SIGLENT SDS1004X-E Series Operating Tips

NTP Synchronization SDS1004X-E
August 29, 2023
Operating Tips – NTP Synchronization SDS1004X-E
The SDS1000X-E oscilloscope series supports date and time settings to allow data to be saved with the
correct time of day. When it is necessary for multiple instruments to have the same date and time setting,
it is convenient to synchronize the instruments to an NTP server. The SDS1xx4X-E series (4-channel)
oscilloscopes allow synchronization to an NTP server using IP Address access.
The NTP feature was added in version 6.1.37R2 of the SDS1xx4X-E Firmware (4-Channel Models). Firmware
update to latest version is recommended. The NTP function may also require an operating system update.
Match version 6.1.37R10 with OS-V3. View all of the firmware and operating system updates here:
https://siglentna.com/service-and-support/firmware-software/digital-oscilloscopes/#sds1000x-e-series
Getting Connected
Connect the SDS 1xx4X-E to the network and power it on.
Press Utility. Then press the Next Page key to display Page 3 / 4
Press Date/Time key for DATE/TIME menu.
