- Page 1 Viper Installation of New Kit Transducer. Release Date: November 12, 2024 Release Number: 740002879INS Review Date: November 12, 2024 Revision: A Visit the Cornelius: www.cornelius.com website for your literature needs. - 1 -...
- Page 2 Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal service conditions with...
-
Page 3: Read And Follow All Safety Instructions
740002879INS: Viper Kit Transducer Installation Manual SAFETY INSTRUCTIONS READ AND FOLLOW ALL SAFETY INSTRUCTIONS Security Summary • Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels installed on the unit (decals, labels, or laminated cards). • Read and understand ALL OSHA (Occupational Safety and Health Administration) safety regulations before operating this unit. -
Page 4: Qualified Service Personnel
740002879INS: Viper Kit Transducer Installation Manual QUALIFIED SERVICE PERSONNEL WARNING: Only trained and certified electrical, plumbing and refrigeration technicians can service the unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY CAN RESULT IN SERIOUS INJURY, DEATH, OR DAMAGE TO EQUIPMENT. IF THE POWER CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER, ITS SERVICE TECHNICIAN OR SIMILARLY QUALIFIED PERSONNEL TO AVOID ANY DANGER. -
Page 5: Kit Components
740002879INS: Viper Kit Transducer Installation Manual KIT COMPONENTS ITEM NUMBER NAME 740002879 KIT SENSOR PRESSURE TRANSDUCER 0-50 311908000 CLAMP OETR 445OPEN STPLS #11.3 Table 1. - Page 6 740002879INS: Viper Kit Transducer Installation Manual KIT PRESSURE TRANSDUCER INSTALLATION PROCEDURE Step Action Figure Figure 1. Make sure the unit is fully charged and free of liquids such as syrup, water and CO2. Remove the rear panel with two Phillips screws to access the rear of the unit.
- Page 7 740002879INS: Viper Kit Transducer Installation Manual Figure 3a Locate the hoses that come out of the expansion tanks and go to the barrel. You will identify them because you will see the barrel pressure transducer sensor on them. Remove the insulation that prevents freezing in the cannon's delivery lines.
- Page 8 740002879INS: Viper Kit Transducer Installation Manual Proceed to remove the quick connector from the expansion tank Figure 5 Make sure to remove the insulation from the hose Figure 6...
- Page 9 740002879INS: Viper Kit Transducer Installation Manual Using cutting pliers, cut the hose as close to the fitting-Splicer .250"X.375" STL as possible. Figure 7 Figure 8 The hose will be as shown in the photograph.
- Page 10 740002879INS: Viper Kit Transducer Installation Manual Figure 9 Use 2 11.3mm clamps and place them on the hose that was just cut. Take the Transducer Kit and insert it into the hose ensuring the position of the elbow that enters the outlet of the...
- Page 11 740002879INS: Viper Kit Transducer Installation Manual Once you secure the clamps, reconnect the parts to the electrical connector and the expansion tank outlet. Figure 12 Make sure there are no product leaks and re-insulate the entire hose. This will help prevent freezing or condensation in the unit after installing the new transducer.
- Page 12 740002879INS: Viper Kit Transducer Installation Manual Cornelius Inc. www.cornelius-usa.com...
