- Page 2 HOTLINE: 0845 27 27 810 Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice. SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL...
-
Page 3: About The Unit
6 additional wet rooms, providing high centrifugal performance with low running noise. Highly cost effective and value for money, the MEV Spider comes with a full five year guarantee. EXPLODED VIEW Commissioning panel... -
Page 4: Wiring Diagram
After Sales Service - We recommend you do not dismantle or remove any other parts than those mentioned, as any tampering would automatically cancel the guarantee. If you detect any fault please contact EnviroVent. SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL... -
Page 5: Technical Specifications
Technical Specifications Supply Voltage 230V / 50-60Hz / 70W Max / 0.5 A Max Dimensions H 387mm x W 440mm x D 198mm Ventilation Capacity 135 l/s @ 100pa. Max 151 l/s (545m Weight Boxed 5.8kg | Unit 4.3kg Dimensions (mm) Ø125 Performance Curve AFTER INSTALLING THIS UNIT PLEASE PASS ONTO END USER... -
Page 6: Installation Instructions
• Precautions must be taken to avoid the back-flow of gases into the dwelling from The MEV Spider unit should be situated so the open flue of gas or other fuel-burning that access for maintenance or replacement appliances. - Page 7 Installation Instructions Description Quantity Item MEV Spider Unit Spigots Spigot Blank Fixing Kit Screws 8G X 2.0” Washers Plasterboard Plugs Adhesive Foam Pads Controls Intelligent Humidity Tracking (Automatic) Boost - Wall Switch MEVS-H and MEVS-W versions only The MEVS and MEVS-H comes with a boost...
- Page 8 Installation Instructions Mounting the unit 4. Secure the MEV unit on all four corners. 1. The unit maybe installed in any vertical or horizontal orientation 2. Use the unit to mark fixing holes, ensuring clearance around the MEV unit. Drill 4 x Ø8mm holes, position plasterboard plugs in the mounting surface and foam pads on the back of the unit’s mounting tabs.
- Page 9 Installation Instructions Connecting the ductwork 1. Scribe around the outer edge of the 4. Push in spigot and fix with self tapping required spigot blank MAX x 3 (a). Knock screws provided. out the blank with a light tap (b). 5.
- Page 10 Commissioning Boost controls The MEV Spider operates continuously Remote control on ‘Normal’ setting to ensure the home is Constant green Flashing red ventilated at the appropriate level although LED = paired LED = not paired you can boost the system via the wired or remote control switch, if fitted.
- Page 11 Commissioning Setup guide for the MEV Spider The control switch is found behind the front cover. Commissioning mode is chosen by pressing the SET button for 4 seconds, all sensor inputs will be disabled in this mode so that they do not interfere with flow rates. LEDs will...
- Page 12 Commissioning Commissioning of a continuous running Multiple Extract Ventilation system- MEV • Adjust using buttons, press up Commissioning system or down until the total extract rate is met. necessary to provide adequate ventilation to the dwelling, as stipulated in Approved See the individual product’s instruction Document F (ADF) of the Building guide for method (pages 9-10).
- Page 13 Checklist to ensure Guaranteed Installed Performance MEV Spider installation instructions have been understood Ductwork is Ø100mm or larger with no more than 10% flexi used (90% rigid) All ducts, vents and diffusers are securely connected & sealed The unit is securely fixed into position with enough space left for servicing...
-
Page 14: Maintenance
Maintenance There are no special requirements for any Cleaning maintenance within a five year period. The Isolate the unit from electrical mains unit is easy to clean by simply removing the supply before removing any cover, or lid and motor plate. After carrying out work, servicing the unit. -
Page 15: Warranty
Guarantee The EnviroVent MEV Spider is covered by a full 5 year warranty which will benefit the occupier over many years. The unit will be set according to the size of the property and will operate continuously. There is no requirement for any maintenance within the 5 year period. - Page 16 AFTER INSTALLING THIS FAN PLEASE PASS ONTO END USER - DO NOT THROW AWAY EnviroVent Ltd EnviroVent House Hornbeam Business Park Harrogate HG2 8PA 01423 810 810 info@envirovent.com www.envirovent.com E&OE MKT ENV230-V6-06.01.15 Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice.
