BLP0093
FITTING INSTRUCTIONS FOR BLP0093 FOOTREST BLANKING PLATES
FOR BMW S1000RR '19-
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
P
LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
MOUNTING TO THE BIKE
P
LEASE NOTE THAT IN CASES WHERE KITS ARE PACKED WITH RUBBER WASHERS HOLDING THE COMPONENTS
–
!
ONTO THE BOLT
THE RUBBER WASHERS SHOULD BE THROWN AWAY
T
(
)
HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY
FOR CLARITY OF INSTRUCTIONS ONLY
D
.
-
.
IGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE TO DOWNLOAD FROM
WWW
RG
RACING
COM
GENERAL TORQUE SETTINGS
M4 BOLT = 8Nm
TOOLS REQUIRED
M5 BOLT = 12Nm
•
T45 Torx Key/Socket
M6 BOLT = 15Nm
•
5mm A/F Allen Key/Socket
M8 BOLT = 20Nm
M10 BOLT = 40Nm
R&G
Unit
, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
1
Tel: +44 (0)
420 89007 Fax: +44 (0)
420 87301
www.rg-racing.com
Email:
info@rg-racing.com
1
1
