Owner's Manual
Tilt Flat-Screen
Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY
OR PROPERTY DAMAGE MAY OCCUR!
200x200/200x300/200x400/
300x200/300x300/300x400/
400x200/400x300/400x400/
500x300/500x400/600x300/
600x400/800x300/800x400
Este manual está disponible en español en la página de Eaton:
Tripplite.Eaton.com/support
Ce manuel est disponible en français sur le site Web de Eaton :
Tripplite.Eaton.com/support
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Eaton по адресу: Tripplite.Eaton.com/support
Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:
Tripplite.Eaton.com/support
Model:
DWT3770X
70"
MAX.
PRODUCT
REGISTRATION
Register your product today for a
chance to win an ISOBAR
surge
®
protector in our monthly drawing!
Tripplite.Eaton.com/warranty
91 kg
91 kg
(200 lbs)
(200 lbs)
MAX
MAX
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TRIPP LITE DWT3770X and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton TRIPP LITE DWT3770X

Summary of Contents for Eaton TRIPP LITE DWT3770X

  • Page 1 500x300/500x400/600x300/ 600x400/800x300/800x400 Este manual está disponible en español en la página de Eaton: Tripplite.Eaton.com/support Ce manuel est disponible en français sur le site Web de Eaton : Tripplite.Eaton.com/support Русскоязычная версия настоящего руководства представлена на веб-сайте компании Eaton по адресу: Tripplite.Eaton.com/support Dieses Handbuch ist in deutscher Sprache auf der Eaton-Website verfügbar:...

  • Page 2: Warranty And Product Registration

    EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL EATON BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit Tripplite.Eaton.com/support for service. (x1) (x1) (x1) Package M M5X14 (x4) M6X14 (x4) M8X50 (x4) M6X30 (x4)
  • Page 4 1a. Mount on Wood Stud Wall Find and mark the exact location of mounting holes Drill pilot holes D6 Washer Anchor Bolt Screw the wall plate onto the wall WARNING • Make sure that mounting screws are anchored into the center of the studs. Use of a stud finder is highly recommended.
  • Page 5 1b. Mount on Solid Brick and Concrete Block Mark the exact location of mounting holes Drill pilot holes D6 Washer Concrete Anchor Anchor Bolt Screw the wall plate onto the wall WARNING • When installing wall mounts onto a concrete masonry unit (also known as a CMU or “cinder block”), verify that the actual concrete thickness is at least 35mm (1-3/8”) in order to hold the concrete anchors.
  • Page 6 2. Install Adapter Brackets Top of display 2-1 For Flat Back Screen M5X14 M6X14 Washer...
  • Page 7 2. Install Adapter Brackets 2-2 For Recessed Back Screen or to Access A/V Inputs M6X30 M6X30 M6X30 M8X30 M8X30 M8X30 Washer Washer Washer Small Spacer Small Spacer Big Spacer Small Spacer Big Spacer M8X50 M8X50 M8X50 Washer Washer Washer Small Small Spacer Spacer...
  • Page 8 Once the display is at the desired angle, retighten the knobs to hold. Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit Tripplite.Eaton.com/support if you have any questions. Eaton 1000 Eaton Boulevard...
