bouncepad Flip Assembly Instructions

Bouncepad Flip
Assembly Instructions
Attach your Case to the Base. Be sure to fully engage all screws
1
in their threads before tightening. Always use a hand screwdriver
or Allen key for this step.
2
Gently but firmly, pull the end plate out, keeping a tight hold
3
of both the tool and the unit.
1-617-804-0110 l www.bouncepad.com l Bouncepad North America Inc. 50 Terminal St, Unit 725, Building 2, 7th Floor, Boston, MA 02129, USA l © 2015 Bouncepad Spotspot Ltd. All rights reserved.
2
4
3
4
Remove End Plate. Hook the flip base tool behind the end plate.
2
Run the cable through the Secure Case. Find the USB end in the
4
base compartment and pull almost all the way through.

Components Key

1 Secure Case
2 Flip Base
Key x 2
3
Fixings Kit - 1x CaseWasher, 4x
4
Security screws, 1x Allen Key and
1x Flip Base Tool
4
