bouncepad Core VESA Assembly Instructions

Core VESA
Assembly Instructions
Tools Required:
Pencil
Electric Drill
2.5mm Drillbit
*if fixing to a surface
Socket Driver
Sheet Code: BP-IM-085_REV0
Release Date: 14/08/2024
Copyright 2024 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Confidential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
*Before attaching the
Mounting Plate, fully clean
the back of the tablet with
the provided wipe and allow
it to fully dry.
Landscape tablet orientation
For optimal adhesion, press firmly and
leave for 72hrs in a 20°C environment
before use. Do not reposition. Do not use
prior to the 72hrs.
Portrait tablet orientation
Tighten screw(s) using hand tools, using electric
tools may damage your Bouncepad.
Landscape
Remove the Mounting Plate adhesive
1
backing. Attach level & centrally to
the Tablet back as shown.
T20 Pin Torx Driver Bit
M4 Split Washer
Case Washer M4x16mm
Buttonhead screw
Locate & attach the Shell
5
to the Wallmount in the
correct orientation.
Flat Cable
Fixings Kit
VESA Mount
Tablet Mounting
Plate
Shell
In the Box
Portrait
Attach the Flat Cable
2
to the Tablet with the
U-Bend Head.
Follow steps A if "Fixing
A
to a surface".
Follow steps B if "Fixing
B
to a VESA Mount".
4x M4 Split
Washer
4x M4x16mm
1x Case
Buttonhead
Washer
screw
1x T20 Pin
Torx Driver Bit
4x No.8
Buttonhead
Self tapping
Screw
Fixings List
* Due to the modular nature of our product range you may receive additional fixings in the fixings kit
2x 3mmx6mm Pan
Head Screws
Cable Clamp
T10 Pin Torx Allen
Key
Secure the Flat Cable to
3
the Mounting Plate with
the Cable Clamp as shown.
Position & mark were the
A1
VESA is to be located.
Ensure the VESA is level.
2x 3mm x 6mm
Pan Head
Screws
4x M3x10mm
Countersunk
Screw
1x Cable
Clamp
1x T10 Pin Torx
Allen Key
Maximum Mounting
surface thickness :
Metric Imperial
25 1"
mm
1x Cleaning
Wipe
Paper Clip
Remove the
VESA Fixing
4
Covers with a
Paper Clip.
Drill central
16mm hole
if running
cable through
surface.
Drill the fixing holes into
A2
your surface.
