent rust and more easily remove concrete. Clean the engine cylinder cooling fins. A broom or old brush are good tools to remove concrete be- fore it becomes solid.
  • Page 16 Maintenance Interval Maintenance Point Check the fuel level. Check the engine oil level. Inspect the fuel lines. Daily before operating Inspect the air filter and replace it if needed. Check and tighten the external hardware. After the first 20 operating Change the engine oil.
  • Page 17 Plain Washer Bolt M12x40 Plain Washer Spring Washer Cap Nut - 15 -...
  • Page 18 Explosion Diagram Descriptions Size or Dimension Handle Welding Assembly ZPJ-25A.2 - 16 -...
  • Page 19 Clamping block ZPJ-25.9 Clamping block ZPJ-25.10 Pin shaft GB/T882-B6*35 Handle Support Rubber TVSA-T.18 Handle Welding Assembly ZPJ-25A.1 Handle Support Pipe ZPJ-25.12 Engine Plate ZPJ-25A.3 Bolt GB/T70.1-M6*30-10.9 Clutch Housing Assembly TVSA-T.15 Wire TVSA-T.16 Rubber hose TVSA-T.17 Vibratory Housing Assembly TVSA-T.14 GB/T6170-M12 Plain Washer GB/T97.1-φ12 Spring Washer...

  • Page 20: Troubleshooting

    Socket wrench Dual-purpose wrench(S=18) hex head screws kit (M12*40) Manual Emission declaration Troubleshooting Please check the list below before addressing the problems to servicing personnel including local dealer. And if the problem continues after the troubleshooting as described below, call your local dealer for future assistance.
  • Page 21 Operator moving too Walk backwards at a Concrete looks slowly faster pace. “WAVY” as the Reduce engine speed screed board passes Too much vibration for and walk backwards over it the type of concrete at a faster pace. Have workers shape the concrete close as Leaving HIGH or possible to grade.
  • Page 22 Tel: +49 1727041930 euvertreter@gmail.com UK REP：Pooledas Group Ltd Unit 5 Albert Edward House, The Pavilions Preston, United Kingdom Tel: 01772418127 pooledas123@gmail.com Made in China - 20 -...
  • Page 24 Technical Support and E-Warranty Certificate www.vevor.com/support...

This manual is also suitable for:

Zpj-25a-8Zpj-25a-11
