Concealed toilet flush valve 1.28 & 1.6 gpf

Advertisement

SELECTRONIC
TOILET FLUSH VALVE
1.28 & 1.6 GPF
Exposed Back Spud
Certified to comply with ASME A112.19.2
© 2015 AS America, Inc.
M965642 Rev. 1.2 (5/15)
NOTE TO INSTALLER: Please give this manual to the customer after installation.
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Selectronic
or e-mail us at: CRTTEAM@americanstandard.com
For Parts, Service, Warranty or other Assistance,
please call (844) CRT-TEAM / (844) 278-8326
®
CONCEALED
Concealed Back Spud
Concealed Flushometer
for 1-1/2" Top or Back Spud Bowls
CLOG RESISTANT
• Self-cleaning piston valve prevents clogging and reduces maintenance.
ONE SENSOR FITS ALL
• Only 1 sensor for entire Selectronic™ line of faucets, urinals, and
flush valves.
• Range can be adjusted manually or with optional remote control.
• Sensor Features Low Battery Indicator.
CAUTION: Use only American Standard supplied cable
sets. Using non-AS supplied cables, or cutting, splicing or
modifying any components will void the warranty.
®
Products visit our website at: www.americanstandard-us.com
(In Canada: 1-800-387-0369)
(In Toronto Area only: 1-905-306-1093)
MODEL NUMBERS
6065.36X
6065.32X
6067.36X
6067.32X
6068.36X
6068.32X
Top Spud

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SELECTRONIC 6065.32X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for American Standard SELECTRONIC 6065.32X

  • Page 1 • Range can be adjusted manually or with optional remote control. • Sensor Features Low Battery Indicator. CAUTION: Use only American Standard supplied cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty.
  • Page 2 Thank you for selecting American-Standard...the benchmark of fine quality for over 100 years. To ensure that your installation proceeds smoothly--please read these instructions carefully before you begin. All American Standard Products Are Water Tested At Our Factory. UNPACKING Some Residual Water May Remain In The Valve During Shipping.
  • Page 3: Prior To Installation

    Fig. 1 CAUTION: Use only American Standard supplied GENERAL DESCRIPTION: transformers and cable sets. Using non-AS Roughing-in Dimensions ® supplied cables, or cutting, splicing or modifying SELECTRONIC any components will void the warranty. PROXIMITY TOILET FLUSH VALVE 25mm (1) MAX.
  • Page 4 FLUSH VALVE INSTALLATION Fig. 3 (TOP SPUD FIXTURE ILLUSTRATED) 389mm INSTALL WALL BOX; Fig. 3 ROUGH OPENING IN WALL (15-5/16) LEVEL 1. Frame out a 389mm x 265mm (15-5/4" X 10-3/8") rough opening in wall for the WALL BOX (1) at the dimension shown.
  • Page 5 4 INSTALL VACUUM BREAKER Fig. 6 FLUSH CONNECTIONS; Fig. 6. 1. Place the SPUD FLANGE (1) over the spud on the Fixture. Fig. 6. 1-1/2" TOP SPUD 2. Place FRICTION WASHER (3) and SEAL WASHER (4) inside SPUD COUPLING NUT (2) and thread onto Spud.
  • Page 6 INSTALL FLUSH VALVE; Fig. 7. Fig. 7 1. Insert the side ADJUSTABLE TAILPIECE (1) on the FLUSH VALVE (2) into the STOP VALVE (3). Lubricate the TAILPIECE O-RING (4) with water if necessary. Thread the COUPLING NUT (5) onto the STOP VALVE (3) and tighten lightly.
  • Page 7: Electrical Installation

    ELECTRICAL INSTALLATION Fig. 9 DC VERSION; Fig. 9, 9a. 1. Connect one end of the 27" EXTENSION CABLE (1) to a SENSOR CABLE (2). Connect the other end of the 27" EXTENSION CABLE (1) to the SOLENOID CABLE (3). Fig. 9. 2.
  • Page 8 AC VERSION ; Fig. 10, 10a. Fig. 10 1. Connect one end of the first 27" EXTENSION CABLE (1) to one SENSOR CABLE (5). Connect the other end of the 27" EXTENSION CABLE (1) to the SOLENOID CABLE (3). Fig.10. 2.
  • Page 9 5. Place Y-ADAPTERS (3) into respective electrical box. 6. Plug in AC power supply into wall outlet once all daisy-chain unit connections have been made. CAUTION: Use only American Standard supplied transformers and cable sets. Using non-AS supplied cables, or cutting, splicing or modifying any components will void the warranty.
  • Page 10 CONNECT OVERRIDE HOSES, Fig. 12 AC & DC POWER; Fig. 12. 1. Push the BLACK HOSE (1) into the BOTTOM HOSE CONNECTOR (2) on flush valve body, and push the othe end into the back of the MANUAL OVERRIDE VALVE (3). 2.
  • Page 11: Maintenance

    Fig. 13 MAINTENANCE INSTALL NEW BATTERY; Fig. 13. 1. Remove the six COVER PLATE SCREWS (1), then remove COVER PLATE (2). Fig. 13. 2. Remove old BATTERY (3) from BATTERY HOLDER (5). Install new BATTERY (4), making sure the terminal side is inserted first and shape of the battery follows the shape of the BATTERY HOLDER (5).
  • Page 12 SET DETECTION RANGE Fig. 15 Fig. 15 & 16. Note: The detection distance is preset and ideal for most installations. Should an adjustment be required, follow the steps below. 1. Remove COVER PLATE (1). See Step A for removing front panel instructions. 2.
  • Page 13: Troubleshooting Flowcharts

    Pr o du c t n am es l is ted h er ein a re t ra de m a rk s o f A S A m er ica , I nc. © 2 0 1 4 AGAIN TO PRIME THE VALVE. To learn more about American Standard Selectronic® Products visit our website at: DOES FLUSHING STOP? www.americanstandard-us.com or e-mail us at: CRTTEAM@americanstandard.com...
  • Page 14 P r o du ct na m e s l i st e d he re i n a r e t r ad em ar k s o f AS A me ri c a, I n c . © 2 0 14 To learn more about American Standard Selectronic® Products visit our website at: www.americanstandard-us.com or e-mail us at: CRTTEAM@americanstandard.com...
