bouncepad Static 60 Assembly Instructions

Static 60
Assembly Instructions
Tools Required:
Pencil
Electric Drill
7mm Spanner
*or adjustable spanner
5.0mm Drillbit
*if fixing from below
2.5mm Drillbit
*if fixing from above
16mm *if routing the tablet
cable through your
Holesaw
mounting surface
Socket Driver
Sheet Code: BP-IM-029_REV2
Release Date: 28/10/2019
Copyright 2016 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Confidential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
Minimum Mounting
surface thickness :
Metric Imperial
34 1
mm 5/16"
Follow steps B if "Fixing
B
from Above".
Mount Washer
M4 Split washer
M4 Locking Nut
7mm Spanner
Tighten screw(s) using hand tools, using electric
tools may damage your Bouncepad.
Mount Washer
M4 Split washer
M4 Wing Nut
Secure the arm to the
A4
surface. Locking Nuts
offer higher security.
Tablet Set-up Kit
Fixings Kit
Faceplate
Case
Static60
Mounting
Pair of Keys
Arm
Surface
Mounting Kit
In the Box
Mount Washer
4x Ø5.0mm
1x Ø16.0mm
Front
Using the Mounting
A1
washer, mark the drill
hole locations as shown.
Mount Plate
*see overleaf
A5 B1
Go to step 1.
4x No.8
4x M4x10mm
Countersunk,
Countersunk
Self tapping
Screw
Screw
4x M4x40mm 4x M4x20mm
Socketset Buttonhead
screw screw
1x T20 Pin
Torx Driver Bit
8x M4 Split
1x Mount
1x Case Washer
Washer
Washer
Fixings List
* Due to the modular nature of our product range
you may receive additional fixings in the fixings kit
Ø5.0mm Drillbit
Ø16.0mm Holesaw
Drill each hole -
A2
using the specified
drill size.
4x Ø2.5mm
1x Ø16.0mm
Front
Using the Mount Plate,
mark the drill hole
locations as shown.
4x M4
Wing Nut
4x M4
Locking
Nut
Maximum Mounting
surface thickness :
Metric Imperial
25 mm 1"
Follow steps A if "Fixing
A
from below".
Tighten screw(s) using hand tools, using electric
tools may damage your Bouncepad.
Locate and screw the Socket
A3
screws into the Static60 as
shown
Ø2.5mm Drillbit
Ø16.0mm Holesaw
Drill each hole - using the specified
B2
drill sizes.
Front
