BRG0029
FITTING INSTRUCTIONS FOR BRG0029SS
BRANDED RADIATOR GUARD
FOR KAWASAKI NINJA ZX-10R/RR 2021-
PICTURE A
T
.
HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
S
.
OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
D
.
O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
P
.
LEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF
OUR DEALERS OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
P
LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE
.
WAY OF MOUNTING TO THE BIKE
I
,
N THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G BRG0029SS
Summary of Contents for R&G BRG0029SS
- Page 1 Page 1 of 21 BRG0029 FITTING INSTRUCTIONS FOR BRG0029SS BRANDED RADIATOR GUARD FOR KAWASAKI NINJA ZX-10R/RR 2021- PICTURE A HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
-
Page 2: Tools Required
Page 2 of 21 BRG0029 TOOLS REQUIRED GENERAL TORQUE SETTINGS M4 BOLT = 8Nm • Allen key set to include 4 & 5mm A/F. M5 BOLT = • 10mm spanner or socket. M6 BOLT = • Phillips and flat bladed driver. M8 BOLT = 20Nm •... - Page 3 Page 3 of 21 BRG0029 LEGEND ITEM NO. DESCRIPTION ITEM 1 BRANDED RADIATOR GUARD (BRG0029SS) ITEM 2 SELF ADHESIVE FOAM x 100mm LONG ITEM 3 2.5mm CABLE TIES PICTURE 1 PICTURE 2 PICTURE 3 PICTURE 4 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
- Page 4 Page 4 of 21 BRG0029 PICTURE 5 PICTURE 6 PICTURE 7 PICTURE 8 PICTURE 9 PICTURE 10 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 5 Page 5 of 21 BRG0029 PICTURE 11 PICTURE 12 PICTURE 13 PICTURE 14 PICTURE 15 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
-
Page 6: Fitting Instructions
Page 6 of 21 BRG0029 FITTING INSTRUCTIONS Near side (left side as you sit on the motorcycle) Remove the three plastic rivets arrowed in pictures 1 and 2. • Remove the five bolts arrowed in pictures 3, 4, 5, 6 and 7. •... - Page 7 Page 7 of 21 BRG0029 CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
- Page 8 Page 8 of 21 BRG0029 MONTAGEANLEITUNG FÜR BRG0029SS KÜHLERSCHUTZ (GEBRANDET) FÜR KAWASAKI NINJA ZX-10R/RR 2021- ABBILDUNG A EILE SIND AUF DEN NACHFOLGENDEN EITEN ABGEBILDET UND GEKENNZEICHNET IE ABGEBILDETEN EILE DIENEN LEDIGLICH ZUR RKLÄRUNG Ü BERPRÜFEN IE ZUERST DASS ALLE EILE VORHANDEN SIND...
- Page 9 Page 9 of 21 BRG0029 SIE BENÖTIGEN FOLGENDES WERKZEUG ALLGEM ANZUGSDREHMOMENTE M4 SCHRAUBE = 8Nm • Satz Inbusschlüssel inkl. 4 & 5mm A/F M5 SCHRAUBE = • 10mm Steckschlüssel oder Schraubenschlüssel M6 SCHRAUBE = • Schraubenzieher (Kreuzschlitz und M8 SCHRAUBE = 20Nm flachen Schraubenzieher) 0 SCHRAUBE = 40Nm •...
- Page 10 Page 10 of 21 BRG0029 LIEFERUMFANG ARTIKEL BESCHREIBUNG MENGE ARTIKEL 1 (GEBRANDET) KÜHLERSCHUTZ (BRG0029SS) ARTIKEL 2 SELBSTKLEBENDER SCHAUMSTOFF x 100mm LÄNGE ARTIKEL 3 2,5mm KABELBINDER ABBILDUNG 1 ABBILDUNG 2 ABBILDUNG 3 ABBILDUNG 4 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
- Page 11 Page 11 of 21 BRG0029 ABBILDUNG 5 ABBILDUNG 6 ABBILDUNG 7 ABBILDUNG 8 ABBILDUNG 9 ABBILDUNG 10 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 12 Page 12 of 21 BRG0029 ABBILDUNG 11 ABBILDUNG 12 ABBILDUNG 13 ABBILDUNG 14 ABBILDUNG 15 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 13 Page 13 of 21 BRG0029 MONTAGEANLEITUNG Linke Seite (in Fahrtrichtung) Entfernen Sie die drei Plastiknieten, die in den Abbildungen 1 und 2 markiert • sind. Entfernen Sie die fünf Schrauben, die in den Abbildungen 3, 4, 5, 6 und 7 •...
- Page 14 Page 14 of 21 BRG0029 Montieren Sie die Bremsschlauchhalterung wie ursprünglich wieder. • Montieren Sie beide Verkleidungen wie ursprünglich wieder. • ISSUE 2 21/09/2021 (NSY) CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
- Page 15 Page 15 of 21 BRG0029 NOTICE DE MONTAGE POUR BRG0029SS GRILLE DE PROTECTION RADIATEUR POUR KAWASAKI NINJA ZX-10R/RR 2021- PHOTO A E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES...
-
Page 16: Outils Requis
Page 16 of 21 BRG0029 OUTILS REQUIS VALEURS DE SERRAGE M4 BOULON = 8Nm • Clés Allen 4 & 5mm. M5 BOULON = • Clé à molette 10mm. M6 BOULON = • Tournevis cruciforme et plat. M8 BOULON = 20Nm •... - Page 17 Page 17 of 21 BRG0029 LÉGENDE ARTICLE DESCRIPTION QTÉ ARTICLE 1 GRILLE DE PROTECTION (BRG0029SS) ARTICLE 2 MOUSSE AUTOCOLLANTE x 100mm DE LONG ARTICLE 3 2.5mm COLLIERS DE SERRAGE PHOTO 1 PHOTO 2 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
- Page 18 Page 18 of 21 BRG0029 PHOTO 3 PHOTO 4 PHOTO 5 PHOTO 6 PHOTO 7 PHOTO 8 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 19 Page 19 of 21 BRG0029 PHOTO 9 PHOTO 10 PHOTO 11 PHOTO 12 PHOTO 13 PHOTO 14 PHOTO 15 R&G Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
-
Page 20: Notice De Montage
Page 20 of 21 BRG0029 NOTICE DE MONTAGE Côté gauche (lorsqu’on est assis sur la moto) • Retirez les trois rivets en plastique fléchés sur les photos 1 et 2. Retirez les cinq boulons fléchés sur les photos 3, 4, 5, 6 et 7. •... - Page 21 Page 21 of 21 BRG0029 Reposer le support de conduite de frein comme d'origine. • Reposer les deux carénages comme d'origine. • ISSUE 2 21/09/2021 (NSY) CONSUMER NOTICE The catalogue description and any exhibition of samples are only broad indications of the Products and R&G may make design changes which do not diminish their performance or visual appeal and supplying them in such state shall conform to the order.
