AFTER INSTALLATION THE END USER SHOULD
AFTER INSTALLATION THE END USER SHOULD
KEEP THIS GUIDE FOR FUTURE REFERENCE
KEEP THIS GUIDE FOR FUTURE REFERENCE
DO NOT THROW AWAY
DO NOT THROW AWAY
PIV & MIV AIR SOURCE / INLINE
PIV & MIV AIR SOURCE
VENTILATION UNIT INSTALLATION GUIDE
VENTILATION UNIT INSTALLATION GUIDE
Advertisement
Related Manuals for Envirovent KIT-PIV-SMOKE-200
Summary of Contents for Envirovent KIT-PIV-SMOKE-200
- Page 1 AFTER INSTALLATION THE END USER SHOULD AFTER INSTALLATION THE END USER SHOULD KEEP THIS GUIDE FOR FUTURE REFERENCE KEEP THIS GUIDE FOR FUTURE REFERENCE DO NOT THROW AWAY DO NOT THROW AWAY PIV & MIV AIR SOURCE / INLINE PIV & MIV AIR SOURCE VENTILATION UNIT INSTALLATION GUIDE VENTILATION UNIT INSTALLATION GUIDE...
- Page 2 Safety Read and understand these instructions before beginning installation. The unit should be installed by a competent person. Location Check there is space for the unit in your chosen location. The unit must not affect the operation of open-flue appliances. Consult local regulations or a qualified gas engineer.
- Page 3 The power supply cable running into the unit must remain the supplied flexible cable (not a solid core lighting cable). If the power supply cable becomes damaged, it must be replaced by EnviroVent, an authorised service agent for your region/country, or a similarly qualified person in order to avoid a hazard.
- Page 4 Diagrams PIV AIR SOURCE ø200 mm 406 mm 479 mm MIV AIR SOURCE ø100 mm 406 mm 479 mm SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: PIV & MIV Air Source...
- Page 5 INLINE DUCT CONFIGURATIONS Use one of three options to connect the inline duct to the outside of the property (extra parts not supplied): 1. Straight duct to a wall mounted vent or grille. 2. Angled duct to a roof tile vent. 3.
- Page 6 WIRING VENTILATION UNIT LOCAL ISOLATOR MAINS SUPPLY 230V 50/60HZ N E L POWER CABLE TO CONNECT OPTIONAL HEATER ENABLE CABLE SEE STEP 1 TO 4 The local isolator must be connected to the mains as part of the fixed wiring. Connect the N, L and E cores of the power cable to the matching terminals on the local isolator.
- Page 7 PIV Air Source box contents MIV Air Source box contents • 1x PIV Air Source unit • 1x MIV Air Source unit • 1x Loft Filter • 1x Loft Filter • 2x Flexible filter rods • 2x Flexible filter rods •...
-
Page 8: Pre-Installation Checklist
Pre - Installation Checklist • Does the unit fit through the loft hatch? • Check there are no obstructions in the hallway or landing where the diffuser is to be fitted and in the loft space above. • Ensure the loft has adequate cross-flow ventilation to provide a supply of fresh air to the unit. - Page 9 In conditions between 19°C - 25°C the units will increase air flow rate by 10%. Above 25°C the PIV & MIV airsource units automatically switch to bringing air directly from outside to avoid bringing hot air into the property from the loft space. The PIV unit uses a single 200mm diffuser to provide air into a hallway or landing area.
-
Page 10: Installation
Installation 1. Place a dust sheet below the required ceiling diffuser position and check the ceiling below and loft space above are unobstructed. 2. a) For PIV units mark a 222mm diffuser hole using the template. 2. b) For MIV units mark two 105mm diffuser holes (see page 9 for positioning information). - Page 11 4. a) Screw the feet of the unit onto two 25mm x 50mm wood battens using the four 10g x 1.5” screws. (Battens not supplied). 4. b) Position the unit with anti-vibration pads and washers onto the loft ceiling joists as in the diagram. 4.
- Page 12 5. Insert the diffuser spigot into the ceiling hole so that the diffuser outlets face towards the walls then mark the four fixing holes. 6. Attach the duct to the spigot of the diffuser and seal the connection using the fixings supplied. 7.
- Page 13 9a. INLINE FILTER (all units) 1. Insert the inline filter into a 350mm long section of rigid 150mm diameter duct (not supplied) on the inlet side of the unit. 2. Connect to the filter with a section of flexible duct approximately 300mm long (not supplied). The connection must be removable, to allow the filter to be replaced.
- Page 14 10. With the mains supply isolated, wire the power cable into the unswitched fuse spur then wire the unswitched fuse spur into the mains supply (see wiring diagram on page 5). Use two of the 8g x 1” screws to attach the spur to a loft joist.
-
Page 15: Fire Safety
The kits listed below contain all the extra parts and instructions required: Order Code Description KIT-PIV-SMOKE-200 200mm fire-rated diffuser for PIV units only KIT-MIV-SMOKE-125 2x 125mm fire-rated diffusers for MIV units only Smoke Alarms For installations with a floor more than 4.5m above ground, the unit... - Page 16 SMOKE ALARM WIRING SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: PIV & MIV Air Source...
-
Page 17: Running Costs
Running costs Please scan our QR code to see the annual running costs of this product. Or visit: envirovent.com/annual-running-costs DO NOT AFTER INSTALLATION THE END USER SHOULD KEEP THIS GUIDE FOR FUTURE REFERENCE THROW AWAY... - Page 18 Performance Figures - PIV INLINE House size Max air flow rate (l/s) Power usage (Watts) setting Performance Figures - MIV INLINE House size Max air flow rate (l/s) Power usage (Watts) setting Diffuser installed without blanking plates fitted. Power usage shown with heater function disabled. Figures calculated at incoming air temperature below 19 degrees C.
-
Page 19: Maintenance
Maintenance The PIV and MIV Air Source units are designed to operate for 5 years before requiring a full service. It is recommended that the filters are replaced after 5 years usage. If there are very high amounts of particulate matter in the air and loft space, the filter will need to be replaced more frequently. -
Page 20: Warranty
Warranty We appreciate you choosing this quality EnviroVent product, which is designed and manufactured to the highest specification in Harrogate, North Yorkshire. We are confident that you will be delighted with the performance of the system and the resulting improvement in air quality in your home after the installation of the unit. - Page 21 DO NOT AFTER INSTALLATION THE END USER SHOULD KEEP THIS GUIDE FOR FUTURE REFERENCE THROW AWAY...
- Page 22 SHOULD YOU ENCOUNTER ANY PROBLEMS 01423 810 810 INSTALLING THIS UNIT, CALL US ON: PIV & MIV Air Source...
- Page 23 DO NOT AFTER INSTALLATION THE END USER SHOULD KEEP THIS GUIDE FOR FUTURE REFERENCE THROW AWAY...
- Page 24 Your feedback is important to us as we strive to improve our and improvement EnviroVent reserves the products, services, and overall customer experience. Please email right to alter products specification and us to help us serve you better: feedback@envirovent.com appearance without notice.
