- Page 1 MOBILE POWER SOLUTIONS DPSI SinePower DPSI1512 TS, DPSI1524 TS, DPSI2012 TS, DPSI2024 TS, DPSI3012 TS, DPSI3024 TS Sinewave inverter Installation and Operating Manual......3...
- Page 2 EN Copyright © 2024 Dometic Group. The visual appearance of the contents of this manual is protected by copyright and design law. The underlying technical design and the products contained herein may be protected by design, patent or pending patent. The trademarks mentioned in this manual belong to Dometic Sweden AB. All rights are reserved.
-
Page 3: Table Of Contents
This product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date product information, please visit documents.dometic.com. -
Page 4: Safety Instructions
EN 3 Safety instructions Also observe the safety instructions and stipulations issued by the vehicle manufacturer and authorized workshops. General safety DANGER! Electrocution hazard Do not touch exposed cables with your bare hands. To be able to disconnect the device quickly from the AC power supply, the socket must be close to the device and be easily accessible. - Page 5 EN Do not pull on the connection cables or use the cables as a handle. The device must not be exposed to rain or moisture. Store in a dry place. Installing the device safely DANGER! Explosion hazard Only install and operate the device in closed, well-ventilated rooms. Do not install or operate the device under the following conditions: •...
-
Page 6: Operating The Device Safely
EN When working on batteries, do not wear any metal objects such as watches or rings. Lead acid batteries can cause short circuits which can cause serious injuries. Only use insulated tools. Do not place any metal parts on the battery and prevent any metal parts from falling on the battery. This can cause sparks or short-circuits the battery and other electrical devices. -
Page 7: Scope Of Delivery
EN 4 Scope of delivery Designation Quantity No. in Fig. on page 7 Sine wave inverter Remote control Remote control connection cable Fixing screws – Installation and operating manual 5 Accessories Designation Ref.no. Remote control DPSI-RC 9620018306 TD283 touch display 9620013272 6 Intended use The inverter is intended to convert direct current into a pure sine wave 230 V alternating voltage (AC) for operation... -
Page 8: Technical Description
• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual Dometic reserves the right to change product appearance and product specifications. 7 Technical description General description The inverter is a DC-to-AC sine wave inverter with integrated transfer switch. -
Page 9: Control Elements And Connections
EN Control elements and connections NOTE The figures show the versions for continental Europe. Designation (+) terminal, connection to the positive pole of the house battery (–) terminal, connection to the negative pole of the house battery Status indication LED Dip switch On/off... -
Page 10: Remote Control
EN Remote control Designation No. in Fig. on page 10 On/off button Status indication LED Remote control connection Status indication LED Status Description Green Inverter operation Orange Warning: AC output present, risk of overvoltage, undervoltage, or power failures Error: No AC input present, inverter deactivated (see chapter Troubleshooting on page 19) -
Page 11: Installation
EN 8 Installation Installation location NOTICE! Damage hazard Before drilling any holes, ensure that no electrical cables or other parts of the vehicle can be damaged by drilling, sawing and filing. Do not mount the device with the connections facing upwards. NOTE The inverter can be mounted either sitting or hanging ( Fig. ... -
Page 12: Mounting The Inverter
EN Observe the following instructions when selecting an installation location: • Ensure that the mounting surface is solid and level. • Observe the distance specifications for sufficient ventilation ( Fig. on page 12). Mounting the inverter 1. Select the appropriate mounting holes depending on the selected mounting type (sitting or hanging) and mark the drilling holes ( Fig. ... -
Page 13: Mounting The Remote Control
EN Mounting the remote control 1. Mark the mounting surface ( Fig. on page 13, A). 2. Drill a hole with a diameter of 44 mm … 45 mm, e.g., with a hole saw ( Fig. on page 13, B). 3. Remove the junction box from the control panel ( Fig. ... -
Page 14: Connecting The Inverter
EN Connecting the inverter The electrical installation and setup of the device must be performed by a qualified electrician who has demonstrated skill and knowledge related to the construction and operation of electrical equipment and installations, and who is familiar with the applicable regulations of the country in which the equipment is to be installed and/or used, and has received safety training to identify and avoid the hazards involved. - Page 15 EN 3. Detach the covers from the terminals ( Fig. on page 15, A:2 – 3). NOTICE! Damage hazard To avoid short-circuiting the device always first connect the black cable (negative terminal). Connect the black (bk) connection cable to the (–) terminal. 5.
-
Page 16: Connecting The Remote Control
EN Connecting the remote control NOTE The remote control and the N-BUS/CI-BUS network cannot be connected simultaneously. Connect the remote control to the remote control connection using the remote control connection cable. Connecting the external switch NOTE If the ENB+ pin is connected, the status of the energy-saving mode cannot be changed. -
Page 17: Configuring The Network System
EN 1. Set the on/off switch to position 2. Use the ENB+ pin as follows: • To switch the inverter on connect the ENB+ pin to the house battery's positive pole via a suitable electrical cable. • To switch the inverter off detach the ENB+ pin from the house battery. 9 Configuring the network system The electrical installation and setup of the device must be performed by a qualified electrician who has demonstrated skill and knowledge related to the construction and operation of electrical equipment and... -
Page 18: Operation
EN 10 Operation 10.1 Operating 230V devices NOTE Only connect devices whose total load does not exceed the values listed in Technical data page 21. Connect 230 V devices to the AC outlet of the inverter ( Fig. on page 18). 10.2 Switching the inverter on and off NOTE... -
Page 19: Cleaning And Maintenance
EN Activating the energy saving mode 1. If necessary, switch the inverter off. 2. Slide the DIP switch S1 in position The energy saving mode is activated. Deactivating the energy saving mode 1. Switch the inverter off. 2. Slide the DIP switch S1 in position The energy saving mode is deactivated. -
Page 20: Warranty
13 Warranty The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see dometic.com/dealer) or your retailer. For repair and warranty processing, please include the following documents when you send in the device: •... -
Page 21: Technical Data
EN 15 Technical data DPSI 1512TS DPSI 2012TS DPSI 1524TS DPSI 2024TS Nominal input voltage 12 V 24 V Input voltage range 10.5 … 16.5 V 21 … 33 V Continuous output power P 1500 W 2000 W 1500 W 2000 W Maximum output power (1 min) 1725 W 2300 W... -
Page 22: General Technical Data
EN DPSI 3012TS DPSI 3024TS Dimensions Fig. on page 21 Weight 5.1 kg 5.1 kg 15.1 General technical data Output voltage range 230 V ± 10% Output frequency 50 Hz ± 1% Output waveform Pure sine wave Peak efficency Ambient temperature for operation 0 …...
