Summary of Contents for Envirovent fliterless infinity fan 230v

  • Page 3 Not using these items will jeopardise both the IP rating and the warranty. Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice.

  • Page 4: Energy Use

    The EnviroVent Filterless Infinity Fan uses award- the rising humidity and reduce in speed to match falling winning Ultra Low Watt motor technology to give the humidity.

  • Page 5: Installation Instructions

    FILTERLESS INFINITY FAN INSTALLATION INSTRUCTIONS IMPORTANT SAFETY AND RECOMMENDATIONS Be sure to have read and understood these All wiring must comply with Building Regulations instructions before beginning installation and the current IEE Wiring Regulations 17th edition process. (BS7671) or the equivalent standards for your country.
  • Page 6 FILTERLESS INFINITY FAN INSTALLATION INSTRUCTIONS Cable gland Avoid cable entry into shaded areas NO CABLES Fig.1 Alternative fixings 100mm ducting (Ø106) 125mm ducting (Ø131) Cable gland Wall fixings NOT TO SCALE - FOR GENERAL INFORMATION ONLY Fig.2 Loosen the two plastic screws and remove front cover.

  • Page 7: Maintenance

    All repair, maintenance and component replacement is carried out simply and quickly by exchanging the plug out/plug in central cartridge. The worn out cartridge can then be returned to the EnviroVent factory to be recycled/reworked. This ‘when necessary’ cartridge exchange – with re-worked components will ensure that the basic fan installation will remain intact throughout the repair cycle of the dwelling, eliminating the wasteful disposal of plastic and other non biodegradable material to landfill sites.

  • Page 8: Troubleshooting

    AFTER SALES SERVICE We recommend that you do not dismantle or remove any other parts than those mentioned, as any tampering would automatically cancel the guarantee. If you detect any fault, please contact EnviroVent on 01423 810 810. OTHER APPLICATIONS/VARIATIONS For recessed only installations we can supply a bezel.

  • Page 9: Technical Specifications

    FILTERLESS INFINITY FAN TECHNICAL SPECIFICATIONS Sound dB(A) Duty (l/s) Power (W) @ 3M 30.8 46.2 Airflow (l/s) OPTIONS & ANCILLARIES Description Code(s) Remote Pullcord EFHTCM-RC Remote Wall Switch EFHTCM-WS Wall Mounted Kit 1RD EFWAK Ceiling Mounted Kit 1AC EFCMBR Window Fixing Kit (230V) EFWIK230V Window Fixing Kit (SELV) EFWIK12V...
  • Page 10 FILTERLESS INFINITY FAN WARRANTY CONDITIONS AND EXCLUSIONS The EnviroVent Filterless Infinity Fan is covered by a full 7 year warranty which will benefit the occupier over many years. There is no requirement for any maintenance within the first 7 year period.
  • Page 12 EnviroVent House F 01423 810 910 Hornbeam Business Park E info@envirovent.com Harrogate HG2 8PA www.envirovent.com E&OE | MKT ENV275-V2-28.03.14 Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice.
