SDS1000CML+
SDS1000DL+
Series Digital
Oscilloscope
Quick Start
EN01C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDS1000CML+ Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIGLENT SDS1000CML+ Series

Summary of Contents for SIGLENT SDS1000CML+ Series

  • Page 1 SDS1000CML+ SDS1000DL+ Series Digital Oscilloscope Quick Start EN01C...

  • Page 3: Guaranty And Declaration

    ⚫ SIGLENT products are protected by patent law in and outside of P.R.C. ⚫ SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at company’s sole decision. ⚫ Information in this publication replaces all previously corresponding material.

  • Page 4: Table Of Contents

    Contents Guaranty and Declaration ....................... 1 General Safety Summary ....................... 3 Safety Terms and Symbols ..................... 4 Allgemeine Sicherheitsübersicht..................... 5 Sicherheitsbegriffe und Symbole .................... 7 General Care and Cleaning ....................8 General Inspection ......................... 8 Quick Start ..........................9 The Front Panel ........................13 The Rear and Side Panels ....................

  • Page 5: General Safety Summary

    General Safety Summary Carefully read the following safety precautions to avoid personal injuries and prevent damage to the instrument and any products connected to it. To avoid potential hazards, please use the instrument as specified. Only qualified technician should perform service procedures To Avoid Fire or Personal Injuries Use Proper Power Line Use only the special power line of the instrument which is approved by local state.

  • Page 6: Safety Terms And Symbols

    Safety Terms and Symbols Terms on the product. These terms may appear on the product: DANGER Indicates direct injuries or hazards that may happen. WARNING Indicates potential injuries or hazards that may happen. CAUTION Indicates potential damages to the instrument or other property that may happen. Symbols on the product.

  • Page 7: Allgemeine Sicherheitsübersicht

    Allgemeine Sicherheitsübersicht Lesen Sie die folgenden Sicherheitshinweise sorgfältig durch, um Verletzungen oder Schäden am Gerät und an den daran angeschlossenen Produkten zu vermeiden. Um mögliche Gefahren zu vermeiden, verwenden Sie das Gerät bitte wie angegeben. Verwenden Sie ein geeignetes Netzkabel Verwenden Sie nur das für das Gerät vorgesehene und im jeweiligen Land zugelassene Netzkabel.
  • Page 8 Wenn Sie vermuten, dass das Gerät beschädigt ist, lassen Sie es vor dem weiteren Betrieb von qualifiziertem Servicepersonal überprüfen. Jegliche Wartung, Einstellung oder Austausch, insbesondere von Schaltkreisen oder Zubehör, muss von SIGLENT autorisiertem Personal durchgeführt werden. Nicht in feuchter Umgebung betreiben Um einen Kurzschluss im Geräteinneren oder einen elektrischen Schlag zu vermeiden, betreiben Sie das...

  • Page 9: Sicherheitsbegriffe Und Symbole

    Sicherheitsbegriffe und Symbole Begriffe in diesem Handbuch. Diese Begriffe können in diesem Handbuch vorkommen: WARNUNG Warnhinweise weisen auf Bedingungen oder Praktiken hin, die zu Verletzungen oder zum Verlust des Lebens führen können. VORSICHT Vorsichtshinweise weisen auf Bedingungen oder Praktiken hin, die zu Schäden an diesem Produkt oder anderen Gegenständen führen können.

  • Page 10: General Care And Cleaning

    The consigner or carrier will be responsible for damages to the instrument resulting from shipment. SIGLENT would not provide free maintenance or replacement. 2. Inspect the instrument. If there are instruments found damaged, defective or failure in electrical and mechanical tests, please contact SIGLENT.

  • Page 11: Quick Start

    Quick Start Appearance and Dimension Figure 1 Front View Figure 2 Side View Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards for stable placement as well as easier operation and observation of the instrument. Figure 3 Adjust the Supporting Legs SDS1000CML+/SDS1000DL+ Quick Start...
  • Page 12 Power socket Note: In want of replacing the fuse, please return the instrument to the factory that produced it to have it repaired by qualified service personnel authorized by SIGLENT. Power-on Inspection When the scope is energized, press the power key at the top of it to turn it on. During the start-up progress, the instrument performs a series of self-test items and you can hear the sound of relay switching.
  • Page 13 Connect the Probe SIGLENT provides passive probes for these series oscilloscope. Please refer to corresponding Probe User Manual for detailed technical information. The following are the probes specified for this oscilloscope. Type Description PB470 70 MHz, passive probe PP510 100 MHz, passive probe...
  • Page 14 Observe waveforms on the screen. In normal condition, the display should be several square waveforms as is shown below: Test channel 2 in the same method. If the square waveforms do not display like figure above, please perform “Probe Compensation”. Note: To avoid electric shock when using the probe, please firstly make sure that the insulated wire of the probe is in good condition, and do not touch the metallic part of the probe when it is connected to a high voltage.

  • Page 15: The Front Panel

    The Front Panel No. Description No. Description Power On/Off Trigger Control Area Menus On/Off Probe Compensation Universal Knob Horizontal Control Area Function Menus EXT TRIG Terminal Default Setup Vertical Control Area Help Channel Input Terminal Single Menu Select keys Run/Stop Print Key Auto USB Host Interface...

  • Page 16: The Rear And Side Panels

    The Rear and Side Panels 1. Handle Pull up the handle vertically for easy carrying. Press it down if you do not need the handle. 2. AC Power Input Terminal The power available of the oscilloscope is 100~240V, 50/60/440Hz. Please use the power cord provided as accessories to connect the instrument to AC power.

  • Page 17: Function Introduction Of Front Panel

    Function Introduction of Front Panel Vertical Control Input channels. These two channels are marked with different colors to distinguish different input channels and their waveforms. Pressing the channel button will turn on the corresponding channel as well as its menu, and pressing it twice continuously will turn off the channel.
  • Page 18 Horizontal Control Press the button to open horizontal control menu under which you can turn on/off the delay sweep function and switch the save modes between “long save” and “normal save”. Modify the trigger position. The trigger point will move left or right relative to the center of the screen when you adjust the knob.
  • Page 19 RUN/STOP Press the button to set the state of the instrument to “RUN” or “STOP”. When in “RUN”, the indicator light displays yellow; When in “STOP”, it displays red. SINGLE Press the button to turn the trigger mode to “Single”. AUTO Press the button to enable the waveform auto setting function.
  • Page 20 Function Menus Press the button to enter the cursor measurement function menu. The instrument provides three measure modes: Manual, Track and Auto. Press the button to enter the acquire function menu, under which you could set the acquisition mode, sampling mode and dot inserting mode. Press the button to enter the file save and recall function menu.
  • Page 21 DEFAULT SETUP Press the button to restore the oscilloscope to its default settings. The default voltage scale and time base are respectively 1v/div and 500us HELP Information Press the button to enable HELP function, and then press down any menu to display corresponding help information.

  • Page 22: User Interface

    User Interface 1. Product logo SIGLENT is the registered trademark of our company. 2. Working state Available working states include Ready, Auto, Trig’d, Scan and Stop. 3. USB Host connection identifier When the USB Host is connected, the identifier is shown.
  • Page 23 9. Frequency counter Display the firmware frequency of current waveform. To display it, you should turn on the “Counter” in menu of “UTILITY”. 10. Trigger parameter  Trigger level. Display the position of the current trigger level, for example:  Trigger type.

  • Page 24: Using Security Lock

    Using Security Lock If needed, you could use the security lock (please buy it yourself) to lock the instrument in a fixed location. The method: align the clock with the clock hole and plug it into the lock hole vertically, turn the key clockwise to lock the instrument and then pull the key out.

  • Page 25: Troubleshooting

    (2). Check whether the fuse is burned out. If the fuse needs to be changed, please contact with SIGLENT as soon as possible and return the instrument to the factory to have it repaired by qualified personnel authorized by SIGLENT.
  • Page 26 (3). Make sure that the capacity of the U disk is not too large. It is suggested that the capacity is no larger than 4 G. (4). Restart the instrument and then insert the U disk to check. (5). If it is still in abnormal use, please contact with SIGLENT. SDS1000CML+/SDS1000DL Quick Start...
  • Page 28 Headquarters: SIGLENT Technologies Co., Ltd Add: Bldg No.4 & No.5, Antongda Industrial Zone, 3rd Liuxian Road, Bao'an District, Shenzhen, 518101, China Tel: + 86 755 3688 7876 Fax: + 86 755 3359 1582 Email: sales@siglent.com Website: int.siglent.com North America: SIGLENT Technologies America, Inc...

This manual is also suitable for:

Sds1000dl+ series
