Assembly Instructions
Tools Required to Fix From Above:
Pencil
Drill + drill bits
16mm Hole Saw
Sheet Code:
BP-IM-074_REV2
Release Date:
08/04/2022
Copyright 2022 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Confidential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
back screw cover
front screw cover
1
Remove Front and Back Screw Covers.
TEXAS POE
GAF-Lightning-PD
Select your PoE device and note it's location in relation to the mounting slots
4
Link
In the Box
faceplate
Remove Faceplate.
2
REDPARK
Gigabit+PoE Adapter L6-NETPOE
1x T10
Pin Torx
Allen Key
1x tie
Fixings Kit
Fixings List
* Due to the modular nature of
our product range you may receive
additional fixings in the fixings kit
3
Remove Cable Lock.
BELKIN
Ethernet + Power
6x M3 x 6mm
Countersunk
Pin Torx
4x No.8
Screws
Countersunk,
Self tapping
Screw
1x Velcro Pad
4x Rawl Plugs
TEXAS POE
GAT-USBC-PD
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for bouncepad LINK
Summary of Contents for bouncepad LINK
- Page 1 1x Velcro Pad 4x Rawl Plugs Release Date: 08/04/2022 Copyright 2022 Spotspot Ltd. (T/A Bouncepad) all rights reserved. Confidential, no part of this publication may be reproduced or transmitted in any Fixings List form without the written permission of the...
- Page 2 16mm hole saw If running a ethernet or USB cable Secure the Link to the surface with 4x Connect the USB cable to the tablet, through the surface use a hole saw in No.8 Self tapping screws. Rawl plugs then place inside the enclosure.
- Page 3 Set up the video-conferencing Reattach the front and back screw Use 6x M3 Screws to secure faceplate. software and peripherals as per the covers provider’s instructions. kensington lock For additional security, tether your Link with a Kensington security cable. *Security cable not provided.
