Fire Safety
Fire Kits
For installations with a floor more than 4.5m above ground, a
compatible fire kit must be fitted. The kits listed below contain all
the extra parts and instructions required:
Order Code
KIT-PIV-SMOKE-200
KIT-MIV-SMOKE-125
Smoke Alarms
For installations with a floor more than 4.5m above ground, the unit
must be wired into a smoke alarm in order to switch the unit off upon
the detection of smoke.
The unit can be wired into an existing smoke alarm (check compatibility
with the smoke alarm manufacturer). All wiring should be completed
by a competent person.
To test the installation, press the TEST button on top of the smoke alarm
and keep it pressed until the PIV unit switches off (LEDs on the board
go out).
13
Atmos
200mm fire-rated diffuser for PIV units only
2x 125mm fire-rated diffusers for MIV units only
SHOULD YOU ENCOUNTER ANY PROBLEMS
INSTALLING THIS UNIT, CALL US ON:
Description
01423 810 810
