MANUAL FLUSH VALVE, 1.0 GPF
Exposed Flushometer
for 3/4" top spud Urinals
Certified to comply with:
• ASSE 1037
• ANSI/ASME A112.19.2
• ADA Compliant
© 2012 AS America, Inc.
M965359 REV. 1.3
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.americanstandard.com
or U.S. customer's e-mail us at: faucetsupport@americanstandard.com
For Parts, Service, Warranty or other Assistance,
1-800-442-1902 (In Canada: 1-800-387-0369)
please call
FOR TOP SPU
FOR TOP SPUD APPLICATIONS
CLOG RESISTA
CLOG RESISTANT
T T N
• Self-cleaning pisto
• Self-cleaning piston valve prevents clogging and reduces maintenance.
OPERATING PRE
OPERATING PRESSURE:
• Overall Range:
• Overall Range: 20-125 psi **
• Recommended: 25 psi (flowing) - 80 psi (static)
• Recommended:
FLOW REQUIREMENT:
FLOW REQUIRE
• 10gpm (37.9 L/m
• 10gpm (37.9 L/min).
• Flush valves includ
• Flush valves include sweat solder kit.
**Water pressure over 80 psi is not recommended with most
plumbing fixtures
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
MODEL NUMBERS
6045.101
7015.101

Advertisement

loading

Related Manuals for American Standard 6045.101

Summary of Contents for American Standard 6045.101

  • Page 1 M965359 REV. 1.3 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,...

  • Page 2: Care Instructions

    M965359 REV. 1.3 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,...

  • Page 3: General Description

    Fig. 1 GENERAL DESCRIPTION: Roughing-in Dimensions FINISHED WALL MANUAL FLUSH VALVE, 1.0 GPF 38mm-127mm 108mm-133mm Exposed Flushometer (1-1/2-5") (4-1/4" to 5-1/4") for 3/4" Top Spud Fixtures Exclusive, self cleaning piston-operated flush valve. OPERATING PRESSURE: Overall Range: 20-125 psi ** SUPPLY DN 19mm Recommended: 20 psi (flowing)- (3/4"...
  • Page 4 INSTALL SWEAT SOLDER Fig.3 Fig.3a ADAPTER; Fig. 3 FINISHED WALL CENTER LINE OF Turn water supplies off CAUTION FIXTURE SPUD before beginning Note: Install Optional Sweat Solder Adapter (Supplied) for copper pipe supply line. Fig. 3. (A-B)= 1. Measure the distance (A) from the finished wall to the 32mm center of the inlet spud on the fixture.
  • Page 5 INSTALL FLUSH VALVE; Fig. 6a Fig. 6a & 6b 1. As shown in Fig. 6a, insert the side INLET FLANGE (1) on the FLUSH VALVE (2) into the SUPPLY STOP (3). Lubricate the INLET FLANGE O-RING (4) with water if necessary.
  • Page 6 If these items do need replacement they must be purchased separately or order the complete flush valve assembly from American Standard. 1. Remove COVER (1) from SUPPLY STOP (2) if installed. Fig. 9.

This manual is also suitable for:

7015.101
