Woodpeckers DPP Owner's Manual

oodpeckers
RILL PRESS PROTRACTOR
WNER ' S MANUAL
hank you for your purchase of the Woodpeckers Drill
Press Protractor. Start tackling angles on your projects
with a high degree of accuracy. The vernier scale lets you
set angles accurate to .083° Use at the drill press, band
saw, miter gauge, or in conjunction with your bevel
gauge.
If you think you ' re missing anything, email us at mailroom@woodpeck.com .
You can also call us at 800-752-0725 from 9:00 a.m. to 4:00 p.m. EST Monday - Friday.
IAGRAM (QTY) PART NAME
NUMBER
(4) Shank, 1/4"
2 (4) Protractor Arm
3 (2) Vernier Scale
Quarter-degree segments on one side,
Degrees and minutes on the other side
4
(4) Vernier Screws
5
(2) Protractor Scale
6 (2) Protractor Lock Knob
7
(1) Hex Key, 1/16"
Scan the QR code above
to watch the video
or visit woodpeck.com
under the video tab towards
the bottom of the product page.
