Envirovent ATMOS Installation Manual page 13

9. With the mains supply isolated, wire the power cable into the
unswitched fuse spur then wire the unswitched fuse spur into the
mains supply (see wiring diagram on page 5).
Use two of the 8g x 1" screws to attach the spur to a loft joist.
10. App and Remote Control units can be connected to an AirSens
intelligent IAQ sensor (not included). Wire into the connection
located under the unit (see Page 5, cable not included).See AirSens
instructions for wiring.
11. Reconnect the mains supply at the local isolator. After a few
seconds air will begin to flow from the diffuser (see pages 16/17 for
air flow rate settings).
9
11
AFTER INSTALLATION THE END USER SHOULD
KEEP THIS GUIDE FOR FUTURE REFERENCE
10
Fuse
App &
spur
Remote
Control
units only
DO NOT
THROW AWAY
12
