Installation

1. Place a dust sheet below the required ceiling diffuser position and

check the ceiling below and loft space above are unobstructed.

2. a) For ATMOS mark a 222mm diffuser hole using the template.

2. b) For ATMOS DUAL mark two 105mm diffuser holes

(see page 8 for positioning information).

3. Wearing a dust mask and eye protection, cut out the hole/s.

Atmos

SHOULD YOU ENCOUNTER ANY PROBLEMS

INSTALLING THIS UNIT, CALL US ON:

01423 810 810

Need help?

Do you have a question about the ATMOS and is the answer not in the manual?

Atmos dual
