Summary of Contents for Envirovent IPX4
-
Page 2: Safety And Recommendations
Safety IMPORTANT SAFETY AND RECOMMENDATIONS Be sure to have read and understood these • All wiring must comply with Building instructions before beginning the installation Regulations and the current I.E.E. Wiring process. Regulations (BS7671) or the equivalent standards for your country. The final installation should be examined and tested This fan can be wall, ceiling, inline or by a qualified electrician. - Page 3 HOTLINE: 0345 27 27 810 Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice. AFTER INSTALLING THIS UNIT PLEASE PASS ONTO END USER...
- Page 4 Wiring Wiring the fan correctly... 1. The connection into the fan MUST be a flexible cable and NOT solid core twin and earth, if the fan is mishandled or a solid core twin and earth cable is forced into the terminals you WILL break it, this will invalidate the warranty.
-
Page 5: Technical Specifications
Technical Specifications Sound dB(A) Duty (l/s) Power (W) @ 3M 30.8 46.2 Airflow (l/s) Options & Ancillaries Description Code(s) Wall Mounted Kit 1RD EFWAK Ceiling Mounted Kit 1AC EFCMBR Window Fixing Kit (230V) EFWIK230V Window Fixing Kit (SELV) EFWIK12V In-line Fixing Kit EFIL-WIK AFTER INSTALLING THIS UNIT PLEASE PASS ONTO END USER DO NOT THROW AWAY... -
Page 6: About The Unit
Keep this user guide handy. The fan has been set by the installation engineer to suit your kitchen or bathroom application. Your EnviroVent Filterless Extract Fan has been designed to improve air quality and reduce humidity levels in kitchens and... -
Page 7: Energy Use
About The Unit ENERGY USE Setting The EnviroVent Filterless Extract Fan uses award-winning Ultra Low Watt motor Background Bathroom Kitchen technology to give the lowest running Trickle on boost on boost costs of any domestic extract fan. It uses only a minimal amount of electricity whilst... -
Page 8: Installation Instructions
Installation Instructions Cable gland Avoid cable entry into Fig.1 shaded areas NO CABLES Alternative fixings 100mm ducting Cable gland (Ø106) 125mm ducting (Ø131) Fig.2 Wall fixings Central carcass Back carcass 230V Gasket NOT TO SCALE - Fig.3 FOR GENERAL INFORMATION ONLY Slider Impeller Loosen the two plastic screws and... -
Page 9: Maintenance
1. Isolate from mains. The worn out cartridge can then be returned 2. Remove front cover. (Fig.1) to the EnviroVent factory to be recycled/ 3. Pull the front cover towards you from reworked. the bottom. It will pull towards you with This ‘when necessary’... -
Page 10: Troubleshooting
For recessed only installations we can supply a bezel. Gold Standard After Sales Service In the unlikely event of any on-site installation problems or queries regarding the EnviroVent Filterless Extract Fan, just call our hotline number. We will take your details and appoint a regional installation manager to call you back to discuss the problem. -
Page 11: Warranty
Guarantee The EnviroVent Filterless Extract Fan is covered by a full 5 year warranty which will benefit the occupier over many years. The unit will be set according to the size of the property and will operate continuously. There is no requirement for any maintenance within the 5 year period. - Page 12 AFTER INSTALLING THIS FAN PLEASE PASS ONTO END USER - DO NOT THROW AWAY EnviroVent Ltd EnviroVent House Hornbeam Business Park Harrogate HG2 8PA 01423 810 810 info@envirovent.com www.envirovent.com E&OE MKT ENV207-V8-25.02.16 Due to our policy of continuous innovation and improvement EnviroVent reserves the right to alter products specification and appearance without notice.
