- Page 1 XPRESSO 14” FHD Pro Quad Screen Tri-Fold Portable Monitor Suitable for 12-17.3” Laptops (1920 x 1200) KAMN14QTFDEA...
-
Page 2: Table Of Contents
Safety & Warnings Components Overview Assembly Specifications Troubleshooting... -
Page 3: Safety & Warnings
Safety & Warnings • Handle the monitor with care and do not press the screens to avoid damage. • Do not exceed its maximum turning angle shown as below. Screen Rotating Angles (0°-360°) (0°-360°) Left Screen (0° - 360°) Right Screen (0° - 360°) (0°-180°) (0°-180°) Top Screen (0°... -
Page 4: Components
Components Monitor 60cm USB-C to USB-C Cable (Video & USB-A to USB-C Cable (Video & Power) Power) 120cm USB-C to USB-C Cable (Power Carry Bag Only) USB Driver Power Adaptor (30W) -
Page 5: Overview
Overview USB-C Port USB-C Port Brightness+ (Right Screen) Brightness- (Left Screen) Brightness+ (Left Screen) Brightness- (Right Screen) Brightness- Brightness+ (Top Screen) (Top Screen) -
Page 6: Assembly
Assembly Remove the monitor from the box. Open the right and left screens following the directions shown in Figure 2. Figure 2 Figure 1 Rotate the top screen upward and horizontally until it aligns with the laptop screen. Figure 4 Figure 3 Extend the rear stand to a suitable position for stable placement on a table. - Page 7 Triple Display USB-C Connection • Connect one end of the provided USB-C cable (Video & Power) to the USB-C port on the monitor, and the other end to the USB-C port on your laptop. • It is recommended to power the monitor using your laptop charger. Connect your laptop charger to the USB-C port on the monitor.
-
Page 8: Dual Display
Dual Display USB-C Connection • If the power output of your laptop’s USB-C port is greater than 10W, the left and right screens can be powered by the laptop. • Connect one end of the USB-C to USB-C cable (Video & Power) to the USB-C port on the laptop and the other end to the USB-C port on the monitor. - Page 9 USB-A Connection Connect both USB-A male connectors to the USB-A connectors on your laptop. If your laptop has only one USB-A port, connect the black USB-A male connector to the laptop and the red USB-A male connector to a 5V/3A USB-A power adaptor (not provided).
-
Page 10: Install The Windows Driver
Install the Windows Driver Note: The monitor is not recommended for use with Windows XP or Windows 7/8 systems. It is compatible with Windows 10 or later versions. Automatic Installation Ensure your laptop is connected to the Internet. Connect the monitor to your laptop. The driver will install automatically. - Page 11 Open the USB drive folder and double-click the ‘DRIVERS’ folder. Select the driver that matches your Windows version (Windows 10 or Windows 11). Double-click the ‘RacerDisplayDriver’ application to begin the installation.
- Page 12 Follow the on-screen instructions and click ‘Next’ until the installation is complete. Restart your laptop after installation. Right-click on the desktop and select ‘Display Settings’.
- Page 13 Under display settings, choose ‘Extend Desktop to this display’. Adjust the arrangement of the screens (e.g., 1, 2, 3, 4) by dragging them to the desired positions.
- Page 14 Install the macOS Driver Note: This driver is compatible only with MacBooks released in 2019 or later, including models with M1, M2, and M3 chipsets. After turning on your laptop, insert the provided driver into a USB port. USB-C Driver USB-A Open the USB drive folder and double-click the ‘DRIVERS’...
- Page 15 Follow the on-screen instructions and click ‘Next’. Enter your laptop password when prompted to authorise the installation. Click the Apple icon in the upper-left corner and select ‘System Preferences’.
- Page 16 Navigate to ‘Security & Privacy,’ then select the ‘Privacy’ tab. Select ‘Screen Recording’.
- Page 17 Enable recording permission for ‘UsbDisplay.’ Once successfully installed, restart the laptop. If the driver cannot be found, follow the steps below to add the driver: a. Click the ‘+’ symbol in the ‘Applications’ menu to manually add the driver.
- Page 18 b. Navigate to ‘Applications > RacerUSB > UsbDisplay’ and select ‘Open’. 10. Return to the ‘System Preferences’ menu and select ‘Displays.’...
- Page 19 11. For the detected monitor, set it to ‘Use as Extended Display.’...
- Page 20 Laptop Display Configuration PC/Windows Go to your Display Settings (Start > Settings > System > Display). Click ‘Identify’ to display a number on each screen. Click and drag the numbered screens to match the desired configuration. If two screens appear combined (e.g., 2/1, 2/3), select one of the screens, then navigate to the ‘Multiple Displays’...
-
Page 21: Auto Sensing
macOS Open Displays Settings ( > System Setting > Displays). Click ‘Arrange Displays’ from the display menu. Click each monitor icon to identify which screen shows a red frame. Drag the screen icons to align them with the corresponding screens displaying the red frame. -
Page 22: Specifications
Specifications Screen size 14” Resolution 1920 x 1200 Aspect ratio 16:10 Backlight type W-LED Power DC 5-20V 3A PD Speaker USB-C 1920 x 1200 (Video and Power) USB-C 1920 x 1200 (Video and Power) Dimensions 352 x 233 x 41.7mm Weight 2.14 kg... -
Page 23: Troubleshooting
Troubleshooting Question Answer Can I turn off any screen of Yes, you can turn off and restart any screen through the monitor? the laptop's display settings. Is it necessary to use the rear Yes, the rear stand must be used to ensure stability stand when using the while using the monitor. - Page 24 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.Kogan.com.
